CISCO1905/K9 Cisco 1905 Integrated Services Router

Router Cisco CISCO1905/K9 1905 with 2 GE, 1 HWIC-1T, CAB-SS-V35MT, 1 EHWIC slot, 256MB USB Flash (internal), 256MB DRAM, IP Base

Mã sản phẩm: CISCO1905/K9



CHI TIẾT

CISCO1905/K9 Cisco 1905 with 2 GE, 1 HWIC-1T, CAB-SS-V35MT, 1 EHWIC slot, 256MB USB Flash, 256MB DRAM, IP Base

Part Number                  : CISCO1905/K9
Spare Part Number        : CISCO1905/K9=
List Price                        : $995

Bảo hành                        : 12 tháng
Made In                          : Asia

Router Cisco CISCO1905/K9 cung cấp mức độ tích hợp dịch vụ ngày càng tăng với các dịch vụ dữ liệu, an ninh, không dây và di động, cho hiệu quả cao hơn và tiết kiệm chi phí.

Router Cisco CISCO1905/K9 cho phép triển khai trong môi trường WAN tốc độ cao với các dịch vụ đồng thời cho phép lên đến 15 Mbps.

View Datasheet

Router Cisco CISCO1905/K9 được thiết kế để đáp ứng các yêu cầu kinh doanh của khách hàng,  CISCO1905/K9 với 2 EHWIC slots cung cấp một loạt hiệu suất các giao diện module và các dịch vụ khi mạng của bạn cần phát triển

CISCO1905/K9 Cisco 1905 Integrated Services Router

Thông số kỹ thuật Router Cisco CISCO1905/K9

Services and Slot Density

Embedded hardware-based cryptography acceleration (IPsec + SSL)

Yes

RJ-45 onboard LAN/WAN 10/100/1000 ports

2

Serial port

Slot 0 (integrated HWIC-1T)

EHWIC slots

1

Memory (DDR2 DRAM): Default/maximum

256 MB/512 MB (license upgradable)

USB flash memory (internal): Default/maximum

256 MB/256 MB

External USB flash-memory slots (Type A)

1

USB console port (mini-Type B) (up to 115.2 kbps)

1

Serial console port (up to 115.2 kbps)

1

Serial auxiliary port (up to 115.2 kbps

1

Integrated power supply

AC

Power-supply options

POE (external)

Redundant-power-supply support

No

Power Specifications

AC input voltage

100-240V ~

AC input frequency

47-63 Hz

AC input current range AC power supply (maximum) (amps)

1.5-0.6

AC input surge current

<50A

Typical power (no modules)

25W

Maximum power capacity with AC power supply

60W

Maximum power capacity with PoE power supply (platform only)

70W

Maximum PoE device power capacity with PoE power supply

80W

Physical Specifications

Dimensions (H x W x D)

1.75 x 13.5 x 11.5 in. (4.45 x 34.29 x 29.21 cm)

Rack height

1 rack unit (1RU)

Rack-mount 19 in. (48.3 cm) EIA

Optional

Wall-mount (refer to installation guide for approved orientation)

Yes

Weight: With AC power supply (no modules)

8 lb (3.175 kg)

Weight: With PoE power supply (no modules)

12.8 lb

Maximum weight: Fully configured

14 lb

Airflow

Back to sides

Environmental Specifications

Operating Conditions

Temperature: 5906 ft (1800m) maximum altitude

32-104˚F (0-40˚C)

Temperature: 9843 ft (3000m) maximum altitude

32-77˚F (0-25˚C)

Altitude

10,000 ft (3,000m)

Humidity

10 to 85% relative humidity (RH)

Acoustic: Sound pressure (typical/maximum)

32.9/58.3 dBA

Acoustic: Sound power (typical/maximum)

41.9/67.2 dBA

Transportation and Storage Conditions

Temperature

-40 to 158˚F (-40 to 70˚C)

Humidity

5 to 95% RH

Altitude

15,000 ft (4,570m)

Regulatory Compliance

Safety

UL 60950-1
CAN/CSA C22.2 No. 60950-1
EN 60950-1
AS/NZS 60950-1
IEC 60950-1

EMC

47 CFR, Part 15 ICES-003 Class A, EN55022 Class A, CISPR22 Class A, AS/NZS 3548 Class A, VCCI V-3, EN 300-386, EN 61000 (Immunity), EN 55024, CISPR 24, EN50082-1

Telecom

TIA/EIA/IS-968
CS-03
ANSI T1.101
IEEE 802.3
RTTE Directive

CISCO1905/K9 Series Router Software License

Software License
SL-19-IPB-K9(=) IP Base License (Paper) for Cisco 1900
SL-19-DATA-K9(=) Data License (Paper) for Cisco 1900
SL-19-SEC-K9(=) Security License (Paper) for Cisco 1900
Feature License
FL-SSLVPN10-K9(=) Cisco SSLVPN Feature license PAK (Paper) - 10 users
FL-SSLVPN25-K9(=) Cisco SSLVPN Feature license PAK (Paper) - 25 users
Memory License
FL-1900-256U512MB Cisco 1905 Memory License 256MB to 512MB DRAM Upgrade

CISCO1905/K9 Routers Modules

HWIC-3G-HSPA 3G HWIC (Non-US) HSPA/UMTS 850/1900/2100MHz 4-band EDGE/GPRS
HWIC-4ESW Four port 10/100 Ethernet switch interface card
WIC-1B-S/T-V3 1-Port ISDN WAN Interface Card (dial and leased line)
HWIC-1T 1-Port Serial WAN Interface Card
HWIC-1B-U 1-Port ISDN BRI U High-Speed WAN Interface Card
HWIC-4B-S/T 4-port ISDN BRI High-Speed WAN Interface Card
EHWIC-3G-HSPA-U 3.5G EHWIC (Non-US) HSPA/UMTS 850/900/1900/2100MHz with SMS/GPS
EHWIC-3G-HSPA+7 (Non-US) 3.7G HSPA+ Release 7 EHWIC w/ SMS/GPS
EHWIC-4ESG 4-port single-wide Gb Ethernet switch EHWIC
