| Capabilities and Capacities |
|
Throughput: Application Control (AVC)
|
850 Mbps |
|
Throughput: Application Control (AVC) and IPS
|
450 Mbps |
| Maximum concurrent sessions |
250,000 |
| Maximum New Connections per second |
20,000 |
| Supported applications |
More than 3,000 |
| URL categories |
80+ |
| Number of URLs categorized |
More than 280 million |
| Centralized configuration, logging, monitoring, and reporting |
Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center |
| On-Device Management |
ASDM (version 7.3 or higher required) |
| Features and Capacities |
| Stateful inspection throughput (maximum) |
1.8 Gbps |
| Stateful inspection throughput (multiprotocol) |
900 Mbps |
| Triple Data Encryption Standard/Advanced Encryption Standard (3DES/AES) VPN throughput |
250 Mbps |
| Users/nodes |
Unlimited |
| IPsec site-to-site VPN peers |
300 |
| Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections |
300 |
| Virtual interfaces (VLANs) |
100 |
| Security contexts (included; maximum) |
2; 5 |
| High availability |
Active/Active and Active/Standby |
|
Integrated Wireless Access Point
(See Cisco AP 702 datasheet for WiFi technical details)
|
N/A |
|
Expansion slot
|
N/A |
|
User-accessible Flash slot
|
No |
|
USB 2.0 ports
|
USB port type ‘A’, High Speed 2.0 |
|
Integrated I/O
|
8 x 1GE |
|
Expansion I/O
|
N/A |
|
Dedicated management port
|
Yes (To be shared with FirePOWER Services), 10/100/1000 |
|
Serial ports
|
1 RJ-45 and Mini USB console |
|
Solid-state drive
|
100 GB mSata |
|
Memory
|
8 GB |
|
System flash
|
8 GB |
|
System bus
|
Multibus architecture |
|
Operating Parameters
|
| Temperature |
32 to 104°F (0 to 40 °C) |
| Relative humidity |
10 to 90 percent noncondensing |
| Altitude |
Designed and tested for 0 to 10,000 ft (3050 m) |
| Acousticnoise |
41.6 A-weighted decibels (dBA) type, 67.2 dBA max |
| Non-operating Parameters |
| Temperature |
-13 to 158ºF (-25 to 70ºC) |
| Relative humidity |
10 to 90 percent noncondensing |
| Altitude |
Designed and tested for 0 to 15,000 ft (4572 m) |
| Power Input (per power supply) |
| AC range line voltage |
External, 90 to 240 volts alternating current (VAC) |
| AC normal line voltage |
92 to 240 VAC |
| AC current |
0.25AC amps |
| AC frequency |
50/60 Hz |
| Dual-power supplies |
None |
| DC domestic line voltage |
N/A |
| DC international line voltage |
N/A |
| DC current |
N/A |
| Output |
| Steady state |
12V @ 3.0A |
| Maximum peak |
12V @ 5.0A |
| Maximum heat dissipation |
205 Btu/hr |
| Form factor |
1 rack unit (RU), 19-in. rack-mountable |
| Dimensions (H x W x D) |
1.72 x 17.2 x 11.288 in. (4.369 x 43.688 x 28.672 cm) |
| Weight (with AC power supply) |
8 lb (3 kg) |
