| Access Point Specifications |
| Frequency Bands |
US-FCC:
2400 – 2484 MHz, 5150 – 5250 MHz
Industry Canada (ISEDC):
2400 – 2484 MHz, 5725 – 5850 MHz
EU-ETSI:
2400 – 2484 MHz, 5150 – 5250 MHz
ROW (individual country limits may apply. Consult DoC):
2400 – 2500 MHz, 5150 – 5850 MHz
|
| SSID Security |
WPA2 (802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK, Open |
| Max Phy Rate |
2.4 GHz radio: 300 Mbps
5 GHz radio: 867 Mbps
|
| Ethernet Ports |
Five IEEE Gigabit Ethernet auto sensing
USB 2.0
|
| Antenna |
External duplexed antenna, 5dBi |
| Max EIRP |
2.4 GHz: 27 dBm
5 GHz: 20 dBm
|
| Voice |
2 ATA ports via RJ11 |
| Power |
12VDC, 1a. 2.1mm x 5.5mm DC barrel connector |
| Physical Environmental |
190 mm x 135 mm x 40 mm
Status LEDs
0C - + 50C ambient op temp
-40C - + 70C storage temperature 95% RH non-condensing
|
| Certifications |
FCC, ETSI, CE, EN 60601-1-2, IEC60950 |
| WLAN AND NETWORK SPECIFICATIONS |
| Controller mode |
Cloud managed cnMaestro HTTP/HTTPS web interface
|
| WLAN |
64 clients, 8 SSIDs WPA-TKIP, WPA2 AES, 802.1x
|
| Authentication |
802.1x EAP-SIM/AKA, EAP-PEAP, EAP- TTLS, EAP-TLS
MAC authentication to external RADIUS
|
| Accounting |
RADIUS accounting, multiple AAA |
| Subscriber QoS |
WMM. |
| Management |
- Firmware Upgrade
- Web Management Interface
- Local and Remote Syslog (RFC3164)
- Auto Provisioning
- SNTP Time Synchronization
- Multi User Level SNMP v2
- Telnet
- TR069
- System Log: local log and remote log
|
| Network |
- Support NAT mode and Bridge mode
- Support DDNS
- MAC address cloning
- Built-in Wired speed NAT Router
- DHCP Server and Client
- IP conflict detection
- Port Forwarding, DMZ, SuperDMZ
- 802.1Q VLAN/802.1p, DSCP, Rate Limiting
- VPN (PPTP,L2TP, IPSec) Passthrough
- SNTP
- IGMPv2
- Firewall (SYN Flooding, IP Spoofing, Smurf Attack, Ping of Death, DoS)
|
| Protocols |
- DHCP/PPPoE
- HTTP Server for Web Management
- TFTP/HTTP for Auto Provisioning
- DHCP Option Codes for SIP (RFC3361)
- DNS/DNS SRV (RFC1706 and RFC 2782)
- IEEE802.1Q VLAN/802.1p and IP DSCP
- SNTP
|
