Software compatibility
|
- Cisco Collaboration Endpoint (CE) Software Version 9.4 or later, or Cisco Webex Room OS |
|
Default components in Room Kit Pro
|
- Cisco Webex Codec Pro
- Cisco Webex Quad Camera
- Cisco Touch 10 control unit
- Wall mount for Quad Camera |
|
Optional hardware components
|
- Cisco Table Microphone (with Euroblock plug), wall mount for Codec Pro, rack mount for Codec Pro, various cables |
|
Bandwidth
|
- Up to 6 Mbps point-to-point |
|
Minimum bandwidth for resolution/frame rate
|
- 720p30 from 768 kbps
- 720p60 from 1152 kbps
- 1080p30 from 1472 kbps
- 1080p60 from 2560 kbps |
|
Firewall traversal
|
- Cisco Expressway ™ technology H.460.18, H.460.19 firewall traversal |
|
Video standards
|
- H.264, H.265, H.263 for TANDBERG MXP interop only (check Admin Guide) |
|
Video inputs (6)
|
- 2 HDMI inputs support formats up to maximum 1080p60
- 3 HDMI inputs support formats up to maximum UHD (3840 x 2160) @ 30 fps including HD1080p60
- One 3G-SDI/HD-SDI input supports formats up to maximum 1080p60
- Extended Display Identification Data (EDID)
- Consumer Electronics Control (CEC) 2.0 |
|
Video outputs (3)
|
- 2 HDMI outputs support formats up to 3840 x 2160@60 fps (4Kp60)
- 1 HDMI output supports formats up to 3840 x 2160@30 fps (4Kp30)
- CEC 2.0 |
|
Encode and decode
|
- Video stream: Full HD 1080p60
- Content stream: 4K 2160p15 |
|
Audio standards
|
- G.711, G.722, G.722.1, G.729AB, 64 kbps and 128 kbps MPEG4 AAC-LD mono and stereo, OPUS |
|
Audio features
|
- High quality 20-kHz audio
- 8 separate acoustic echo cancellers
- 8-port audio mixer
- 8 assignable equalizers
- Automatic Gain Control (AGC)
- Automatic noise reduction
- Active lip synchronization |
|
Audio inputs
|
- 8 microphones, 48V phantom powered, Euroblock connector, each with separate echo cancellers and noise reduction; all microphones can be set for balanced line level
- 3 HDMI, digital: stereo PC/DVD input |
|
Audio outputs
|
- 6 balanced line level outputs, Euroblock connector
- 3 HDMI outputs
- HDMI input supports Audio Return Channel (ARC) audio output to Quad Camera
- 1 line out for subwoofer (Quad Camera) |
|
Speakers (Quad Camera)
|
- High-quality speakers
- Frequency response 70 Hz to 20 kHz
- Max output level SPL 90 dB |
|
Speaker tracking (Quad Camera, SpeakerTrack 60)
|
- 6-element microphone array for accurate speaker tracking |
|
Dual stream
|
- H.239 (H.323) dual stream
- BFCP Session Initiation Protocol (SIP) dual stream
- Supports resolutions up to 3840 x 2160p15 fps and 1080p60 |
|
Wireless sharing
|
- Cisco Webex clients (up to 3840 x 2160p5)
- Cisco Intelligent Proximity client (up to 1920 x 1080p5) |
|
Multipoint support
|
- 5-way embedded SIP/H.323 conferencing capability with MultiSite option |
|
MultiSite features (embedded multipoint) (optional upgrade)
|
- Adaptive SIP/H.323 MultiSite:
+ 3-way resolution up to 1080p30 plus content up to 4Kp15
+ 4-way resolution up to 720p30 plus content up to 4Kp15
+ 5-way resolution up to 720p30 plus content up to 4Kp15
- Full individual audio and video transcoding
- H.323, SIP, and VoIP in the same conference
- Support for presentation (H.239, BFCP) from any participant at resolutions up to 3840 x 2160p5
- Best impression (automatic continuous presence layouts)
- Encryption and dual stream from any site |
|
Protocols
|
- H.323
- SIP
- Cisco Webex |
|
Embedded encryption
|
- H.323 and SIP point-to-point
- Standards-based: H.235 v3 and Advanced Encryption Standard (AES)
- Automatic key generation and exchange |
|
IP network features
|
- DNS lookup for service configuration
- Differentiated Services (DiffServ) (Quality of Service [QoS])
