AIR-AP1542I-S-K9 Cisco Aironet 1540 Dual-band 802.11a/g/n/ac, Wave 2, internal omni antennas

Cisco AIR-AP1542I-S-K9 Aironet 1540 Dual-band 802.11a/g/n/ac, Wave 2, internal omni antennas, Support 400 User
Mã sản phẩm: AIR-AP1542I-S-K9
Tình trạng: Còn hàng
Check Giá List

Cisco AIR-AP1542I-S-K9 Aironet 1540 Dual-band 802.11a/g/n/ac, Wave 2, internal omni antennas

Cisco Part Number        : AIR-AP1542I-S-K9
Bảo hành                       : 12 tháng
List Price                       : $995
Stock                             : Liên hệ

Mô tả Cisco Aironet AIR-AP1542I-S-K9:

Bộ phát wifi Cisco Aironet AIR-AP1542I-S-K9 lý tưởng cho các ứng dụng yêu cầu vùng phủ sóng Wi-Fi ngoài trời và hỗ trợ chuẩn vô tuyến 802.11ac Wave 2 mới nhất. Được thiết kế nhỏ gọn, thẩm mỹ, dễ triển khai, AIR-AP1542I-S-K9 cung cấp các tùy chọn triển khai linh hoạt cho các nhà cung cấp dịch vụ và mạng doanh nghiệp cần liên kết nhanh nhất có thể cho khách hàng di động ngoài trời (điện thoại thông minh, máy tính bảng và máy tính xách tay) và mạng không dây.

View Datasheet AIR-AP1542I-S-K9

AIR-AP1542I-S-K9 cung cấp cho các doanh nghiệp sự linh hoạt để cân bằng vùng phủ sóng không dây mong muốn của họ với nhu cầu triển khai dễ dàng

Cisco AIR-AP1542I-S-K9 Aironet 1540 Dual-band 802.11a/g/n/ac, Wave 2, internal omni antennas

Thông số kỹ thuật Cisco Aironet AIR-AP1542I-S-K9 Access Point:

Item

Specifications

802.11ac Wave 1 and 2 capabilities

-  2 x 2 MIMO with two spatial streams
-  Multiuser and single-user MIMO
-  Maximal ratio combining (MRC)
-  802.11ac beamforming (transmit beamforming)
-  20-, 40-, and 80-MHz channels
-  PHY data rates up to 867 Mbps (80 MHz in 5 GHz)
-  Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
-  802.11 dynamic frequency selection (DFS)
-  Cyclic-shift-diversity (CSD) support

802.11n (and related) capabilities

-  2 x 2 MIMO with two spatial streams
-  MRC
-  20- and 40-MHz channels (40 MHz in 5 GHz)
-  PHY data rates up to 300 Mbps
-  Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
-  802.11 DFS
-  CSD support

Data rates supported

802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps

802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps

802.11n data rates on 2.4 and 5 GHz:

MCS Index

GI = 800 ns

GI = 400 ns



20-MHz Rates (Mbps)

40-MHz Rates
(Mbps)

20-MHz Rates
(Mbps)

40-MHz Rates (Mbps)

0

6.5

13.5

7.2

15

1

13

27

14.4

30

2

19.5

40.5

21.7

45

3

26

54

28.9

60

4

39

81

43.3

90

5

52

108

57.8

120

6

58.5

121.5

65

135

7

65

135

72.2

150

8

13

27

14.4

30

9

26

54

28.9

60

10

39

81

43.3

90

11

58.5

108

57.8

120

12

78

162

86.7

180

13

104

216

115.6

240

14

117

243

130

270

15

130

270

144.4

300



802.11ac Data Rates (5 GHz)

Spatial Streams

MCS

GI = 800 ns

GI = 400 ns





20 MHz

40 MHz

80 MHz

20 MHz

40 MHz

80 MHz

1

0

6.5

13.5

29.3

7.2

15

32.5

1

1

13

27

58.5

14.4

30

65

1

2

19.5

40.5

87.8

21.7

45

97.5

1

3

26

54

117

28.9

60

130

1

4

39

81

175.5

43.3

90

195

1

5

52

108

234

57.8

120

260

1

6

58.5

121.5

263.3

65

135

292.5

1

7

65

135

292.5

72.2

150

325

1

8

78

162

351

86.7

180

390

1

9

180

390

200

433.3

2

0

13

27

58.5

14.4

30

65

2

1

26

54

117

28.9

60

130

2

2

39

81

175.5

43.3

90

195

2

3

52

108

234

57.8

120

260

2

4

78

162

351

86.7

180

390

2

5

104

216

468

115.6

240

520

2

6

117

243

526.5

130

270

585

2

7

130

270

585

144.4

300

650

2

8

156

324

702

173.3

360

780

2

9

360

780

400

866.7

Frequency band and 20- MHz operating channels

2.412 to 2.472 GHz, 13 channels

5.500 to 5.700 GHz, 11 channels

5.745 to 5.825 GHz, 5 channels

Maximum number of nonoverlapping channels

2.4 GHz

802.11b/g:

◦  20 MHz: 3

802.11n:

◦  20 MHz: 3

5 GHz

802.11a:

◦  20 MHz: 27

 802.11n:

◦  20 MHz: 27

◦  40 MHz: 13

802.11ac:

◦  20 MHz: 27

◦  40 MHz: 13

◦  80 MHz: 6

Note: This number varies by regulatory domain. Refer to the product documentation for specific details for each regulatory domain.

