Components
|
Fully integrated unit including:
- Codec
- Camera
- Display
- Microphones and loudspeaker
Included: Screen cleaning cloth, Ethernet cable (2.9m), and power supply
|
|
Display
|
- 14-inch LCD monitor
- Resolution: 1920 x 1080 (16:9)
- AHVA display technology contrast ratio: 700:1 (typical)
- Viewing angle: +/–178 degrees (typical)
- Response time: 25 ms
- Brightness: 300 cd/m2 (5 points average)
- 10-point multi touch surface |
|
Supported PC input resolutions
|
Up to 1080p
|
|
Ergonomic design
|
- The stand is retractable in the upright position for easy transportation
- You can tilt the screen from an angle of 5° to 70° from the vertical
- You can tilt the camera from an angle of –5° to 70° from the display
- The main I/O panel includes a flip cover to obscure connections |
|
Audio
|
- Audio system playback:
+ Frequency range: 100 Hz to 15 kHz, +/–3 dB *
+ Maximum level: 90 dB at 1w/1m *
- The video conferencing system optimally tuned and located analog omnidirectional microphone
Specification based on direct measurement of the acoustic sub-system
|
|
Front camera
|
- 63° horizontal field of view
- 38° vertical field of view
- Resolution: 1080p30
- F 2.2
- Privacy shutter |
|
Processor
|
TI OMAP 4470 1.5-GHz dual-core ARM Cortex-A9 processor
|
|
Storage
|
8-GB eMMC NAND flash memory (embedded multimedia card; nonvolatile)
|
|
Memory
|
2-GB RAM; Low Power Double Data Rate Synchronous Dynamic Random-Access Memory (LPDDR2 SDRAM)
|
|
Ports and slots
|
- High-Definition Multimedia Interface (HDMI) type A port for PC or Mac video input
- HDMI type A port output (not in use)
- High-speed USB 2.0 ports:
+ Three standard type A ports enable wired or wireless (dongle) headsets and handset use
+ Side-mounted USB port that provides high-current (2A) charging; the two rear-mounted ports each provide 500 mA charging
+ One Micro-B USB port (serial port for diagnostic and service use)
- Micro Secure Digital Standard Capacity (HDSC) slot for nonvolatile storage of applications or file expansion up to 32 GB (Standard-Definition [SD] card speed Class 4 or later recommended)
- One 3.5-mm analog headphone and headset jack |
|
Physical buttons
|
- Volume up/down
- Mute |
|
Visual indicator
|
- Cap-sense Audio Volume up/down
- Cap-sense Audio Mute
- Power/Reset/Sleep button |
|
Physical dimensions
(H x W x D)
|
14.84 x 13.91 x 2.45 in. (377.1 x 353.1 x 62.3 mm)
|
|
Weight
|
7.5 lb (3.4 kg)
|
|
Power
|
Rated: 3.5A at 12V maximum
Low-power standby mode
|
|
Physical security
|
Compatible with Kensington Security Slot
|
|
Connectivity
|
|
Ethernet
|
- Internal 2-port Cisco Ethernet switch allows for a direct connection to a 10/100/1000BASE-T Ethernet network (IEEE802.3i/802.3u/802.3ab) through an RJ-45 interface with single LAN connectivity for both the phone and a co-located PC
- The system administrator can designate separate VLANs (IEEE 802.1Q) for the PC and phone, providing improved security and reliability of voice and data traffic |
|
Accessories
|
|
Cisco VESA mounting kit
|
This optional mounting kit includes an adapter that replaces the DX70 foot stand and provides mounting points in the two VESA standards (75 x 75 mm and 100 x 100 mm), allowing the use of third-party mounting solutions or the basic flush wall-mount included with the kit
|
|
Temperature Range
|
|
Operating temperature
|
- 32 to 104°F (0 to 40°C) |
|
Relative humidity
|
- 10 to 90% (noncondensing) |
|
Storage temperature
|
- –4 to 140°F (–20 to +60°C) |
|
Approvals and Compliance
|
|
|
- Directive 2014/35/EU (Low-Voltage Directive)
- Directive 2014/30/EU (EMC Directive) – Class A
- Directive 2014/53/EU (Radio Equipment Directive)
- Directive 2011/65/EU (RoHS)
- Directive 2002/96/EC (WEEE)
- NRTL approved (Product Safety)
- FCC CFR 47 Part 15B (EMC) – Class B
- FCC Listed (Radio Equipment) |
