| Attributes |
| Memory |
128 GB |
| Ethernet ports (Published Ethernet interfaces compliant per IEEE802.3-2002/2005/2008/2012) |
4x 50GE QSFP28; 8x 10GE SFP+ |
| Transceivers support |
50GE QSFP28 port: 50GE/100GE QSFP28: SR4; 40GE QSFP+: SR4 25GE
SFP28: SR (Adapter required) 10GE SFP+: SR, LR (Adapter required) 10GE SFP+ port: 10GE SFP+: SR, LR |
| Raid support |
Yes |
| Pay-As-You-Grow and Burst Pack License upgrades |
Upgrade option to MPX 15100-50G |
| Performance |
| System throughput, Gbps (L7 throughput) |
80 |
| L7 HTTP requests/sec |
3,900,000 |
| SSL transactions/sec (2K) |
127,000 |
| ECDHE transactions/sec |
55,000 |
| SSL throughput, Gbps |
60 |
| Compression throughput, Gbps |
9.3 |
| ICA Proxy/SSL VPN concurrent users |
20,000 |
| Number of instances included/Maximum number of instances |
N/A |
| Mechanical, environmental, and regulatory |
| Power supplies |
2 |
| Input voltage and frequency ranges |
100-240VAC full range 50-60 Hz |
| Optional DC power supply |
Yes |
| Max power supply |
522W |
| Typical/max power consumption |
300W 1024 BTU/Hr |
| Weight, lbs |
39 |
| Height |
2U |
| Width |
EIA 310-D, IEC 60297, DIN 41494 SC48D rack width with mounting brackets |
| Depth |
72 cm / 28 in |
| Operating temperature |
0-45°C (32-113°F) |
| Allowed relative humidity |
5%-95%, non-condensing |
| Safety certifications |
IEC 60950-1, 2nd Edition, CSA 60950-1, 2nd Edition, UL 60950-1, 2nd Edition, AS/NZS 60950-1 |
| Electromagnetic emissions certifications and susceptibility standard |
US (FCC (Part 15 Class A)), Europe (CE
(EN55032/55024)), Australia (RCM), Japan (VCCI), Korea (KCC), Taiwan (BSMI), China (CCC), India (BIS), Russia
(CUTR) Russia (EAC), Saudi Arabia (CITC), Brazil (Anatel), South Africa (ICASA), Mexico (NOM), Egypt (NTRA), Israel (MoC) |
| Regulatory compliance |
RoHS, WEEE |
| Citrix compliance regulatory model |
2U1P1A |