Clients Supported

200 per radio / 400 per access point

Receive sensitivity

Transmit Power and Receive Sensitivity





2.4 GHz Radio

5 GHz Radio



Spatial Streams

Total TX Power (dBm)

RX Sensitivity (dBm)

Total TX Power (dBm)

RX Sensitivity (dBm)

802.11/11b

1 Mbps

1

27

-100

NA

NA

11 Mbps

1

27

-92

NA

NA

802.11a/g

6 Mbps

1

27

-95

25

-93

24 Mbps

1

27

-89

25

-87

54 Mbps

1

25

-79

24

-77

802.11n HT20

MCS0

1

27

-95

25

-92

MCS4

1

27

-84

25

-82

MCS7

1

25

-76

23

-74

MCS8

2

27

-94

25

-91

MCS12

2

27

-82

25

-80

MCS15

2

25

-74

23

-72

802.11n HT40

MCS0

1





25

-90

MCS4

1





25

-79

MCS7

1





23

-72

MCS8

2





25

-89

MCS12

2





25

-77

MCS15

2





23

-70

802.11ac VHT20

MCS0

1





25

-92

MCS4

1





24

-82

MCS7

1





21

-74

MCS8

1





20

-70

MCS0

2





25

-91

MCS4

2





24

-80

MCS7

2





21

-72

MCS8

2





20

-68

802.11ac VHT40

MCS0

1





25

-90

MCS4

1





23

-79

MCS7

1





20

-72

MCS8

1





19

-68

MCS9

1





19

-66

MCS0

2





25

-89

MCS4

2





23

-77

MCS7

2





20

-70

MCS8

2





19

-66

MCS9

2





19

-64

802.11ac VHT80

MCS0

1





25

-87

MCS4

1





23

-76

MCS7

1





21

-69

MCS8

1





19

-64

MCS9

1





19

-62

MCS0

2





25

-86

MCS4

2





23

-74

MCS7

2





21

-67

MCS8

2





19

-62

MCS9

2





19

-60

Note: The maximum power setting will vary by channel and according to individual country regulations. Refer to the product documentation for specific details.

Maximum conducted transmit power

2.4 GHz: 27 dBm with 2 antennas

5 GHz: 25 dBm with 2 antennas

Note: The maximum power setting will vary by channel and according to individual country regulations. Refer to the product documentation f or specific details.

Interfaces

WAN port 10/100/1000BASE-T Ethernet, autosensing (RJ-45), PoE in
Management console port (RJ-45)
Multicolor LED/Reset button

Uplink options

Ethernet and wireless mesh

Dimensions
(L x W x H)

7.9 x 5.9 x 2.4 in.(20 x 15 x 6.1 cm)

Weight

2.75 lb (1.25 kg)

Environmental

Operating temperature:

–40° to 65°C (–40° to 149°F) ambient air with no solar loading
–40° to 55°C (–40° to 131°F) ambient air with solar loading
Storage temperature: –40° to 85°C (–40° to 185°F)

Humidity:

- 5 – 95% non-condensing

Wind resistance:

Up to 100-mph sustained winds
Up to 165-mph wind gusts

Environmental ratings

IEC 60529 IP67
Icing protection    NEMA 250-2008
Corrosion            NEMA 250-2008 (600 hours)
Solar radiation      EN 60068-2-5 (1200 W/m2)
Vibration              MIL-STD-810

Antennas

-  Integrated dual-band, vertical polarization, omnidirectional antenna radome, 5 dBi (2.4 Ghz) and 5dBi (5.8 GHz)**

** This model can be mounted horizontally on a wall or pole, to provide omni-directional coverage; or can be mounted vertically to provide semi-omni coverage.

Powering options

802.3af, 802.3at
Cisco power injectors:

◦  AIR-PWRINJ-60RGD1= (outdoor rated, 60W, with NEMA 5-15 AC plug)

◦  AIR-PWRINJ-60RGD2= (outdoor rated, 60W, unterminated AC cable)

◦  AIR-PWRINJ5= (indoor, 802.3af)

◦  AIR-PWRINJ6= (indoor, 802.3at)

Power consumption

13W

Compliance

Safety

UL60950, 2nd Edition
CAN/CSA-C22.2 No. 60950, 2nd Edition
IEC 60950, 2nd Edition
EN 60950, 2nd Edition

Immunity

<= 5 mJ f or 6kV/3kA @ 8/20 ms waveform
ANSI/IEEE C62.41
EN61000-4-5 Lev el 4 AC Surge Immunity
EN61000-4-4 Lev el 4 Electrical Fast Transient Burst Immunity
EN61000-4-3 Lev el 4 EMC Field Immunity
EN61000-4-2 Lev el 2 ESD Immunity
EN60950 Overvoltage Category IV

Radio Approvals

FCC Part 15.247, 15.407
FCC Bulletin OET-65C
RSS-210
RSS-102
AS/NZS 4268.2003
ARIB-STD 66 (Japan)
ARIB-STD T71 (Japan)
EN 300 328
EN 301 893

EMI and Susceptibility

FCC part 15.107, 15.109
ICES-003
EN 301 489-1, -17

Security

-  Wireless bridging/mesh
-  X.509 digital certificates
-  MAC address authentication
-  Advanced Encryption Standard (AES)

Wireless Access

802.11i, Wi-Fi Protected Access 2 (WPA2), and WPA
802.1X authentication, including Extensible Authentication Protocol (EAP) and Protected EAP (EAP -PEAP), EAP Transport Layer Security (EAP-TLS), EAP-Tunneled TLS (EAP-TTLS), EAP-Subscriber Identity Module (EAP-SIM), and Cisco LEAP
VPN pass-through
IP Security (IPsec)
Layer 2 Tunneling Protocol (L2TP)
MAC address filtering
