| TECHNICAL SPECIFICATIONS |
| AP type |
Indoor, dual radio, 5 GHz 802.11ac 4x4 MIMO and 2.4 GHz 802.11n 4x4 MIMO |
| Radio 5Ghz |
- Four spatial stream Single User (SU) MIMO for up to 1,733 Mbps wireless data rate to individual 4x4 VHT80 or 2x2 VHT160 client devices
- Four spatial stream Multi User (MU) MIMO for up to 1,733 Mbps wireless data rate to up to three MU-MIMO capable client devices simultaneously |
| Radio 2.4Ghz |
Four spatial stream Single User (SU) MIMO for up to 600 Mbps wireless data rate to individual 4x4 HT40 client devices |
| Maximum number of associated client devices |
Up to 256 associated client devices per radio |
| Maximum number of BSSIDs |
16 BSSIDs per radio |
| Supported frequency bands (country-specific restrictions apply) |
- 2.400 to 2.4835 GHz
- 5.150 to 5.250 GHz
- 5.250 to 5.350 GHz
- 5.470 to 5.725 GHz
- 5.725 to 5.850 GHz |
| Dynamic frequency selection (DFS) optimizes the use of available RF spectrum |
| Supported radio technologies |
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM) |
| Supported modulation types |
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM |
| 802.11n high-throughput (HT) support |
HT20/40 |
| 802.11ac very high throughput (VHT) support: |
VHT20/40/80/160 |
| Supported data rates (Mbps): |
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n: 6.5 to 600 (MCS0 to MCS31)
- 802.11ac: 6.5 to 1,733 (MCS0 to MCS9, NSS = 1 to 4 for VHT20/40/80, NSS = 1 to 2 for VHT160) |
| 802.11n/ac packet aggregation: |
A-MPDU, A-MSDU |
| Transmit power |
Configurable in increments of 0.5 dBm |
| Maximum (aggregate, conducted total) transmit power (limited by local regulatory requirements): |
- 2.4 GHz band: +24 dBm, 18 dBm per chain
- 5 GHz band: +24 dBm, 18 dBm per chain |
| WI-FI ANTENNAS |
| Antenna |
- Four (vertically polarized) integrated 2.4 GHz downtilt omni-directional antennas for 4x4 MIMO with peak antenna gain of 3.8dBi per antenna.
- Each 5 GHz radio chain has both a vertically and a horizontally polarized antenna element; AP software automatically and dynamically selects the best set of elements for each data packet transmitted or received.
- Four integrated vertically polarized 5 GHz downtilt omnidirectional antennas for 4x4 MIMO with peak antenna gain of 4.9dBi per antenna
- Four integrated horizontally polarized 5 GHz downtilt omni-directional antennas for 4x4 MIMO with peak antenna gain of 5.7dBi per antenna
- Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.
- Combining the patterns of each of the antennas of the MIMO radios, the peak gain of the effective per-antenna pattern is 1.6dBi in 2.4 GHz and 2.5dBi in 5 GHz. |
| OTHER INTERFACES |
| Interfaces |
• One HPE Smart Rate port (RJ-45, maximum negotiated speed 5Gbps)
- Auto-sensing link speed (100/1000/2500/5000BASE-T) and MDI/MDX
- 2.5Gbps and 5Gbps speeds comply with NBase-T and 802.3bz specifications
- PoE-PD: 48 Vdc (nominal) 802.3at PoE
• One 10/100/1000BASE-T Ethernet network interface (RJ-45)
- Auto-sensing link speed and MDI/MDX
- PoE-PD: 48 Vdc (nominal) 802.3at PoE
• Link aggregation (LACP) support between both network ports for redundancy and increased capacity
• DC power interface, accepts 1.35/3.5-mm center-positive circular plug with 9.5-mm length
• USB 2.0 host interface (Type A connector)
• Bluetooth Low Energy (BLE) radio
- Up to 4 dBm transmit power (class 2) and -91 dBm receive sensitivity
- Integrated antenna with roughly 30 degrees downtilt and peak gain of 5.1 dBi
• Visual indicators (tri-color LEDs): for System and Radio status
• Reset button: factory reset (during device power up)
• Serial console interface (RJ-45, RS232)
• Kensington security slot |
| FLEXIBLE OPERATION AND MANAGEMENT |
| Controller-managed mode |
When managed by Aruba Mobility Controllers, Aruba 330 Series Access Points offer centralized configuration, data encryption, policy enforcement, and network services, as well as distributed and centralized traffic forwarding. |
| Aruba Instant mode |
In Aruba Instant mode, a single AP automatically distributes the network configuration to other Instant APs in the WLAN. Simply power-up one Instant AP, configure it over the air, and plug in the other APs – the entire process takes about five minutes. If WLAN requirements change, a built-in migration path allows 330 series Instant APs to become part of a WLAN that is managed by a Mobility Controller |
| Remote AP (RAP) |
for branch deployments |
| Air monitor (AM) |
for wireless IDS, rogue detection, and containment. |
| POWER SOURCES AND POWER CONSUMPTION |
| Power Sources |
• The AP supports direct DC power and Power over Ethernet (PoE)
• When both power sources are available, DC power takes priority over PoE
• Power sources are sold separately
• Direct DC source: 48Vdc nominal, +/- 5%
- Interface accepts 1.35/3.5-mm center-positive circular plug with 9.5-mm length
• Power over Ethernet (PoE): 48 Vdc (nominal) 802.3af/802.3at compliant source
- When using IPM, the AP may enter power-save mode with reduced functionality when powered by a PoE source (see details on Intelligent Power Monitoring in this datasheet)
- Without IPM the AP will apply some fixed restrictions when using PoE:
> The USB interface is disabled when using an 802.3at PoE power source
> The USB interface and second Ethernet port are disabled, and both radios operate in 1x1 mode when using an 802.3af POE power source
• Maximum (worst-case) power consumption: 25.3W (802.3at PoE), 13.2W (802.3af PoE) or 25W (DC)
- Excludes power consumed by external USB device (and internal overhead); this could add up to 5.9W (PoE or DC) for a 5W/1A USB device
• Maximum (worst-case) power consumption in idle mode: 10.9W (PoE or DC)
|
| MECHANICAL SPECIFICATIONS |
| Dimensions/weight (unit, excluding mount accessories): |
• Dimensions/weight (unit, excluding mount accessories):
- 225mm (W) x 224mm (D) x 52mm (H) 8.9” (W) x 8.9” (D) x 2.0” (H)
- 1150g/41oz
• Dimensions/weight (shipping):
- 335mm (W) x 290mm (D) x 85mm (H) 13.2” (W) x 11.4” (D) x 3.35” (H)
- 1750g/62oz |
| Dimensions/weight (shipping): |
- 315mm(W) x 265mm(D) x 100mm (H) 12.4” (W) x 10.4” (D) x 3.9” (H)
- 1,350g/48 oz |
| ENVIRONMENTAL SPECIFICATIONS |
| Operating conditions |
• Operating:
- Temperature: 0° C to +50° C (+32° F to +122° F)
- Humidity: 5% to 93% non-condensing |
| Storage and transportation conditions |
- Temperature: -40° C to +70° C (-40° F to +158° F) |
| RELIABILITY |
| Mean Time Between Failure (MTBF): |
MTBF: 531,662hrs (61yrs) at +25C operating temperature |
| MINIMUM OPERATING SYSTEM SOFTWARE VERSIONS |
| ArubaOS |
6.5.0.0, 8.0.1.0 |
| Minimum Software Release |
4.3.0.0 |
