Components
|
Fully integrated unit including:
- Codec
- Camera
- Display
- Microphones and loudspeaker
Included: Screen cleaning cloth, HDMI cable (2m), USB cable (2m), Ethernet cable (2.9m), and power supply.
|
|
Display
|
- 23-inch (0.58m) LCD monitor
- Resolution: 1920 x 1080 (16:9)
- High-contrast IPS LED panel
- Contrast ratio: 1000:1 (typical)
- Viewing angle: +/–178 degrees (typical)
- Response time: 5 ms (typical)
- Brightness: 215 cd/m2 (typical)
- Color depth: 16.7 million colors
- Color gamut 72% (of NTSC)
- 10-point multitouch surface |
|
Supported PC input resolutions
|
Up to 1080p
|
|
Ergonomic design
|
- The stand is retractable in the upright position for easy transportation
- You can tilt the screen from an angle of 11° to 50° from the vertical
- You can tilt the camera from an angle of –5° to 70° from the display
- You can lift the connector lid fully and lock it to the back of the unit with magnets |
|
Audio
|
- The loudspeaker is mounted on the front panel and faces you
- Four digital microphones are mounted in two arrays
- Loudspeaker frequency range: 70 Hz to 20 kHz
- Microphones frequency range: 100 Hz to 20 kHz |
|
Front camera
|
- 63° horizontal field of view
- 38° vertical field of view
- Resolution: 1080p30
- F 2.2
- Privacy shutter |
|
Processor
|
TI OMAP 4470 1.5-GHz dual-core ARM Cortex-A9 processor
|
|
Storage
|
8-GB eMMC NAND flash memory (embedded multimedia card; nonvolatile)
|
|
Memory
|
2-GB RAM; Low Power Double Data Rate Synchronous Dynamic Random-Access Memory (LPDDR2 SDRAM)
|
|
Ports and slots
|
- High-Definition Multimedia Interface (HDMI) type A port for PC or Mac video input
- HDMI type A port output (not in use)
- High-speed USB 2.0 ports:
+ Three standard type A ports enable wired or wireless (dongle) headsets and handset use
+ One standard type B port (reserved for future use)
+ One Micro-B USB port with native RS-232 (serial port, intended for service only)
+ Maximum of 500-mA power output at 5V or 2.5W for each USB port |
|
Physical buttons
|
- Volume up/down
- Mute |
|
Visual indicator
|
- Camera LED indicator (incoming calls and camera activation)
- Microphone LED indicator (mute)
- Power button LED indicator (power on, sleeping, message waiting, and error) |
|
Physical dimensions
(H x W x D)
|
20.2 x 22.2 x 3.5 in. (51.2 x 56. 5 x 8.9 cm)
|
|
Weight
|
15.65 lb (7.1 kg)
|
|
Power
|
Rated: 60W maximum
Low-power standby mode
|
|
Physical security
|
Compatible with Kensington Security Slot
|
|
Connectivity
|
|
Ethernet
|
- Internal 2-port Cisco Ethernet switch allows for a direct connection to a 10/100/1000BASE-T Ethernet network (IEEE802.3i/802.3u/802.3ab) through an RJ-45 interface with single LAN connectivity for both the phone and a co-located PC
- The system administrator can designate separate VLANs (IEEE 802.1Q) for the PC and phone, providing improved security and reliability of voice and data traffic |
|
Accessories
|
|
Cisco VESA mounting kit
|
The optional mounting kit includes an adapter that replaces the DX80 foot stand and provides mounting points for 75- x 75-mm and 100- x 100-mm VESA, allowing the use of third-party mounting solutions or the basic flush wall-mount included with the kit
|
|
Temperature Range
|
|
Operating temperature
|
- 32° to 104°F (0° to 40°C) |
|
Relative humidity
|
- 10% to 90% (noncondensing) |
|
Storage temperature
|
- –4° to 140°F (–20° to +60°C) |
|
Approvals and Compliance
|
|
|
- Directive 2014/35/EU (Low-Voltage Directive)
- Directive 2014/30/EU (EMC Directive) – Class A
- Directive 2014/53/EU (Radio Equipment Directive)
- Directive 2011/65/EU (RoHS)
- Directive 2002/96/EC (WEEE)
- NRTL approved (Product Safety)
- FCC CFR 47 Part 15B (EMC) – Class B
- FCC Listed (Radio Equipment) |
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: CP-DX80-K9 ?
Báo giá bộ hội nghị truyền hình Cisco Cisco Webex DX80 đã được gửi vào mail, bạn vui lòng check mail nhé.
phụ kiện đi kèm theo bộ hội nghị truyền hình Cisco webex CP-DX80-K9 bao gồm:
- Codec, Camera, Display, Microphones and loudspeaker, Screen cleaning cloth, HDMI cable (2m), USB cable (2m), Ethernet cable (2.9m), and power supply.
Bộ hội nghị tryền hình Cisco webex CP-DX80-K9 có thể kết nối bộ hội nghị tryền hình Cisco webex CS-KITPRO-P60-K9 thông qua IP WAN (hoặc vpn) nhé, nếu chỉ kết nối 2 điểm cầu không cần mua license ạ.
Hãng Cisco không có cable 7m dùng cho bộ hội nghị truyền hình Cisco Webex CP-DX80-K9, bạn có thể tham khảo cable CAB-HDMI-MULT-9M (HDMI to DP, mini-DP and HDMI) ạ.
Camera tích tích hợp trong bộ hội họp trực tuyến Cisco Webex DX80 CP-DX80-K9 có độ phân giải Full HD 30 hình/giây. Góc rộng 63 độ chiều ngang và 38 độ theo chiều dọc. Tiêu cự F2.2 ạ
