| Physical Specifications |
| Width x depth x height |
218 mm x 55.5 mm x 250 mm (8.6 in x 2.2 in x 9.9 in) |
| Weight |
2kg |
| Protection rating |
IP67 |
| Interfaces |
| Ethernet Standard |
IEEE 802.3 (10T)
IEEE 802.3u (100TX)
IEEE 802.3ab (1000T) |
| Ports Connector |
1 Internal RJ-45 female, with waterproof cable gland |
| Power Characteristics |
| PoE |
- IEEE 802.3at
- Max. consumption: 19.4W
- Avg. consumption: 16.5W |
| Specifications |
| Wireless |
- IEEE 802.11a/b/g/n/ac 2x2:2ss MIMO
- IEEE 802.11d
- IEEE 802.11e (WMM)
- IEEE 802.11h
- IEEE 802.11i (enhanced security)
- WPA/WPA2-Personal
- WPA/WPA2-Enterpris |
| Operational Modes |
- Allied Telesis Unified Wireless Controller
- AP Cluster (up to 16 members)
- Standalone |
| Management |
- Graphical User Interface (HTTP, HTTPS)
- Simple Network Management Protocol (SNMPv1, v2c)
- Extended MIB set |
| Security |
- 128-bit hardware-accelerated AES encryption/decryption
- WPA/TKIP, WPA2/CCMP
- Extensible Authentication Protocol (EAP)
- Protected Extensible Authentication Protocol (PEAP)
- MAC address filtering
- IEEE 802.1X RADIUS support
- IEEE 802.1X authentication
- IEEE 802.1X dynamic VLAN assignment
- Rogue AP detection |
| Environmental Specifications |
| Operating temperature |
-40° to 65°C (-40° to 149°F) |
| Operating humidity |
≤95% relative (non-condensing) |
| Storage temperature |
-40° to 70°C (-40° to 158°F) |
| Storage humidity |
≤95% relative (non-condensing) |
| Operating altitude |
≤2,000m (9,843ft) |
| Embedded Antennas |
| Omni-directional |
Frequency band: 2.4 GHz
Max. peak gain: 5 dBi |
| Omni-directional |
Frequency band: 5GHz
Max. peak gain: 7 dBi |
| Radio Characteristics |
| Supported Frequencies |
- 2.400 ~ 2.4835 GHz
- 5.150 ~ 5.250 GHz
- 5.250 ~ 5.350 GHz
- 5.470 ~ 5.725 GH
- 5.725 ~ 5.850 GHz |
| Modulation Technique |
- 02.11a/g/n/ac: OFDM
- 802.11b: DSSS, CCK, DQPSK, DBPSK
- 802.11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM
- 802.11a/g/n: BPSK, QPSK, 16QAM, 64QAM |
| Data Rate |
- 802.11a/g: 54/48/36/24/18/12/9/6Mbps
- 802.11b: 11/5.5/2/1Mbps
- 802.11n: 6.5 – 450Mbps (MCS 0 - 15)
- 802.11ac: 6.5 – 1867Mbps (MCS 0 - 9, NSS 1 - 2) |
| Media Access |
- CSMA/CA + Ack with RTS/CTS |
| Diversity |
- Spatial diversity |
