Cisco Meraki MR57-HW Access Point.

Category

Specifications

Radios

2.4 GHz 802.11b/g/n/ax client access radio

5 GHz 802.11a/n/ac/ax client access radio

6GHz 802.11ax client access radio

2.4 GHz, 5 GHz, and 6 GHz tri-band Air Marshal WIDS/WIPS, spectrum analysis, & location analytics radio

2.4 GHz Bluetooth Low Energy (BLE) radio with Beacon and BLE scanning support Concurrent operation of all five radios

Antenna

Integrated omni-directional antennas (4.5 dBi gain at 2.4 GHz, 5.5 dBi gain at 5 GHz and 5.5 dBi gain at 6GHz)

802.11ax, 802.11ac Wave 2 and 802.11n capabilities

DL-OFDMA, TWT support, BSS coloring*

4 x 4 multiple input, multiple output (MIMO) with four spatial streams on 6 GHz

4 x 4 multiple input, multiple output (MIMO) with four spatial streams on 5 GHz

4 x 4 multiple input, multiple output (MIMO) with four spatial streams on 2.4 GHz

SU-MIMO, UL and DL MU-MIMO support

Maximal ratio combining (MRC) & beamforming

20 and 40 MHz channels (802.11n); 20, 40, 80 MHz channels (802.11ac Wave 2);  20, 40, 80 and 160MHz channels (802.11ax)

Up to 1024-QAM on all three - 2.4 GHz, 5 GHz and 6GHz bands

Packet aggregation

Power

Power over Ethernet: 42.5 - 57 V (PoE+ and UPoE compliant)

Alternative 54 V DC input via DC adapter

Power consumption: 30W to 40W (UPoE)

Minimum power requirement: 30W (PoE+, USB is disabled)

Maximum power consumption: 40W

Power over Ethernet injector and DC adapter sold separately.

Interfaces

2x 1000/2.5G/5G BASE-T Ethernet (RJ45)

1x DC power connector (5.5 mm x 2.5 mm, center positive)

Mounting

All standard mounting hardware included (AIR-AP-BRACKET-2)

Desktop, ceiling, and wall mount capable

Ceiling tile rail (9/16, 15/16, or 1 ½” flush or recessed rails), assorted cable junction boxes

Physical Security

Two security screw options (included) (13.5 mm long and 2.5 mm diameter and 5 mm head)

Kensington lock

Concealed mount plate with anti-tamper cable bay

Environment

Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)

Humidity: 5 to 95% non-condensing

Reliability

Mean Time Between Failure (MTBF): 998,440 hrs at +25°C operating temperature

Physical Dimensions

260mm x 260mm x 56mm, not including desk mount feet or mount plate

Weight: 1.7 kg

Security

Integrated Layer 7 firewall with mobile device policy management

Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal

Flexible guest access with device isolation

VLAN tagging (802.1q) and tunneling with IPsec VPN

PCI compliance reporting

WEP*, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X, WPA3 - Personal*, WPA3 - Enterprise*, WPA3 - Enhanced Open (OWE)

EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM

TKIP and AES encryption

Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration

Cisco ISE integration for Guest access and BYOD Posturing

Quality of Service

Advanced Power Save (U-APSD)

WMM Access Categories with DSCP and 802.1p support

Layer 7 application traffic identification and shaping

Mobility

PMK, OKC, & 802.11r for fast Layer 2 roaming

Distributed or centralized layer 3 roaming

Analytics

Embedded location analytics reporting and device tracking

Global L7 traffic analytics reporting per network, per device, & per application

LED Indicators

1 power/booting/firmware upgrade status

Regulatory

RoHS

For additional country-specific regulatory information, please contact Meraki sales

Warranty

Lifetime hardware warranty with advanced replacement included
