| TECHNICAL SPECIFICATIONS |
| AP type |
High-end dual radio Wi-Fi 6 Hospitality AP with 1+4 Ethernet ports |
| 5GHz radio |
Two spatial stream (SU/MU) MIMO for up to 1.2Gbps wireless data rate (HE80) |
| 2.4GHz radio |
Two spatial stream (SU/MU) MIMO for up to 287Mbps wireless data rate (HE20) Note: HE40 operation is supported in 2.4GHz, but uncommon and not recommended for enterprise deployments |
| Maximum number of associated client devices |
Up to 256 associated client devices per radio |
| Maximum number of BSSIDs |
16 BSSIDs per radio |
| Supported frequency bands (country-specific restrictions apply) |
• 2.400 to 2.500GHz (ISM) channels 1-13
• 5.150 to 5.250GHz (U-NII-1) channels 36, 40, 44, 48
• 5.250 to 5.350GHz (U-NII-2A) channels 52, 56, 60, 64
• 5.470 to 5.725GHz (U-NII-2C) channels 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144
• 5.725 to 5.850GHz (U-NII-3) channels 149, 153, 157, 161, 165 |
| Dynamic frequency selection (DFS) optimizes the use of available RF spectrum |
| Supported radio technologies |
• 802.11b: Direct-sequence spread-spectrum (DSSS)
• 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
• 802.11ax: Orthogonal frequency-division multiple access (OFDMA) with up to 8 resource units |
| Supported modulation types |
• 802.11b: BPSK, QPSK, CCK
• 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM (proprietary extension)
• 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM (proprietary extension)
• 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM |
| 802.11n high-throughput (HT) support |
HT20/40 |
| 802.11ac very high throughput (VHT) support: |
VHT20/40/80 |
| 802.11ax high efficiency (HE) support: |
HE20/40/80 |
| Supported data rates (Mbps): |
• 802.11b: 1, 2, 5.5, 11
• 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
• 802.11n: 6.5 to 300 (MCS0 to MCS15, HT20 to HT40), 400 with 256-QAM
• 802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS = 1 to 2, VHT20 to VHT80), 1,083 with 1024-QAM
• 802.11ax (2.4GHz): 3.6 to 574 (MCS0 to MCS11, NSS = 1 to 2, HE20 to HE40)
• 802.11ax (5GHz): 3.6 to 1,201 (MCS0 to MCS11, NSS = 1 to 2, HE20 to HE80) |
| 802.11n/ac packet aggregation: |
A-MPDU, A-MSDU |
| Transmit power |
Configurable in increments of 0.5 dBm |
| Maximum (aggregate, conducted total) transmit power (limited by local regulatory requirements): |
• 2.4 GHz band: +20 dBm (17 dBm per chain)
• 5 GHz band: +21 dBm (18 dBm per chain)
• Note: conducted transmit power levels exclude antenna gain. For total (EIRP) transmit power, add antenna gain |
| Minimum configurable transmit power level |
0dBm (conducted, per chain) |
| WI-FI ANTENNAS |
| Antenna |
• Two integrated semi-directional antennas for 2x2 MIMO with peak single antenna gain of 5.2dBi in 2.4GHz and 5.4dBi in 5GHz. Built-in antennas are optimized for vertical wall or desk mounted orientation of the AP.
