| Characteristics |
| Ports |
48p 100M/1G Base-T ports + 4p 1/10/25G SPF28,+2p 40/100G QSFP28 |
| Supported speeds |
100M, 1 Gbps on Base-T ports
1, 10, and 25 Gbps on SPF28 ports
40 and 100G Gbps on QSFP28 |
| Port configuration |
48p 100M/1G Base-T ports for downlinks;
1/10/25G for the 4 SFP28 ports
40/100-Gbps for the uplinks |
| Telemetry support |
Yes, SW only |
| CPU |
4 cores |
| System memory |
8 GB |
| Solid-State Disk (SSD) drive |
16GB |
| Shared system buffer |
40 MB |
| Management ports |
2 ports: 1 RJ-45 and 1SFP+ |
| USB ports |
1 |
| RS-232 serial ports |
1 |
| Power supplies (PSU - up to 2) |
400W AC, 400/350W DC |
| Typical power* (AC) |
150W |
| Maximum power* (AC) |
245W |
| Input voltage (AC) |
100 to 240V |
| Input voltage (HVAC) |
200 to 277V |
| Input voltage (DC) |
–40 to –72V DC (minimum and maximum) –48 to –60V DC (nominal) |
| Input voltage (HVDC) |
192 to 400 VDC,
90 to 295 VAC |
| Frequency (AC) |
50 to 60 Hz |
| Fans |
3 |
| Airflow |
Port-side intake and exhaust |
| MTBF (hours) |
474,571 |
| Physical (H x W x D) |
1.72 x 17.3 x 18.5 in. (4.4 x 43.9 x 45.7 cm) |
| Acoustics |
71.6 dBA at 50% fan speed, 75.7 dBA at 70% fan speed, and 81.0 dB at 100% fan speed |
| RoHS compliance |
Yes |
| Performance and scalability specifications |
| Number of Longest Prefix Match (LPM) routes |
Default: 16,000 |
| Number of IP host entries |
Default: 16,000 |
| Number of MAC address entries |
97,000 |
| Number of multicast routes |
Shipping: 8000 |
| Number of Interior Gateway Management Protocol (IGMP) snooping groups |
Shipping: 8000 |
| Number of Access Control List (ACL) entries |
Per slice of the forwarding engine:
3000 ingress
2000 egress |
| Maximum number of VLANs |
4096 |
| Number of Virtual Routing and Forwarding (VRF) instances |
Shipping: 1000 |
| Maximum number of links in a port channel |
32 |
| Maximum number of ECMP paths |
64 |
| Maximum number of ECMP groups |
256 |
| Maximum number of ECMP members |
64,000 |
| Maximum number of port channels |
512 |
| Maximum number of port channels |
4 |
| Number of VLAN’s in Rapid per-VLAN Spanning Tree (RPVST) instances |
3967 |
| Number of Hot-Standby Router Protocol (HSRP) groups |
490 |
| Number of Multiple Spanning Tree (MST) instances |
64 |
| Maximum Number of VXLAN Tunnel Endpoints (VTEPs) |
VXLAN not supported |
| Number of Network Address Translation (NAT) entries |
1023 |
| Environmental properties |
| Operating temperature |
32 to 104°F (0 to 40°C) |
| Nonoperating (storage) temperature |
-40 to 158°F (-40 to 70°C) |
| Humidity |
5 to 85% (noncondensing) |
| Altitude |
0 to 13,123 ft (0 to 4000m) |
| Weight |
| Weight without power supplies or fans |
14.12 lb (6.4 kg) |
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: N9K-C92348GC-X ?
Báo giá thiết bị chuyển mạch Switch Cisco Nexus 9200 series N9K- C92348GC-X with 48p 100M/1G Base-T ports and 4p 1/10/25G SPF28 and 2p 40/100G QSFP28 đã được gửi vào mail nhé bạn
Tiết bị chuyển mạch Switch Cisco Nexus 9200 series N9K- C92348GC-X có thời gian bảo hành 12 tháng nhé bạn
Thiết bị chuyển mạch Switch Cisco Nexus 9200 series N9K- C92348GC-X không hỗ trợ POE nhé bạn
Thiết bị N9K-C92348GC-X Switch Cisco Nexus 9200 series có hỗ trợ VXLAN nhé bạn
Báo giá Switch Cisco Nexus 9200 series N9K- C92348GC-X with 48p 100M/1G Base-T ports and 4p 1/10/25G SPF28 and 2p 40/100G QSFP28 đã được gửi vào mail nhé bạn
