| Uplink |
2x QSFP28 (100 GE or 40 GE or 4x25 GE)
2x SFP28 / SFP+ (25 GbE or 10 GbE) |
| PON |
16 PON Ports Supporting PON: GPON, XGS-PON, or Combo PON
Maximum Split Ratios: XGS-PON 1:256, GPON 1:128, (ITU-T G.9807.1, ITU-T G.984.1, ITU-T G.984.2, ITU-T G.984.3, ITU-T G.984.4) |
| Management |
Console ports: USB 2.0, D-SUB 9-Pin, 1x RJ-45 Out-of-Band Management (100/1000-BaseT)
In-band and out-of-band IPv4 & IPv6 Management |
| Performance |
Non-blocking switching capacity: 300Gb/s
Jumbo frames: 9K, MAC address: 16K, VLAN number: 4K |
| Environmental |
4+1 Left-to-Right Airflow Fan Modules (SDA FAN)
Operating temperature: -40°F to 149°F (-40°C to +65°C)
Relative humidity: 5% to 95% |
| Power |
Hot Swappable Redundant Power Modules (AC is a priority when using AC and DC)
AC PSU: Universal 250W AC (100 to 240VAC, 50 Hz to 60 Hz)
DC PSU: -48VDC 250W (-72 to -38.4VDC) |
| Networking |
DHCP Relay, Option 82 Support
IGMP V2/V3 Multicast Support VLAN tagging, Support IEEE 802.1Q, SVLAN, CVLAN, Q-in-Q
IEEE 802.1p QoS Service Prioritization Support |
| Single Management Interface |
8 or 16 PON (Downlink) interfaces and 4 Uplink Interfaces. |
| Dimensions |
440 x 260 x 44.5 mm
17.32 x 10.24 x 1.75 in |
| Management |
SNMP, Syslog, CLI, API, TR-069, and cnMaestro Support for ease of use |
| Network Protection |
G.8032 Ring protection, RSTP, Rogue ONT Detection, AES Encryption |
| Provisioning |
Advanced QoS, service rate limits, VLAN, Q-in-Q, full statistics engine |
