Cisco Catalyst IW9167EH-S-CURWB Heavy Duty Access Point.
| Cisco Part Number |
:
|
| List Price |
: $
|
| Giá bán |
:
|
| Bảo hành |
:
|
| Made In |
:
|
| Stock |
:
|
Bộ phát wifi công nghiệp IW9167EH-S-CURWB sử dụng phần mềm Cisco Ultra-Reliable Wireless Backhaul (URWB), cung cấp các kết nối không dây cực kỳ đáng tin cậy để mở rộng mạng khi mà việc đi cáp quang không khả thi hoặc quá tốn kém. Giải pháp cung cấp kết nối với độ trễ nhỏ hơn 10 ms, không mất gói tin, triển khai tương tự như mạng wifi, hoạt động trên phổ tần riêng được cấp phép giúp người dùng toàn quyền kiểm soát mạng. Cisco URWB là giải pháp đã được chứng minh với rất nhiều khách hàng đã và đang sử dụng.
Thông số kỹ thuật.
| Software | Cisco Unified Client Software 17.9.2 or later |
| Supported wireless LAN controllers | Cisco Catalyst 9800 Series Wireless Controllers (physical or virtual) |
| 802.11n version 2.0 (and related) capabilities |
- 4x4 MIMO with four spatial streams in one 2.4 GHz radio and two 5 GHz radios
- Maximal Ratio Combining (MRC)
- 802.11n and 802.11a/g
- 20- and 40-MHz channels
- PHY data rates up to 1.5 Gbps (with 40 MHz on both 5 GHz radios and 20 MHz on the 2.4 GHz radio)
- Packet aggregation: Aggregate MAC Protocol Data Unit (A-MPDU) (transmit and receive), Aggregate MAC Service Data Unit (A-MSDU) (transmit and receive)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
|
| 802.11ac |
- 4x4 downlink MU-MIMO with four spatial streams on both 5 GHz radios
- Maximal Ratio Combining (MRC)
- 802.11ac beamforming
- 20, 40, 80, and 80+80 MHz contiguous channels
- PHY data rates up to 3.4 Gbps (dual 4x4:4SS 80 MHz or 4x4:2SS 80+80 MHz contiguous on 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- Wi-Fi Protected Access (WPA) 3 support
|
| 802.11ax |
- 4x4 uplink/downlink MU-MIMO with four spatial streams in 2.4, 5, and 6 GHz*
- Uplink/downlink OFDMA
- Target Wake Time (TWT)
- BSS coloring
- Maximal Ratio Combining (MRC)
- 802.11ax beamforming
- 20, 40, 80, and 160 MHz channels (5/6 GHz radio)
- 20, 40, 80, 80+80 MHz contiguous (limited to 4x4:2SS) channels (5 GHz radio)
- 20 MHz channels (2.4 GHz radio)
- PHY data rates up to 7.8 Gbps (4x4 160 MHz on 6 GHz, 4x4 80 MHz on 5 GHz, and 4x4 20 MHz on 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- WPA3 support
|
| External antennas |
- Certified for use with antenna gains up to 13 dBi (2.4 GHz) and 19 dBi (5 GHz).
- Cisco offers the industry's broadest selection of antennas, delivering optimal coverage for a variety of deployment scenarios.
- Supports Self-Identifying Antennas (SIA)
|
| Interfaces |
- 1x 100M/1000M/2.5G/5G Multigigabit Ethernet (RJ-45)/M12 X-code autosensing PoE+ in (802.3at/bt), UPOE in
- 1x SFP (copper) 100M/1000M/10G Multigigabit Ethernet /M12 X-code
OR - 1x SFP (fiber) 1G/10G
- Management console port (RJ-45)
- Multicolor system LED
- DC power input (micro-fit/M12 A-code)
- Reset button
|
| Dimensions (W x L x H) | 11.3 x 10.5 x 2.8 in (28.7 x 26.7 x 7.1 cm) |
| Weight | 9.2 lb. (4.2 kg) |
| Input power requirements |
- 802.3at (PoE+), 802.3bt (PoE++), Cisco Universal PoE (Cisco UPOE ®)
- DC power source: 24 to 48 VDC (maximum voltage range: 18 to 60 VDC)
- Cisco power AC-DC power adapter, IW-PWRADPT-MFIT4PN=
- Cisco power injector, IW-PWRINJ-60RGD5GE=
|
