Software compatibility
|
- Cisco Collaboration Endpoint Software Version 9.12 (CE9.12) or later, or Cisco Webex RoomOS |
|
Default components shipped with Webex Desk Pro
|
- Desk Stand
- Stylus with two spare tips
- Network cable 3m/118 in
- USB-C cable (see USB-C BYOD section for details), 1.8 m/70.8 in
- HDMI 2.0 presentation cable 1.5 m/59 in
- Power supply Cisco Desk Pro |
|
Optional hardware components
|
- VESA adapter and wall mount kit
- Replaceable metal speaker grille |
|
Display
|
- 27 inch LCD monitor
- 4k resolution (3840x2160) (16:9)
- High-contrast IPS LED panel
- Contrast ratio: 1000:1 (typical)
- Viewing angle: +/- 89° (typical)
- Brightness 300 cd/m2
- Color depth 1.07B colors
- Color gamut 72% NTSC (100% sRGB) |
|
User interface
|
- Projected capacitive touch
- Optically bonded cover glass
- Multi-touch |
|
Supported PC resolutions
|
- 1080p60, 1440p60, 2160p30 (4K) and 2160p60 (4K) |
|
Camera
|
- 4k Ultra HD camera
- 71° horizontal field of view, 59° vertical field of view
- f/2.0 aperture
- 12 MP image sensor, supports up to 30 fps
- 1/2.8” CMOS, Dual Pixel Technology
- Automatic tilt adjustment
- Automatic focus, brightness and white balance
- Focus distance 20 cm to infinity
- Privacy shutter with LED light |
|
Video standards
|
- H.264 AVC, H.263 compatibility with TANDBERG MXP endpoints |
|
Video inputs
|
- USB-C DisplayPort Alternate Mode up to 3840 x 2160p60 (4kp60)
- HDMI 2.0 type A input supports formats up to 3840 x 2160p60 (4kp60) |
|
Video outputs
|
- HDMI 2.0 type A output supports formats up to 3840 x 2160p60 (4kp60) * |
|
Encode and decode
|
- Video stream: Full HD 1080p30
- Content stream: 4K 2160p15 |
|
Audio standards
|
- G.711, G.722, G.722.1, G.729, AAC-LD, and Opus |
|
Audio features
|
- High-quality 20-kHz audio
- Automatic gain control
- Automatic noise reduction
- Active lip synchronization
- Keyclick suppression |
|
Audio inputs
|
- Internal 8-element microphone array for speech
- USB headset
- Bluetooth headset |
|
Audio outputs (external)
|
- 1 analog headphone output (stereo minijack)
- USB headset
- Bluetooth headset |
|
Loudspeakers (integrated)
|
- High-quality speakers with left, center and right channels enabling directional audio, plus dual woofers in balanced configuration
- Frequency response 60 Hz to 20 kHz
- Amplifier power 4 x 14W |
|
USB-C BYOD
|
Ability to provide the following over one USB-C cable to a connected computer
- Extension of display (3840x2160 @60fps) (Computer must support Alt-mode Display Port)
+ Touch forwarding capabilities on supported operating systems
- Use Desk Pro camera, microphone and speakers with any SW client
- Laptop charging (60W maximum) |
|
Power
|
- Rated: 200W maximum
- Standby power consumption: 15W |
|
Other USB 2.0 ports
|
- Three standard type A ports enable headsets and handset use
- One Micro-B USB port intended for service only |
|
Sensors (experimental)
|
- ALS (Ambient Light Sensor) for automatic brightness adjustment and Control Hub analytics reporting
- 1D Time-of-Flight (LiDAR) for accurate presence detection. Range < 80 centimeters distance and 25 degrees angle
- Temperature (experimental) for Control Hub analytics reporting. Resolution 0.1°C. Accuracy ±1°C
- Humidity (experimental) Control Hub analytics reporting. Resolution 1%. Accuracy ±10% |
|
Operating temperature and humidity
|
- 0°C to 35°C (32°F to 104°F) ambient temperature
