| TECHNICAL SPECIFICATIONS |
| AP type |
Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz 2x2 MIMO and 2.4 GHz 2x2 MIMO |
| Radio 5Ghz |
Two spatial stream Single User (SU) MIMO for up to 1.2 Gbps wireless data rate with individual 2SS HE80 802.11ax client devices, or with two 1SS HE80 802.11ax MU-MIMO capable client devices simultaneously |
| Radio 2.4Ghz |
Two spatial stream Single User (SU) MIMO for up to 574 Mbps (287 Mbps) wireless data rate with individual 2SS HE40 (HE20) 802.11ax client devices or with two 1SS HE40 (HE20) 802.11ax MU-MIMO capable client devices simultaneously |
| Maximum client |
Up to 256 associated client devices per radio, 16 SSID per radio |
| Supported frequency bands (country-specific restrictions apply) |
- 2.400 to 2.4835 GHz
- 5.150 to 5.250 GHz
- 5.250 to 5.350 GHz
- 5.470 to 5.725 GHz
- 5.725 to 5.850 GHz
- 5.825 to 5.875 GHz |
| Available channels |
Dependent on configured regulatory domain |
| Supported radio technologies |
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
- 802.11ax: Orthogonal frequency-division multiple access (OFDMA) with up to 16 resource units (RU) |
| Supported modulation types |
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM (proprietary extension)
- 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024 QAM (proprietary extension)
- 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024 QAM |
| 802.11n high-throughput (HT) support |
HT20/40 |
| 802.11ac very high throughput (VHT) support: |
VHT 20/40/80 |
| 802.11ax high efficiency (HE) support |
HE20/40/80 |
| Supported data rates (Mbps): |
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n: 6.5 to 300 (MCS0 to MCS15, HT20 to HT40), 400 with 256-QAM
- 802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS = 1 to 2, VHT20 to VHT80), 1,083 with 1024-QAM
- 802.11ax (2.4GHz): 3.6 to 574 (MCS0 to MCS11, NSS = 1 to 2, HE20 to HE40) |
| 802.11n/ac/ax Packet aggregation |
A-MPDU, A-MSDU |
| Transmit power |
Configurable in increments of 0.5 dBm |
| Maximum (aggregate, conducted total) transmit power (limited by local regulatory requirements): |
- 2.4 GHz band: +23 dBm per chain, +26 dBm aggregate (2x2)
- 5 GHz band: +23 dBm per chain, +26 dBm aggregate (2x2) |
| Maximum EIRP |
- 2.4 GHz band: 33 dBm EIRP
- 5 GHz band: 32.7 dBm EIRP |
| FLEXIBLE OPERATION AND MANAGEMENT |
| Controller-less (Instant) mode |
In controllerless mode, one AP serves as a virtual controller for the entire network. |
| Mobility Controller mode |
For optimized network performance, roaming and security, APs tunnel all traffic to a mobility controller for centrally managed traffic forwarding and segmentation, data encryption, and policy enforcement |
| Management options |
- Aruba Central (cloud-managed)
- Aruba AirWave |
| WI-FI ANTENNAS |
| Antenna |
- Built-in 90°H x 90°V Directional Antennas
- 5 GHz Antennas 6.8 dBi
- 2.4 GHz Antennas 7.1 dBi
- BLE/802.15.4 Antennas 3.0 dBi |
| OTHER INTERFACES |
| Interfaces |
E0: 10/100/1000BASE-T (RJ-45)
- Auto-sensing link speed and MDI/MDX
- PoE-PD: 48Vdc (nominal) 802.3at/bt (Class 3 or higher)
- 802.3az Energy Efficient Ethernet (EEE) |
| Bluetooth 5 and 802.15.4 radio |
- 2.4 GHz - Bluetooth 5: up to 8 dBm transmit power and -95 dBm receive sensitivity
- Zigbee: up to 8 dBm transmit power and -97 dBm receive sensitivity
- Up to 4 dBm transmit power (class 2) and -91 dBm receive sensitivity |
| Reset button |
Factory reset (during device power up) |
| Visual indicator (LED) |
For system and radio status |
| Serial console interface |
USB-C console interface |
| POWER SOURCES AND POWER CONSUMPTION |
| Maximum (worst-case) power consumption |
15.6W |
| Maximum (worst-case) power consumption in idle mode |
4.2W |
| Maximum (worst-case) power consumption in deep-sleep mode |
1.7W |
| AP support power |
- Power sources sold separately
- Power over Ethernet (PoE+): 802.3at-compliant
- When powered by 1x 802.3at, there are no restrictions
- When powered by 1x 802.3af with IPM enabled, the AP will start up in unrestricted mode, but may dynamically apply restrictions depending on the POE budget and actual power. The feature restrictions can be programmed.
- When powered by 1x 802.3af with IPM disabled, the AP will lower the 2.4Ghz radio to 1x1:1 |
| MECHANICAL SPECIFICATIONS |
| Dimensions/weight |
- 16.5 cm (W) x 16.5 cm (D) x 11 cm (H)/ 6.5” (W) x 6.5” (D) x 4.3” (H)
- 1.09 kg/2.4 lbs |
| ENVIRONMENTAL SPECIFICATIONS |
| Operating conditions |
- Temperature: Temperature: -40° C to +55° C (-40° F to +140° F) with full solar loading
- Humidity: 5% to 95% non-condensing internal |
| Storage and transportation conditions |
- Temperature: -40° C to +70° C (-40° F to +158° F) |
| Operating Altitude |
3000m |
| Water and Dust |
IP66/67 |
