MX5108n Dell EMC PowerEdge MX I/O Modules
| DELL Part Number |
:
|
| List Price |
: $
|
| Giá bán |
:
|
| Bảo hành |
:
|
| Made In |
:
|
| Stock |
:
|
Thiết bị chuyển mạch Dell EMC Networking MX5108n Ethernet Switch High performance 25 Gigabit Ethernet switch for single PowerEdge MX7000 chassis.
Thông số kỹ thuật Dell EMC MX5108n
| Product |
Description |
| Physical |
- Full featured 25/100GE switch in PowerEdge MX Fabric A/B I/O sled form factor
- 1 USB 2.0 type A storage port
- 1 micro USB type B port for console/management port access
- Indicators:
- Power/Health LED
- ID LED
- Link/activity LEDs
- Size: 1.18”h x 17.11”w x 10.94”d
- Weight: 7.72lbs (3.5kg)
- Max. power consumption: 65 Watts
- Typ. power consumption: 63.3 Watts
- Max. operating specifications:
- Standard Operating Temperature 10°C to 35°C (50°F to 95°F)
- Operating Relative Humidity 5% to 85%, noncondensing
- Max. non-operating specifications:
- Storage temperature: -40°C to 65°C (-40°F to 149°F)
- Storage humidity: 5 to 95% (RH), noncondensing
- Expanded Operating Temperature, Continuous
- Operation: 5°C to 40°C at 5% to 85% RH with 29°C dew point
- Note: Outside the standard operating temperature, the system can operate continuously in temperatures as low as 5°C and as high as 40C.
- For temperature between 35°C to 40°C, de-rate maximum allowable temperature by 1°C per 175m above 950m (1°F per 319 ft)
|
| Redundancy |
Redundant Power and Cooling provided by Dell EMC PowerEdge MX7000 Chassis |
| Performance |
- Switching I/O bandwidth: 960 Gbps
- Forwarding capacity: 363 Mpps
- Latency: Sub 800ns
- MAC addresses: 273K
- IPv4 Unicast routes: 200K
- IPv6 Unicast routes: 160K
- ARP entries: 48K
- Layer 2 VLANs: 4K
- Layer 3 VLANs: 500
- MST: 32instances
- PVST+: 128 instances
- LAG: 128 groups, 16 members per LAG group
- ACL Entries-Layer 2 Egress: 1000
- ACL Entries-Layer 2 Ingress: 3000
- ACL Entries-IPv4 Egress: 3000
- ACL Entries-IPv4 Ingress: 3000
- ACL Entries-IPv6 Egress: 500
- ACL Entries-IPv6 Ingress: 1500
- iSCSI Number of sessions: 256
- Jumbo Frames: 9K
|
| Optics |
- Transceiver, 100GbE, SR4 QSFP28
- Transceiver, 100GbE, LR4 QSFP28
- Transceiver, 100GbE, CWDM4 2Km QSFP28
- Transceiver, 100GbE, PSM4 500m QSFP28
- Transceiver, 40GbE, SR4 optic QSFP+
- Transceiver, 40GbE, eSR4 optic QSFP+
- Transceiver, 40GbE, LR4 optic QSFP+
- Transceiver, 40GbE, BIDI optic QSFP+
- Transceiver, 40GbE, PSM4 10Km QSFP+
- Transceiver, 40GbE, LM4 Duplex QSFP+
- Transceiver, 40GbE, SM4 Duplex QSFP+
|
| Cables |
- 100GbE, QSFP28 to QSFP28, active optical, passive DAC
- 100GbE, QSFP28 to 4xSFP28 (4x10/25GbE), active optical, passive DAC
- 100GbE, MTP to MTP optical
- 100GbE, MTP to 4xLC optical breakout
- 40GbE, QSFP+ to QSFP+, active optical & passive DAC
- 40GbE, QSFP+ to 4xSFP+ (4x10GbE), active optical & passive DAC
|
| Software |
- Dell EMC OS10 Enterprise
- Edition Select third-party operating system offerings (future)
|
.png){kind=icon}
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: MX5108n ?
Moduele chuyển mạch Dell EMC PowerEdge MX5108n có tính năng ghép kênh với tối đa 128 kênh, 16 cổng mỗi kênh nhé bạn.