- Combining the patterns of each of the antennas of the MIMO radios, the peak gain of the combined, average pattern is 3.3dBi in 2.4GHz and 2.9dBi in 5GHz. |
| OTHER INTERFACES |
| Uplink (E0): Smart Rate Ethernet wired network port (RJ45) |
• Auto-sensing link speed (100/1000/2500BASE-T) and MDI/MDX
• 2.5Gbps speed complies with NBase-T and 802.3bz specifications
• 802.3az Energy Efficient Ethernet (EEE)
• POE-PD: 48Vdc (nominal) 802.3af/at/bt POE (class 3, 4 or 6) |
| Local (E1-E4): Four Ethernet wired network ports (RJ45) |
• Auto-sensing link speed (10/100/1000BASE-T) and MDI/MDX
• 802.3az Energy Efficient Ethernet (EEE)
• E1 & E2: POE-PSE: 802.3af/at POE output; dual 802.3af (both ports) or single 802.3at (E1 only) |
| DC power interface |
• 48Vdc (nominal, +/- 5%), accepts 1.35mm/3.5mm center-positive circular plug with 9.5mm length |
| USB 2.0 host interface (Type A connector) |
• Cellular modems
• IOT or other plug-in accessories
• Device battery charging port
• Capable of sourcing up to 1A / 5W to an attached device |
| Bluetooth Low Energy (BLE5.0) and Zigbee (802.15.4) radio |
• BLE: up to 7dBm transmit power (class 1) and -100dBm receive sensitivity (125kbps)
• Zigbee: up to 7dBm transmit power and -97dBm receive sensitivity (250kbps)
• Integrated semi-directional antenna with peak gain of 1.3dBi |
| Visual indictors (two multi-color LEDs): |
• Power/System status
• Radio status
• Local network port status (4x)
• POE-PSE status (2x) |
| Reset button: |
Factory reset, LED mode control (normal/off) |
| Serial console interface |
Proprietary, micro-B USB physical jack |
| FLEXIBLE OPERATION AND MANAGEMENT |
| Controller-less (Instant) mode |
In controller-less mode, one AP serves as a virtual controller for the entire network |
| Remote AP or IAP-VPN mode |
For both cloud and on-premises deployments, each AP can establish secure overlay VPN tunnels to a VPN Concentrator (VPNC). Aruba Central-managed SD-WAN Gateways and onpremises Mobility Controllers both support VPNC functionality |
| Mobility Controller mode |
For optimized network performance, roaming and security, APs tunnel all traffic to a mobility controller for centrally managed traffic forwarding and segmentation, data encryption, and policy enforcement |
| Management options |
Available management solutions include Aruba Central (cloud-managed) or Aruba AirWave – a multi-vendor on-premises management solution. |
| POWER SOURCES AND POWER CONSUMPTION |
| Power Sources: The AP supports direct DC power and Power over Ethernet |
• The AP supports direct DC power and Power over Ethernet
• When both DC and POE power sources are available, DC power takes priority over POE
• Power sources are sold separately; see the 500H Series Ordering Guide for details
• When powered by DC or 802.3bt (class 6) POE, the AP will operate without restrictions
• When powered by 802.3at (class 4) POE and with the IPM feature disabled, the AP will disable the USB port (only) if POE-PSE is enabled, and support (802.3af) POE-PSE power on E1 only (no PSE on E2)
• When powered by 802.3af (class 3) POE with the IPM feature disabled, the AP will disable the USB port and POE-PSE capability
• With IPM enabled, the AP will start up without restrictions, but may dynamically apply additional restrictions depending on the POE budget and actual power consumption. The feature specific restrictions and order in which they are applied can be configured |
| Maximum (worst-case) power consumption (without USB or PSE / max): |
• DC powered: 14W / 50W
• POE powered (802.3bt): 14W / 51W
• POE powered (802.3at): 14W / 25.5W
• POE powered (802.3af): 13.5W / 13.5W |
| Maximum (worst-case) power consumption in idle mode (without USB or PSE) |
6.2W |
| Maximum (worst-case) power consumption in deep-sleep mode (without USB or PSE) |
3.5W |
| MECHANICAL SPECIFICATIONS |
| Dimensions/weight (AP505; unit, excluding mount bracket): |
• 86mm (W) x 47mm (D) x 150mm (H)
• 360g |
| Dimensions/weight (AP-505; shipping) |
• 111mm (W) x 54mm (D) x 167mm (H)
• 450g |
| ENVIRONMENTAL SPECIFICATIONS |
| Operating conditions |
• Temperature: 0C to +40C / +32F to +104F
• Humidity: 5% to 93% non-condensing
• ETS 300 019 class 3.2 environments |
| Storage and transportation conditions |
• Temperature: -40C to +70C / -40F to +158F
• Humidity: 5% to 93% non-condensing
• ETS 300 019 classes 1.2 and 2.3 environments |
| RELIABILITY |
| Mean Time Between Failure (MTBF): |
780khrs (88yrs) at +25C operating temperature. |
| REGULATORY AND SAFETY COMPLIANCE |
| Regulatory model numbers |
• APINH505 |
| Minimum Software Release |
• ArubaOS and Aruba InstantOS 8.7.0.0 |
| Regulatory compliance (For more country-specific regulatory information and approvals, please see your Aruba representative.) |
• FCC/ISED
• CE Marked
• RED Directive 2014/53/EU
• EMC Directive 2014/30/EU
• Low Voltage Directive 2014/35/EU
• IEC/EN 60950
• EN 60601-1-1, EN60601-1-2
• IEC/EN 62368-1 |
| Certifications |
• Wi-Fi Alliance:
- Wi-Fi CERTIFIED a, b, g, n, ac
- Wi-Fi CERTIFIED 6 (ax)
- WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
- WMM, WMM-PS, Wi-Fi Vantage, Wi-Fi Agile Multiband - Passpoint (release 2)
• Bluetooth SIG
• Ethernet Alliance (POE, PD device, class 6) |