- IP-adaptive bandwidth management (including flow control)
- Automatic gatekeeper discovery
- Dynamic playout and lip-sync buffering
- H.245 dual-tone multifrequency (DTMF) tones in H.323
- DTMF tones in SIP, RFC 4733
- Date and time support using Network Time Protocol (NTP)
- Packet loss-based down speeding
- Uniform Resource Identifier (URI) dialing
- TCP/IP
- Dynamic Host Configuration Protocol (DHCP)
- 802.1X network authentication
- 802.1Q Virtual LAN
- 802.1p QoS and class of service
- Cisco Media Assure and ClearPath |
|
Call control
|
- Cisco Collaboration Cloud / Webex
- Cisco Unified Communications Manager (CUCM)
+ Native registration CUCM
+ Requires CUCM Version 10.5.2 or later with device pack for Room Kit Pro
- Cisco TelePresence Video Communication Server (VCS)
+ Native registration with VCS
- Third-party H.323 gatekeepers and standards-based SIP proxies |
|
IPv6 network support
|
- Single call stack support for both H323 and SIP
- Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ
- Support for static IP address assignment, stateless auto-configuration, and DHCP v6 |
|
Security features
|
- Management using HTTPS and SSH
- IP administration password
- Password to access administration features on Touch controller
- Disable IP services
- Network settings protection |
|
Certificate management
|
- Certificate Authority Proxy Function (CAPF) support for additional security
- Manufacturer-Installed Certificates (MIC)
- Locally Significant Certificates (LSC)
- X.509 Digital Certificates (DER encoded binary); both DER and Base-64 formats are acceptable for the client and server certificates; certificates with a key size of 1024, 2048, and 4096 are supported |
|
Network interfaces Codec Pro
|
- 1 Ethernet (RJ-45) 10/100/1000 for LAN
- 2 Ethernet (RJ-45) 10/100/1000 for direct pairing with camera (camera control)
- 2 Ethernet (RJ-45) 10/100/1000 with PoE, 1 dedicated for direct pairing with Touch 10
- Wi-Fi 802.11a/b/g/n/ac 2.4 GHz and 5 GHz for LAN
- 2x2 multiple input and multiple output (MIMO) |
|
Other interfaces
|
- 2x USB A port, USB-B, uUSB, factory reset pinhole |
|
Power supply (Quad Camera)
|
- 100 to 240 VAC, 50/60 Hz, 12V DC input
- Standby 6W, average 20W, peak 70W |
|
Operating temperature and humidity
|
- 0° to 40°C (32° to 104°F) ambient temperature
- 10% to 90% Relative Humidity (RH) |
|
Storage and transport temperature
|
- -20° to 60°C (-4° to 140°F) at RH 10% to 90% (noncondensing) |
|
Dimensions
|
Quad Camera:
- Width: 37.4 in. (95.0 cm)
- Height: 4.7 in. (12.0 cm)
- Depth: 4.0 in. (10.3 cm)
- Weight: 10.6 lb (4.8 kg)
Codec Pro:
- Width: 17.1 in. (43.6 cm)
- Height: 2.6 in. (6.6 cm)
- Depth: 9.1 in. (23.1 cm)
- Weight: 7.3 lb (3.3 kg) |
.png){kind=icon}
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: CS-KITPRO-K9 ?
Thông tin đã được gửi vào mail của anh, anh vui lòng check mail ạ.
Camera tích hợp trong bộ hội họp trực tuyến Cisco Webex CS-KITPRO-K9 có độ phân giải lên đến 5K UltraHD, 15.1 MP image sensor (5184 x 2916)
Bộ hội nghị truyền hình Cisco webex CS-KITPRO-K9 mặc định bao gồm:
- Cisco Webex Codec Pro
- Cisco Webex Quad Camera (a package is also available with the Precision 60 camera)
- Cisco Touch 10 control unit
- Wall mount for Quad Camera
Hãng Cisco không có cable 7m dùng cho bộ hội nghị truyền hình Cisco Webex CS-KITPRO-K9, bạn có thể tham khảo cable CAB-HDMI-MULT-9M (HDMI to DP, mini-DP and HDMI) ạ.
bộ thiết bị hội nghị truyền hình Cisco CS-KITPRO-K9 bao gồm:
- Cisco Webex Codec Pro
- Cisco Webex Quad Camera
- Cisco Touch 10 control unit
- Wall mount for Quad Camera
- Các loại dây nguồn, HDMI và cáp mạng
