| Specifications |
| Physical |
- 64-port 40/100G QSFP28 ports and 2-port 1/10G SFP+ ports
- Buffer: 40MB
- System memory: 32GB
- SSD: 128GB
- USB: 1 port
- RS-232 serial console ports: 1
- Management ports: 2 (1 x 10/100/1000BASE-T and 1 x 1-Gbps SFP)
- Broadwell-DE CPU: 4 cores
|
| Power and cooling |
- Power: 1200W AC, 930W DC or 1200W HVAC/HVDC
- Input voltage: 100 to 240V * AC or -40V to -72V DC (min‑max), -48V to -60V DC (nominal)
*Supports input voltage of 100–120V for a max output of 800W, 200–240V for a max output of 1200W. PSU redundancy is not supported when used in 100–120V.
- Hot-swappable, dual fan trays with redundant fans
- Frequency: 50 to 60 Hz (AC)
- Efficiency: 90% or greater (20 to 100% load)
- Port-side intake or port-side exhaust options
- Typical power: 429W (AC)
- Maximum power: 1245W (AC)
|
| Environmental |
- Physical (H x W x D): 3.38 x 17.37 x 22.27 in. (8.59 x 44.13 x 56.58 cm)
- Weight: 36.9 lb (16.74kg) with power supplies and fans, 27.4 lb (12.43kg) without power supplies and fans
- Operating temperature: 32 to 104°F (0 to 40°C)
- Nonoperating (storage) temperature: –40 to 158°F
(–40 to 70°C) This is correct
- Humidity: 5 to 85% (noncondensing)
- Altitude: 0 to 13,123 ft (0 to 4000m)
- RoHS compliance: Yes
|
| Acoustics |
- Fan speed at 40%: 76.7 dBA
- Fan speed at 70%: 88.7 dBA
- Fan speed at 100%: 97.4 dBA
|
| MTBF |
- 257,860 hours |
| Performance and Scalability |
| Maximum number of IPv4 Longest Prefix Match (LPM) routes |
- Default: 7000
- LPM heavy : 262,000
|
| Maximum number of IPv4 host entries |
- Default: 96,000
- LPM heavy : 262,000
|
| Maximum number of MAC address entries |
92,000 |
| Number of multicast routes |
- Default: 8000
- LPM heavy: 32,768
|
| Number of Interior Gateway Management Protocol (IGMP) snooping groups |
8000 |
| Number of Access Control List (ACL) entries |
- Per slice of the forwarding engine:
- 4000 ingress
- 2000 egress
- Maximum: 16,000 ingress
- 8000 egress
- Shipping: 14,328 ingress
- 7160 egress
|
| Maximum number of VLANs |
3967 |
| Maximum number of Virtual Routing and Forwarding (VRF) instances |
1000 |
| Maximum number of links in a port channel |
32 |
| Maximum number of Equal-Cost Multipath (ECMP) paths |
64 |
| Maximum number of ECMP groups |
1024 |
| Maximum number of port channels |
64 |
| Number of active SPAN sessions |
4 |
| Maximum number of Rapid Per-VLAN Spanning Tree (RPVST) instances |
3967 |
| Maximum number of Hot-Standby Router Protocol (HSRP) groups |
490 |
| Maximum number of Multiple Spanning Tree (MST) instances |
64 |
| Maximum number of VTEPs |
256 |
| Maximum number of static Network Address Translation (NAT) entries |
1023 |
| Maximum number of dynamic NAT entries |
1023 |
| Maximum number of static twice NAT entries |
768 |
| Maximum number of dynamic twice NAT entries |
1023 |
| Number of Queues |
8 |
| Regulatory Standards Compliance |
| Safety |
- UL 60950-1 Second Edition
- CAN/CSA-C22.2 No. 60950-1 Second Edition
- EN 60950-1 Second Edition
- IEC 60950-1 Second Edition
- AS/NZS 60950-1
- GB4943
|
| EMC: Emissions |
- 47CFR Part 15 (CFR 47) Class A
- AS/NZS CISPR22 Class A
- CISPR22 Class A
- EN55022 Class A
- ICES003 Class A
- VCCI Class A
- EN61000-3-2
- EN61000-3-3
- KN22 Class A
- CNS13438 Class A
|
| EMC: Immunity |
- EN55024
- CISPR24
- EN300386
- KN 61000-4 series
|
| RoHS |
- The product is RoHS-6 compliant with exceptions for leaded-Ball Grid-Array (BGA) balls and lead press-fit connectors |
