| Datasheet Cambium XV2-21X |
| Access Point Specifications |
| Radios |
5 GHz 802.11 a/n/ac Wave 2/ax, 2x2:2
2.4 GHz 802.11 b/g/n/ax, 2x2:2 |
| Wi-Fi |
802.11 a/b/g/n/ac Wave 2/ax |
| SSID Security |
WPA3-SAE, WPA3-Enterprise, WPA2 (CCMP, AES, 802.11i), WPA2 Enterprise (802.1x/EAP), WEP, Open |
| Max PHY Rate |
5 GHz radio 2402 Mbps
2.4 GHz radio 573.5Mbps |
| Ports |
1 x IEEE 10/100/1000 Mbps |
| Antenna |
5 GHz 6 dBi
2.4 GHz 5 dBi |
| Max EIRP |
5 GHz 33 dBm
2.4 GHz 32 dBm |
| Power |
Typical 11W, Maximum 12.95W 802.3af powered device |
| Dimensions |
155 mm x 155 mm x 37 mm
(6.1 in x 6.1 in x 1.46 in)
With Bracket:
155 x 155 x 46 mm
(6.1 x 6.1 x 1.81 in) |
| Weight |
475g (1.05 lbs) |
| LEDs |
Multi-color status LEDs, dimmable, on/of |
| Ambient Operation Temperature |
0ºC to 50ºC (32ºF to 122ºF) |
| Storage Temperature |
-40ºC to 70ºC (-40ºF to 158ºF) |
| Humidity |
95% RH non-condensing |
| MTBF |
1,980,244 hours at 50ºC ambient (estimated) |
| Mount Options |
Wall or ceiling, T-bar with included locking bracket, ceiling tile plate |
| Certifications (Compliance) |
Passpoint 3.0,
802.11 a/b/e/g/i/k/n/r/u/v/w/ac/ax, PP2.0
FCC, IC, ETSI, CE, EN 60601-1-2, IEC60950,
UL2043, EN 61373 |
| Network Specifications |
| Operational Modes |
Controller-less standalone
Cloud-managed cnMaestro, VM |
| WLAN |
16 WLAN profiles per radio
128 clients per radio, 16 SSIDs,
WPA-TKIP, WPA2 AES, 802.1x
802.11w PMF |
Guest Access/
Captive Portal |
cnMaestro, On-AP hosted guest portal
Social login, Voucher based login, SMS
gateway, Payment gateway support.
Supports radius based authentication.
cnMaestro API support for external captive
portal integration. |
| Authentication Encryption |
Hotspot 2.0, 802.1x EAP-SIM/AKA,
EAP-PEAP, EAP-TTLS, EAP-TLS, MAC
Authentication local database or RADIUS |
| Scheduled WLAN |
On/off by day, week, time of day |
| Data Limit |
Client bitrate/time/throughput limit per SSID |
| Subscriber QoS |
WMM |
| Fast Roaming |
802.11r, OKC, cnMaestro assisted roam |
| Mesh |
Multi-hop, either band |
| Channel Selection |
Multi-modal channel selection with AutoChannel and autotune (cnMaestro) |
| RF Management |
Multi-Modal RF optimization supporting AutoRF (cnMaestro) performed in the intelligent edge AP. Out of band RF spectrum analysis, RF monitor with chn/ noise/interference |
| Network |
TCP connection log, NAT logging firewall, DHCP server, L2, L3 or DNS based access control, VLAN Pooling, RADIUS attribute VID VLAN per SSID per user |
| Band Steer Load Balance |
Yes |
| Tunnel |
L2TPv2, L2GRE, PPPoE |
| Network Tools |
Wired and wireless remote packet capture, logging, ZapD |
| Network and RF Management Tools |
Wired and wireles remote packet capture, ZapD performance tool, rogue AP detection |
| Services |
L2-L7 application visibility & control, WiFi Calling control, WIDs/WIPs, NTP, Syslog, SNMP traps, DNS proxy, auto-off on WAN failure |
| API |
RESTful management and statistics API Presence location APIs |
| IP |
IPv4, IPv6 |
| Standards |
| Wi-FiProtocols |
VHT MCS rates, 16/64/256/1024-QAM, 20/40/80/160 MHz |
| TWT, Long OFDM Symbol, Transmit beamforming, Airtime Fairness, AMSDU, AMPDU, RIFS, STBC, LDPC, MIMO Power Save, MRC, BPSK, QPSK, CCK, DSSS, OFDM, OFDMA, UL/DL MU-MIMO |
| IEEE 802.11 a/ac/ax/b/d/e/g/h/i/k/n/r/u/v |
