| Authentication and security |
- Wi-Fi Protected Access 2 (WPA2) WPA3 is coming in a post–Frame Check Sequence (FCS) release
- 802.1X, RADIUS Authentication, Authorization, and Accounting (AAA)
- Segmentation via VLANs (up to 16)
- 802.11r and 802.11i
- Guest network can also authenticate against: Google and Facebook
|
| Maximum clients |
- Maximum number of associated wireless clients: 200 per Wi-Fi radio, for a total of 400 clients per access point, or 1000 in a system |
| Maximum # of Access Points |
- 50
- Recommended up to 25
|
| Max # of Mesh Extenders |
- Maximum number of associated Cisco Business mesh extenders: 25 per Access Point, up to 8 hops |
| 802.11ac |
- 2x2 single-user/multi-user MIMO with two spatial streams, up to 867 Mbps in 5GHz
- 20-, 40-, and 80-MHz channels
- Dynamic Frequency Selection (DFS)
|
| Ethernet ports |
- Authentication with 802.1X or MAC filtered
- Dynamic VLAN or per port
- Traffic locally switched or tunneled back to Master AP
|
| Data rates supported |
802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates on 2.4 GHz: 6.5 to 300 Mbps (MCS0-MCS15, HT 20/40)
802.11ac data rates on 5 GHz: 6.5 to 867 Mbps (MCS0-MCS9) |
| Available transmit power settings |
2.4 GHz
- Up to 20 dBm
5 GHz
- Up to 20 dBm
|
| Integrated antennas |
- 2.4 GHz, gain 2 dBi
- 5 GHz, gain 4 dBi
|
| Interfaces |
- 1x Gigabit Ethernet (10/100/1000BASE-T autosensing), Power over Ethernet (PoE)
- RJ-45 console port (not functional)
|
| Indicators |
- Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors |
| Dimensions (W x L x H) |
- Access point (without mounting bracket): 6 x 6 x 1.3 in. (150.8 x 150.8 x 33 mm) |
| Weight |
- Access point without mounting bracket or any other accessories: 14 oz (400 g) |
| Environmental |
Operating
- Temperature: 32° to 104°F (0° to 50°C)
- Humidity: 10% to 90% (noncondensing)
- Maximum altitude: 9843 ft (3000 m) at 40°C
Nonoperating (storage and transportation)
- Temperature: –22° to 158°F (-30° to 70°C)
- Humidity: 10% to 90% (noncondensing)
- Maximum altitude: 15,000 ft (4500 m) at 25°C
|
| System |
- 1 GB DRAM, 256 MB flash
- 710-MHz quad core processor
|
| Powering options |
- 802.3af/at Ethernet switch; a Cisco Business switch with PoE is recommended
- Optional Cisco Business PoE injector
|
| Power draw |
- 8.3W (maximum, on PoE) |
| Mounting and physical security |
Included with the access point:
- Mounting bracket
- Torx security screw
- Ceiling rail mount clip
|
| Warranty |
Cisco Business limited lifetime hardware warranty
Free software updates, no service contract required
|
