| Capabilities and Capacities |
|
Throughput: Application Control (AVC)
|
850 Mbps |
|
Throughput: Application Control (AVC) and IPS
|
450 Mbps |
| Maximum concurrent sessions |
250,000 |
| Maximum New Connections per second |
20,000 |
| Supported applications |
More than 3,000 |
| URL categories |
80+ |
| Number of URLs categorized |
More than 280 million |
| Centralized configuration, logging, monitoring, and reporting |
Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center |
| On-Device Management |
ASDM (version 7.3 or higher required) |
| Features and Capacities |
| Stateful inspection throughput (maximum) |
1.8 Gbps |
| Stateful inspection throughput (multiprotocol) |
900 Mbps |
| Triple Data Encryption Standard/Advanced Encryption Standard (3DES/AES) VPN throughput |
250 Mbps |
| Users/nodes |
Unlimited |
| IPsec site-to-site VPN peers |
300 |
| Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections |
300 |
| Virtual interfaces (VLANs) |
100 |
| Security contexts (included; maximum) |
2; 5 |
| High availability |
Active/Active and Active/Standby |
|
Integrated Wireless Access Point
(See Cisco AP 702 datasheet for WiFi technical details)
|
N/A |
|
Expansion slot
|
N/A |
|
User-accessible Flash slot
|
No |
|
USB 2.0 ports
|
USB port type ‘A’, High Speed 2.0 |
|
Integrated I/O
|
8 x 1GE |
|
Expansion I/O
|
N/A |
|
Dedicated management port
|
Yes (To be shared with FirePOWER Services), 10/100/1000 |
|
Serial ports
|
1 RJ-45 and Mini USB console |
|
Solid-state drive
|
100 GB mSata |
|
Memory
|
8 GB |
|
System flash
|
8 GB |
|
System bus
|
Multibus architecture |
|
Operating Parameters
|
| Temperature |
32 to 104°F (0 to 40 °C) |
| Relative humidity |
10 to 90 percent noncondensing |
| Altitude |
Designed and tested for 0 to 10,000 ft (3050 m) |
| Acousticnoise |
41.6 A-weighted decibels (dBA) type, 67.2 dBA max |
| Non-operating Parameters |
| Temperature |
-13 to 158ºF (-25 to 70ºC) |
| Relative humidity |
10 to 90 percent noncondensing |
| Altitude |
Designed and tested for 0 to 15,000 ft (4572 m) |
| Power Input (per power supply) |
| AC range line voltage |
External, 90 to 240 volts alternating current (VAC) |
| AC normal line voltage |
92 to 240 VAC |
| AC current |
0.25AC amps |
| AC frequency |
50/60 Hz |
| Dual-power supplies |
None |
| DC domestic line voltage |
N/A |
| DC international line voltage |
N/A |
| DC current |
N/A |
| Output |
| Steady state |
12V @ 3.0A |
| Maximum peak |
12V @ 5.0A |
| Maximum heat dissipation |
205 Btu/hr |
| Form factor |
1 rack unit (RU), 19-in. rack-mountable |
| Dimensions (H x W x D) |
1.72 x 17.2 x 11.288 in. (4.369 x 43.688 x 28.672 cm) |
| Weight (with AC power supply) |
8 lb (3 kg) |
Switch
.png){kind=icon}
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: ASA5516-FPWR-K8 ?
Chào anh,
Nhân viên tư vấn CNTTShop sẽ liên hệ tới anh để báo giá Cisco ASA5516-FPWR-K8, anh vui lòng để ý điện thoại ạ.
Thiết bị tường lửa Cisco Firewall ASA5516-FPWR-K8 có tính năng lọc web, nhưng cần mua license để kích hoạt nhé bạn.
Thông lượng tường lửa của CIsco Firewall ASA5516-FPWR-K8 là 1.8 Gbps nhé bạn.
Thiết bị tường lửa Cisco Firewall ASA5516-FPWR-K8 mặc định dùng nguồn AC, không có tùy chọn nguồn DC nhé bạn.
CNTTShop phân phối thiết bị Cisco ASA chính hãng giá tốt. Thiết bị tường lửa Cisco Firewall ASA5516-FPWR-K8 do CNTTShop phân phối có đầy đủ CO, CQ kèm theo nhé bạn.
