| TECHNICAL SPECIFICATIONS |
| AP type |
outdoor, dual radio, 5 GHz 802.11ac and 2.4 GHz 802.11n |
| Radio 5Ghz |
2x2 MIMO with two spatial streams 300 Mbps |
| Radio 2.4Ghz |
2x2 MIMO with two spatial streams 867 Mbps |
| Supported frequency bands (country-specific restrictions apply) |
- 2.4000 GHz to 2.4835 GHz
- 5.150 GHz to 5.250 GHz
- 5.250 GHz to 5.350 GHz
- 5.470 GHz to 5.725 GHz
- 5.725 GHz to 5.875 GHz |
| Available channels |
Dependent on configured regulatory domain |
| Supported radio technologies |
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
- 802.11n/ac: 2x2 MU-MIMO with up to two spatial streams |
| Supported modulation types |
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
- 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM |
| 802.11n high-throughput (HT) support |
HT20/40 |
| 802.11ac very high throughput (VHT) support: |
VHT20/40/80 |
| Supported data rates (Mbps): |
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n: 6.5 to 300 (MCS0 to MCS15)
- 802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS = 1 to 2) |
| 802.11n/ac packet aggregation: |
A-MPDU, A-MSDU |
| Transmit power |
Configurable in increments of 0.5 dBm |
| Maximum (aggregate, conducted total) transmit power (limited by local regulatory requirements): |
-2.4-GHz band: +26 dBm (23 dBm per chain)
-5-GHz bands: +25 dBm (22 dBm per chain) |
| Maximum EIRP |
- 2.4 GHz band
> 365 28.7 dBm EIRP
> 367 32.3 dBm EIRP
- 5 GHz Band
> 365 29.3 dBm EIRP
> 367 31.5 dBm EIRP |
| FLEXIBLE OPERATION AND MANAGEMENT |
| Controller-less (Instant) mode |
In controllerless mode, one AP serves as a virtual controller for the entire network. |
| Mobility Controller mode |
For optimized network performance, roaming and security, APs tunnel all traffic to a mobility controller for centrally managed traffic forwarding and segmentation, data encryption, and policy enforcement |
| Management options |
- Aruba Central (cloud-managed)
- Aruba AirWave |
| WI-FI ANTENNAS |
| Antenna |
AP-365: Integrated Omni antennas (H and V polarized)
- 2.7 dBi @ 2.4 GHz
- 4.3 dBi @ 5.x GHz |
| OTHER INTERFACES |
| Interfaces |
One 10/100/1000BASE-T Ethernet network interfaces (RJ-45)
- Auto-sensing link speed and MDI/MDX
- 802.3az Energy Efficient Ethernet (EEE)
- PoE-PD: 802.3af PoE |
| Reset button |
Yes |
| Visual indicator (LED) |
Power/system status |
| Serial console interface |
Micro USB |
| POWER SOURCES AND POWER CONSUMPTION |
| Maximum power consumption |
12.5 watts |
| Power over Ethernet (PoE) |
48 Vdc (nominal) 802.3af-compliant source |
| MECHANICAL SPECIFICATIONS |
| Dimensions/weight |
- 165mm (W) x 165mm (D) x 110mm (H)
6.5” (W) x 6.5” (D) 4.3” (H)
- 807g/1.78lbs |
| ENVIRONMENTAL SPECIFICATIONS |
| Operating conditions |
- Temperature: -40° C to +55° C (-40° F to +131°F) ambient in full sun
- Humidity: 5% to 95% non-condensing |
| Storage and transportation conditions |
- Temperature: -40° C to +70° C (-40° F to +158°F)
- EN 300 019 Storage and Transportation |
