| Radios |
- 2.4 GHz 802.11b/g/n/ax client access radio
- 5 GHz 802.11a/n/ac/ax client access radio
- 2.4 GHz and 5 GHz dual-band WIDS/WIPS, spectrum analysis, and location analytics radio
- 2.4 GHz Bluetooth Low Energy (BLE) radio with Beacon and BLE scanning support
- Concurrent operation of all three radios
- Supported frequency bands (country-specific restrictions apply):
2.412-2.484 GHz
5.150-5.250 GHz (UNII-1)
5.250-5.350 GHz (UNII-2)
5.470-5.600, 5.660-5.725 GHz (UNII-2e)
5.1725-5.825 GHz (UNII-3) |
| Antenna |
- List of compatible antennas: MA-ANT-3-A6/B6/C6/D6/E6/F6
- Individual antenna elements for each radio |
| 802.11ax, 802.11ac Wave 2 & 802.11n Capabilities |
- UL/DL OFDMA, TWT support, BSS coloring
- 4×4 multiple input, multiple output (MIMO) with four spatial streams
- UL/DL SU-MIMO and MU-MIMO support
- Maximal ratio combining (MRC) and beamforming
- 20 and 40 MHz channels (802.11n); 20, 40, and 80 MHz channels (802.11ac Wave 2); 20, 40 and 80 MHz channels (802.11ax)
- Up to 1024 QAM on both 2.4 GHz and 5 GHz bands
- Packet aggregation |
| Power |
- Power over Ethernet: 42.5 - 57 V (802.3at compatible)
- Alternative: 12 V DC input
- Power consumption: 18W max (802.3at)
- Power over Ethernet injector and DC adapter sold separately |
| Interfaces |
- 1x 100/1000/2.5G BASE-T Ethernet (RJ45)
- 1x DC power connector (5.5 mm x 2.5 mm, center positive) |
| Mounting |
- All standard mounting hardware included
- Desktop, ceiling, and wall mount capable
- Ceiling tile rail (9/16, 15/16 or 1 1⁄2” flush or recessed rails), assorted cable junction boxes
- Bubble level on mounting cradle for accurate horizontal wall mounting |
| Physical Security |
- Two security screw options (included) (10 mm long and 2.5 mm diameter and 4.7 mm head)
- Kensington lock hard point
- Concealed mount plate with anti-tamper cable bay |
| Environment |
- Operating temperature: 32 °F to 122 °F (0 °C to 50 °C)
- Humidity: 5 to 95% non-condensing |
| Reliability |
Mean Time Between Failure (MTBF): 1,328,360hrs at +25°C operating temperature |
| Physical Dimensions |
- 9.84” x 4.72” x 1.42” (30.72 cm x 15.62 cm x 3.49 cm), not including desk mount feet or mount plate
- Weight: 850 g |
| Security |
- Integrated Layer 7 firewall with mobile device policy management
- Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal
- Flexible guest access with device isolation
- VLAN tagging (802.1q) and tunneling with IPsec VPN
- PCI compliance reporting
- WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X, WPA3 - Personal**, WPA3 - Enterprise,
WPA3 - Enhanced Open (OWE)
- EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM
- TKIP and AES encryption
- Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration
- Cisco ISE integration for Guest access and BYOD Posturing |
| Quality of Service |
- Advanced Power Save (U-APSD)
- WMM Access Categories with DSCP and 802.1p support
- Layer 7 application traffic identification and shaping |
| Mobility |
- PMK, OKC, & 802.11r for fast Layer 2 roaming
- Distributed or centralized layer 3 roaming |
| Analytics |
- Embedded location analytics reporting and device tracking
- Global L7 traffic analytics reporting per network, per device, & per application |
| LED Indicators |
1 power/booting/firmware upgrade status |
| Regulatory |
Lifetime hardware warranty with advanced replacement included |
