Product Description |
Allied Telesis AT x240-10GTXm - switch - 8 ports - Managed - rack-mountable |
Device Type |
Switch - 8 ports - L3 - Managed |
Enclosure Type |
Rack-mountable |
Subtype |
5 Gigabit Ethernet |
Ports |
8 x 10/100/1000/2.5G/5G + 2 x 1 Gigabit / 10 Gigabit SFP+ |
Performance |
Switching capacity: 120 Gbps
Forwarding performance: 89.3 Mpps
Latency (1 Gbps): 4.5 µs
Latency (2.5 Gbps): 8.7 µs
Latency (5 Gbps): 5.9 µs
Latency (10 Gbps): 2.9 µs
Packet buffer size: 3MB |
Capacity |
IP multicast entries: up to 100
VLANs supported: 4094 |
MAC Address Table Size |
32K entries |
Jumbo Frame Support |
9KB |
Routing Protocol |
CIDR |
Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, SSH-2, CLI, SSH 6, TACACS+, RADIUS, MIB |
Features |
Flow control, full duplex capability, auto-negotiation, ARP support, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, WRR queuing, IPv6 support, SNTP support, RSTP support, MSTP support, DHCP snooping, TFTP support, ACL support, QoS, MLD snooping, DAI, PVST+, STP Root Guard, SNMP trap, DHCP client, Energy Efficient Ethernet, NAC, SPQ, loop prevention, static routing, packet storm protection, SFTP client, Storm Control, EPSRing, BIST, Cable fault locator (TDR), DDM, Active Fiber Monitoring, Voice VLAN, CFM, CPP, Find my Switch, IP Link Ethernet monitoring, IPv4 and IPv6 dual stack, BPDU protection, loop detection, loop protection, web GUI management portal, eco-friendly button, AMF Plus, UFO, ping polling, PVST+, SCP, UDLD, RSPAN |
Compliant Standards |
IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX |
Power |
Ac 100- 240 V |
Dimensions (WxDxH) |
21 cm x 27.5 cm x 4.25 cm |
Weight |
1.9 kg |
