Aruba AP-203R Flex-radio 802.11ac 2x2 Unified Remote AP.

AP type

Indoor, flexible radio

Spatial Stream

• 5GHz 802.11ac 2x2 MIMO OR 2.4GHz 802.11n 2x2 MIMO1
• 5GHz 802.11ac 1x1 AND 2.4GHz 802.11n 1x1

Software-configurable

Supports 5GHz (Radio 0) and/or 2.4GHz (Radio 1)

SSID

Support for up to 256 associated client devices per radio, and up to 16 BSSIDs per AP

Frequency bands

• 2.400 to 2.4835GHz
• 5.150 to 5.250GHz
• 5.250 to 5.350GHz
• 5.470 to 5.725GHz
• 5.725 to 5.850GHz

Supported radio technologies

• 802.11b: Direct-sequence spread-spectrum (DSSS)
• 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)

Supported modulation types:

• 802.11b: BPSK, QPSK, CCK
• 802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM

Supported data rates (Mbps)

• 802.11b: 1, 2, 5.5, 11
• 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
• 802.11n: 6.5 to 300 (MCS0 to MCS15)
• 802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS = 1 to 2 for VHT20/40/80)

Transmit power

Configurable in increments of 0.5 dBm

Dimensions  (unit, excluding mount accessories)

• 155mm (W) x 50mm (D) x 95mm (H)
• 320g (AP-203R), 340g (AP-203RP)

Environmental

• Operating:

   - Temperature: 0° C to +40° C (+32° F to +104° F)

   - Humidity: 5% to 93% non-condensing

• Storage and transportation:

   - Temperature: -40° C to +70° C (-40° F to +158° F)

Regulatory

• FCC/ISED

• CE Marked

• RED Directive 2014/53/EU

• EMC Directive 2014/30/EU

• Low Voltage Directive 2014/35/EU

• UL/IEC/EN 60950

• EN 60601-1-1 and EN 60601-1-2

Minimum Operating System Software

 • ArubaOS™: 6.5.2.0/8.2.0.0

 • InstantOS™: 6.5.2.0/8.2.0.0

Power

• The AP supports direct AC power: 90V – 265V, 47Hz – 63Hz. - Note that the unit does not include an AC power cord (IEC C7 plug). A compatible region-specific cord should be selected and added when ordering the AP.

• Maximum (worst-case) power consumption: 8.2W. - Excludes power consumed by external USB and/or PoE-PD device (and internal losses); this could add up to 5.7W for a 5W/1A USB device and up to 17.2W for a max load (15.4W) 802.3af PoE-PD device

• Maximum (worst-case) power consumption in idle mode: 5.0W.
