| Performance |
| Firewall throughput |
750 Mbps |
| Concurrent sessions |
100,000 |
| New sessions per second |
3,600 |
| IPS throughput |
200 Mbps |
| VPN throughput |
400 Mbps |
| Processor and memory |
| Security processor |
800MHz dual-core |
| Memory (RAM) |
512MB |
| Memory (Flash) |
4GB |
| Tunneling & encryption |
| IPsec site-to-site VPN tunnels |
50 |
| SSL VPN users |
100 |
| Encrypted VPN |
IPsec, SHA-1, SHA-256, SHA-512, IKEv2, SSL/TLS VPN |
| Encryption |
3DES, AES-128, AES-192, AES-256 |
| Key exchange |
Diffie-Hellman groups 2, 5, 14, 15, 16, 18 |
| Dynamic routed VPN |
RIP, OSPF, BGP, RIPng, OSPFv3, BGP4+ |
| Point to point |
Static PPP, L2TPv2 virtual tunnels, L2TPv3 Ethernet pseudo-wires |
| Encapsulation |
GRE for IPv4 and IPv6 |
| Networking |
| Routing (IPv4) |
Static, Dynamic (BGP4, OSPF, RIPv1/v2), source-based routing, policy-based routing, VRF-Lite, SD-WAN |
| Routing (IPv6) |
Static, Dynamic (BGP4+, OSPFv3, RIPng), policy-based routing, SD-WAN |
| Multicasting |
IGMPv1/v2/v3, PIM-SM, PIM-DM, PIM-SSM, PIMv6 |
| Resiliency |
STP, RSTP |
| High availability |
VRRP, VRRPv3, hardware controlled bypass port |
| Traffic control |
8 priority queues, DiffServ, HTB scheduling, RED curves |
| IP address management |
Static v4/v6, DHCP v4/v6 (server, relay, client), PPPoE |
| NAT |
Static, IPsec traversal, Dynamic NAPT |
| Link aggregation |
802.3ad static and dynamic (LACP) |
| VLANs |
802.1Q tagging |
| Discovery |
LLDP, LLDP-MED |
| Hardware characteristics |
| Input power |
90 to 260V AC (auto-ranging), 47 to 63Hz |
| Max power consumption |
14 watts |
| LAN ports |
4 x 10/100/1000T RJ-45 |
| WAN port |
1 x 10/100/1000T RJ-45 |
| High Availability bypass ports |
1 x 10/100/1000T RJ-45 |
| Other ports |
1 x USB, 1 x RJ-45 console |
| Product dimensions (H x W x D) |
42.5mm (1.67 in) x 210mm (8.26 in) x 220mm (8.66 in) |
| Packaged dimensions (H x W x D) |
112 mm (4.41 in) x 254 mm (10.00 in) x 360 mm (14.17 in) |
| Product weight |
1.8 kg (4.0 lb) unpackaged, 2.5 kg (5.51 lb) packaged |
| Environmental specifications |
| Operating temperature range |
0°C to 45°C (32°F to 113°F). Derated by 1°C per 305 meters (1,000 ft) |
| Storage temperature range |
-20°C to 60°C (-4°F to 140°F) |
| Operating relative humidity range |
5% to 80% non-condensing |
| Storage relative humidity range |
5% to 95% non-condensing |
| Operating altitude |
2,000 meters maximum (6,600 ft) |