- 20% to 90% Relative Humidity (RH) |
|
Storage and transport temperature
|
- -20°C to 60°C (-4°F to 140°F) at RH 10% to 90% (noncondensing) |
|
Dimensions
|
- Width 24.8 in. (63 cm)
- Height 20.1 in. (51 cm)
- Depth 3 in. (7.5 cm)
- Weight 24.4 lb. (11.6 kg)
When packaged
- Width 30.7 in. (78 cm)
- Height 30.7 in. (78 cm)
- Depth 8.6 in. (22 cm)
- Weight 35.2 lb. (16 kg) |
|
Ergonomic design
|
- Tiltable screen
- Flippable cable cover and integrated cable management in Desk Stand |
|
Physical buttons
|
- Power button |
|
Touch buttons
|
- Volume up and down LED indicator
- Microphone mute LED indicator |
|
Visual indicator
|
- Camera On LED indicator (camera activation) |
|
Network
|
- Internal 2-port Cisco Ethernet switch allows for a direct connection to a 10/100/1000BASE-T Ethernet network (IEEE802.3i/802.3u/802.3ab) through an RJ-45 interface with single LAN connectivity for both the phone and a co-located PC
- Wi-Fi 802.11a/b/g/n/ac 2.4 GHz and 5 GHz |
|
Bandwidth requirements
|
- Up to 6 Mbps point-to-point |
|
Call control
|
- Cisco Unified Communications Manager (Unified CM)
+ Native registration with Unified CM
+ Requires Unified CM Version 10.5(2) or later with latest device pack
- Cisco Expressway
+ Native registration with Expressway
- Cisco Webex Service
- Third-party H.323 gatekeepers and standards based SIP proxies |
|
Peripherals supported
|
- USB headset
- Bluetooth headset (wide band)
- Analog headphone output (stereo minijack) |
|
Wireless sharing
|
- Cisco Webex Teams App
- Cisco Webex Meetings App
- Cisco Proximity App |
|
Approvals and compliance
|
- Directive 2014/53/EU (Radio Equipment Directive) for the radio versions
- Directive 2014/30/EU (EMC Directive) for the non-radio versions
- Directive 2014/35/EU (Low-Voltage Directive) for the non-radio versions
- Directive 2011/65/EU (RoHS)
- Directive 2002/96/EU (WEEE)
- NRTL approved (product safety)
- FCC CFR 47 Part 15B (EMC) – Class A
- FCC CFR 47 Part 15C (RF)
- FCC CFR 47 Part 15E (RF)
- FCC Listed (radio equipment) |
|
Multipoint support
|
- 5-way embedded SIP/H.323 conferencing capability with MultiSite option |
|
MultiSite features (embedded multipoint) (optional upgrade)
|
- Adaptive SIP/H.323 MultiSite:
+ 3-way, resolution up to 1080 at 30 fps plus content up to 4K at 15 fps
+ 4-way, resolution up to 720 at 30 fps plus content up to 4K at 15 fps
+ 5-way, resolution up to 720 at 30 fps plus content up to 4K at 10 fps
- Full individual audio and video transcoding
- H.323, SIP, and Audio only in the same conference
- Best impression (automatic continuous presence layouts)
- Encryption and dual stream from any site |
Bạn đang cần tư vấn về sản phẩm: CS-DESKPRO-K9 ?
Bộ họp trực tuyến Cisco CS-DESKPRO-K9 có thể kết nối bộ họp trực tuyến Cisco Webex Room CS-ROOM70S-K9 qua WAN nhé bạn, kết nối 2 điểm cầu không cần mua license ạ.
Hãng Cisco không có sợi cable HDMI dài 7m, bạn có thể tham khảo cable CAB-HDMI-MULT-9M (HDMI to DP, mini-DP and HDMI, dài 9m) phù hợp với bộ thiết bị hội thảo Cisco webex CS-DESKPRO-K9 nhé.
Chị hoàn toàn có thể sử dụng 2 bộ Cisco webex CS-DESKPRO-K9 cho 2 điểm chi nhánh chị nhé
Bạn có thể kết nối để họp trực tuyến giữa bộ hội nghị truyền hình Cisco CS-DESKPRO-K9 và bộ hội nghị truyền hình Cisco CS-KITPRO-P60-K9 thông qua IP WAN (hoặc vpn) nhé, kết nối giữa 2 điểm cầu không cần license.
Camera tích hợp trên bộ hội nghị truyền hình Cisco webex CS-DESKPRO-K9 là 12MP bạn nhé
