| Interfaces Specifications |
| Interfaces |
24 x 1GbE RJ45 |
| Uplink |
Modular |
| 120G Hardware Stack Port |
2 |
| Dedicated Management Interface |
1 |
| PoE/ UPoE Capabilities |
n/a |
| Physical Specifications |
| Dimensions (h x w x d) W/ Default Power Supply |
1.73” x 17.5” x17.7” (4.4 x 44.5 x 44.9cm) |
| Weight |
16.03 lb (7.27 kg) |
| Mount Type |
1U Rack Mount |
| Hot Swap Fans |
Yes, 3x |
| Operating Temperature |
-5°C to 45°C |
| Humidity |
5 to 90% |
| Performance |
| Switching Capacity |
208 Gbps |
| Stacking Bandwidth |
480 Gbps |
| Forwarding rate |
154.76 Mpps |
| Power Options and Specifications |
| Default Power Supply |
MAPWR-350WAC |
| Hot Swap Power Supply |
Yes, Dual |
| Available PoE W/ Primary PS |
n/a |
| Available PoE W/ Secondary PS |
n/a |
| Power Load (idle/max) |
79.2 / 99 W |
| MTBF at 25°C |
314,790 |
| Features |
| Highlights |
• Layer-3
• 40G or 10G modular uplink options on all models
• mGig support
• Dual Dedicated 120G Hardware Stacking Ports
• PoE+ and UPoE Support
• StackPower |
| Management |
• Managed via Cisco Meraki Dashboard
• Zero-touch remote provisioning (no staging needed)
• Basic configuration capability via local management page
• Detailed historical per-port and per-client usage statistics
• Operating System, device, and hostname fingerprinting
• Automatic firmware upgrades with scheduling control
• SNMP and SYSLOG support for integration with other network management solutions* |
| Remote Diagnostics |
• Email, SMS and Mobile push notification alerts1
• Ping, traceroute, cable testing, and link failure detection with alerting
• Remote packet capture
• Dynamic and interactive network discovery and topology
• Combined event and configuration change logs with instant search |
| Stacking |
• Physically stack up to 8 switches with 480 Gbps of stacking bandwidth on all models
• Virtual stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration
• Faster convergence
• StackPower |
| Ethernet Switching Capabilities |
• 802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping)
• 802.1Q VLAN and trunking support for up to 4,094 VLANs (1000 active VLANs with STP enabled)
• Single Instance of 802.1s Multiple Spanning Tree Protocol (interoperable with RSTP, STP, PVST, RPVST)
• STP Enhancements: BPDU guard, Root guard, Loop guard, UDLD • Broadcast storm control
• 802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP) • 802.3ad Link aggregation with up to 8 ports per aggregate, Multichassis aggregates supported on stacked switches
• Port mirroring
• IGMP snooping for multicast filtering
• MAC Forwarding Entries: 32K |
| Layer 3 |
• Static routing, OSFPv2
• Multicast routing (PIM-ASM)
• Warm Spare (VRRP)
• DHCP Server, DHCP Relay |
| Security |
• Integrated multi-factor authentication for Dashboard management
• Role-based access control (RBAC) with granular device and configuration control
• Corporate wide password policy enforcement
• IEEE 802.1X RADIUS and MAB, hybrid authentication and RADIUS server testing
• Single-Host/Multi-Domain/Multi-Host/Multi Authentication
• Port security: Sticky MAC, MAC whitelisting
• DHCP snooping, detection and blocking, Dynamic ARP Inspection
• IPv4 and IPv6 ACLs
• Secure Connect
• Adaptive Policy |
