| Physical Specifications |
| Width x depth x height |
215 x 215 x 48 mm (8.46 x 8.46 x 1.89 in) |
| Weight |
700 g (24.69 oz) |
| 10/100/1000T (RJ-45) copper ports |
2 (1 PoE-in port) |
| Power Characteristics |
| PoE |
Average: 10W
Maximum: 19W
Max heat dissipation: 64 BTU/h |
| 100-240VAC |
Average: 10W
Maximum: 20W
Max heat dissipation: 67 BTU/h |
| Specifications |
| Wireless |
- Multi-channel operation
- Airtime fairness
- Automatic channel selection
- Automatic control of transmission power
- Band Steering
- Fast roaming
- RF load balancing
- Wireless Distribution System (WDS)
- Wi-Fi Multimedia (WMM) for traffic prioritization
- Deploy with no data cables using AWC-SC |
| Operational Modes |
- Centrally managed in multi-channel mode by Vista Manager EX (up to 3,000 APs)
- Centrally managed in single-channel or hybrid mode (multi-channel and single-channel) by Vista Manager EX (up to 100 APs per Channel Blanket)
- Standalone |
| Management |
- Graphical User Interface (HTTP/HTTPS)
- Simple Network Management Protocol (SNMPv1, v2c, v3)
- Firmware upgrade
- Backup/restore settings
- Syslog notification
- DHCP client
- NTP client |
| Security |
- Authentication and accounting
Captive Portal (External RADIUS, Click-Through)
IEEE 802.1X authentication and accounting
IEEE 802.1X RADIUS support
Shared Key Authentication
WPA (Enterprise, Personal)
WPA2 (Enterprise, Personal)
WPA3 (Enterprise, Personal)
Captive Portal (External RADIUS, Click-Through)
Passpoint
- Encryption
WEP: 64/128 bit (IEEE 802.11a/b/g only)
WPA/WPA2: CCMP (AES), TKIP
WPA3: CCMP (AES/CNSA)
- MAC address filtering (Up to 2048 MAC address)
- SSID hiding/ignoring
- Client isolation
- Neighbor AP detection
- Kensington lock |
| Environmental Specifications |
| Operating temperature range |
PoE: 0°C to 50°C (32°F to 122°F)
AC adapter: 0°C to 45°C (32°F to 113°F) |
| Storage temperature range: |
-25°C to 70°C (-13°F to 158°F) |
| Operating relative humidity range |
90% non-condensing |
| Storage relative humidity range |
95% non-condensing |
| Supplied External Antennas |
| Omni-directional |
Frequency band: 2.4 GHz
Max. peak gain: 3.95 dBi
Supports Channel Blanket |
| Omni-directional |
Frequency band: 5GHz (5.2-5.3GHz)
Max. peak gain: 4.20 dBi
Supports Channel Blanket |
| Omni-directional |
Frequency band: 5GHz (5.6-5.8GHz)
Max. peak gain: 4.83 dBi |
| Radio Characteristics |
| Supported Frequencies |
- 2.400 ~ 2.4835 GHz
- 5.150 ~ 5.250 GHz
- 5.250 ~ 5.350 GHz
- 5.470 ~ 5.725 GH
- 5.725 ~ 5.850 GHz |
| Modulation Technique |
- 02.11a/g/n/ac: OFDM
- 802.11b: DSSS, CCK, DQPSK, DBPSK
- 802.11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM
- 802.11a/g/n: BPSK, QPSK, 16QAM, 64QAM, 256QAM |
| Data Rate |
- 802.11a/g: 54/48/36/24/18/12/9/6Mbps
- 802.11b: 11/5.5/2/1Mbps
- 802.11n: 6.5 - 400Mbps (6) (MCS 0 - 15)
- 802.11n: 6.5 - 300Mbps (MCS 0 - 15)
- 802.11ac: 6.5 – 866.7Mbps (MCS 0 - 9, NSS 1 - 2) |
| Media Access |
- CSMA/CA + Ack with RTS/CTS |
| Diversity |
- Spatial diversity |
