| Access Point Specifications |
| Radios |
5 GHz radio (802.11a/n/ac Wave 2/ax), 8x8 (or configure as 2 x 5 GHz 4x4)
2.4 GHz (802.11b/g/n/ax), 4x4 Dual-band scan radio, 1x1 BLE 4 |
| Wi-Fi |
802.11a/b/g/n/ac Wave 2/ax |
| SSID Security |
WPA3, WPA2 (CCMP, AES, 802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK (TKIP), Open |
| Max Phy Rate |
2.4 GHz radio: 1,147 Mbps
5 GHz radio: 4,804 Mbps |
| Ports |
1 x IEEE gigabit, auto sensing
1 x IEEE 5 gigabit Ethernet auto sensing (802.3bz)
1 x USB 3.0 |
| Antenna |
5 dBi (2.4 GHz) 6.7 dBi (5 GHz), Omni dual - band sensor antenna, 5 dBi (2.4 GHz) / 6.3 dBi (5 GHz) BLE antenna, 5 dBi |
| Max EIRP |
2.4 GHz: 31 dBm
5 GHz: 36 dBm |
| Power |
Max power with USB/BLE, 35 W (802.3bt) 802.3at mode with USB/BT disabled 12 VDC power, 2.1 mm (.083 in) barrel connector |
| Dimensions |
235 mm x 235 mm x 42 mm (9.25 in x 9.25 in x 1.65 in) |
| Weight |
1,250 g (2.76 lbs) |
| Security |
Kensington lock slot |
| LEDs |
Multi-color status LEDs |
| Ambient Operating Temperature |
0ºC to 50ºC (32ºF to 122ºF) |
| Storage Temperature |
-20ºC to 70ºC (-4ºF to 158ºF) |
| Humidity |
95% RH non-condensing |
| Mount Options |
Wall or ceiling, T-bar with included locking bracket |
| Certifications (Compliance) |
Wi-Fi Alliance 80211a/b/g/n/ac/ax, PP2.0 FCC, ETSI, CE, EN 60601-1-2, IEC60950 |
| Management |
| Management |
Cambium XMS Management
Cambium cnMaestro Management |
| Network Specifications |
| WLAN |
1,024 clients, 16 SSIDs
WPA3, WPA-TKIP, WPA2 AES, 802.1x,
802.11w PMF |
| Authentication Encryption |
802.1x EAP-SIM/AKA, EAP-PEAP, EAP-TTLS, EAP-TLS MAC authentication to local database or external RADIUS |
| Scheduled WLAN |
On/off by day, week, time of day |
| QoS |
WMM, 802.11e |
| VLAN |
802.11q |
| Fast Roaming |
802.11r, OKC, Enhanced roaming |
| Channel Selection |
Manual or automatic |
| TX Power |
Manual or automatic |
| Network |
NAT, NAT logging firewall, DHCP server L2, L3 or DNS based access control VLAN Pooling, RADIUS attribute VID VLAN per SSID per user |
| Band Steer Load Balance |
Yes |
| Tunnel |
L2TP, L2oGRE, PPPoE |
| Network and RF Management Tools |
Out-of-band RF spectrum analysis, radio self-test network assurance, RF monitor with chn/noise/interference, wired and wireless remote packet capture, auto logging, ZapD performance tool, rogue AP detection, ultra low power mode, honeypot control |
| Wi-Fi Protocols |
- MU-OFDMA, MU-MIMO, TWT, MIMO, VHT MCS rates, 16/64/256-QAM, HT20/40/80 MHz
- Transmit beamsteering, Airtime Fairness, AMSDU, AMPDU, RIFS, STBC, LDPC, MIMO Power Save, MRC, BPSK, QPSK, CCK, DSSS, OFDM
- IEEE 802.11a/ac/ax/b/d/e/g/h/i/k/r/u/v
|
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: XV3-8X00A00-RW ?
Chào anh/chị, bộ phát wifi 6 chuyên dụng Cambium XV3-8X00A00-RW có hỗ trợ các thiết bị sử dụng chuẩn wifi cũ hơn như 802.11a/g/n/ac.
Chào anh,chị, bộ phát wifi 6 Cambium XV3-8X00A00-RW có thể cấu hình DHCP được ạ.
Chào anh/chị, bộ phát wifi 6 Cambium XV3-8X00A00-RW không cần thêm license gì để hoạt động ạ.
Báo giá bộ phát wifi 6 cambium XV3-8X00A00-RW đã được gửi vào email, anh/chị vui lòng kiểm tra.
Bộ phát wifi 6 cambium XV3-8X00A00-RW dùng được đồng thời 2 băng tần 2.5Ghz và 5Ghz bạn nhé.
