| Integrated antennas |
Flexible radio (either 2.4 GHz or 5 GHz)
- 2.4 GHz, gain 4 dBi, External antenna, omnidirectional in azimuth
- 5 GHz, gain 6 dBi, External directional antenna, elevation plane beamwidth 90°
Dedicated 5-GHz radio
- 5 GHz, gain 5 dBi, External antenna, omnidirectional in azimuth
|
| Interfaces |
◦ 2x100/1000BASE-T autosensing (RJ-45)
- Management console port (RJ-45)
- USB 2.0 (enabled via future software)
|
| Indicators |
- Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors
|
| Dimensions (W x L x H) |
- Access point (without mounting brackets): 2802I: 8.66” x 8.68” x 2.17”, 2802E: 8.66” x 8.77” x 2.50” |
| Weight |
- 3.53 lb (1.6 kg) |
| Environmental |
- Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C)
- Nonoperating (storage) altitude test: 25˚C, 15,000 ft.
- Operating temperature: 32° to 104°F (0° to 40°C)
- Operating humidity: 10% to 90% (noncondensing)
- Operating altitude test: 40˚C, 9843 ft.
|
| System |
- 1024 MB DRAM
- 256 MB flash
|
| Powering options |
- 802.3at PoE+, Cisco Universal PoE (Cisco UPOE®)
- 802.3at power injector (AIR-PWRINJ6=)
|
| Power draw |
- 26W at the PSE (22.6W at the PD) with all features enabled except for the USB 2.0 port
- 30W at the PSE (25.5W at the PD) with the USB 2.0 port enabled
|
| Compliance |
- Safety: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1
- Radio approvals: FCC Part 15.247, 15.407, RSS-247 (Canada), EN 300.328, EN 301.893 (Europe), ARIB-STD 66 (Japan), ARIB-STD T71 (Japan), EMI and susceptibility (Class B), FCC Part 15.107 and 15.109, ICES-003 (Canada), VCCI (Japan), EN 301.489-1 and -17 (Europe), EN 50385
- IEEE standards: IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d, IEEE 802.11ac
- Security: 802.11i, WPA2, WPA, 802.1X, AES
- Extensible Authentication Protocol (EAP) types: EAP-Transport Layer Security (TLS), EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2), Protected EAP (PEAP) v0 or EAP-MSCHAPv2, EAP-Flexible Authentication via Secure Tunneling (FAST), PEAP v1 or EAP-Generic Token Card (GTC), EAP-Subscriber Identity Module (SIM)
- Multimedia: Wi-Fi Multimedia (WMM)
- Other: FCC Bulletin OET-65C, RSS-102
|
| Software |
- Cisco Unified Wireless Network Software Release 8.2.111.0 or later
- Cisco IOS® XE Software Release 16.3
|
| Supported wireless LAN controllers |
- Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Catalyst® 6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco Flex® 7500 Series Wireless Controllers, Cisco 8500 Series Wireless Controllers, Cisco Virtual Wireless Controller
- Cisco Catalyst 3850 Series Switches, Cisco Catalyst 3650 Series Switches
- Cisco Mobility Express
|
| 802.11n version 2.0 (and related) capabilities |
- 4x4 MIMO with three spatial streams
- Maximal ratio combining (MRC)
- 802.11n and 802.11a/g beamforming
- 20- and 40-MHz channels
- PHY data rates up to 450 Mbps (40 MHz with 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
- 802.11 dynamic frequency selection (DFS)
- Cyclic shift diversity (CSD) support
|
| 802.11ac Wave 1 capabilities |
- 4x4 MIMO with three spatial streams
- MRC
- 802.11ac beamforming
- 20-, 40-, and 80-MHz channels
- PHY data rates up to 1.3 Gbps (80 MHz in 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
- 802.11 DFS
- CSD support
|
| 802.11ac Wave 2 capabilities |
- 4x4 MU-MIMO with three spatial streams
- MRC
- 802.11ac beamforming
- 20-, 40-, 80, 160-MHz channels
- PHY data rates up to 5.2 Gbps
- Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
- 802.11 DFS
- CSD support
|
