S4148U-ON Dell EMC PowerSwitch 24x Unified SFP+, 24x 10GbE SFP+, 2x QSFP+, 4x Unified QSFP28

Thiết bị chuyển mạch Core Dell EMC Networking S4148U-ON Switch S Series with 24x Unified port SFP+, 24x 10GbE SFP+, 2x QSFP+, 4x Unified port QSFP28, 2x AC PSU, 4x Fan module.

✓ Mã sản phẩm: S4148U-ON
✓ Tình trạng: Còn Hàng
Check Giá List
S4148U-ON Datasheet

Cam Kết Bán Hàng

✓ Sản Phẩm Chính Hãng 100% Đầy Đủ CO/CQ

✓ Giá Cạnh Tranh Rẻ Nhất Thị Trường

✓ Ưu Đãi Lớn Cho Đại Lý Và Dự Án

✓ Bảo Hành, Đổi Trả Nhanh Chóng

✓ Giao Hàng Trên Toàn Quốc

✓ Hỗ Trợ Kỹ Thuật Chuyên Nghiệp, Nhiệt Tình

✓ Chăm Sóc Khách Hàng Trước, Trong và Sau Khi Mua Hàng Tận Tâm.

CNTTShop.vn - 19 năm Uy tín cung cấp Thiết bị mạng & Dịch vụ Mạng trên toàn quốc.

NTT03, Thống Nhất Complex, Thanh Xuân, Hà Nội. Số 31B, Đường 1, Phường An Phú, Quận 2 (Thủ Đức), TP HCM.

Dell EMC PowerSwitch S4148U-ON

DELL Part Number
List Price
: $
Giá bán
Bảo hành
Made In
Stock

Thiết bị chuyển mạch Core Dell EMC Networking S4148U-ON Switch S Series with 24x Unified port SFP+, 24x 10GbE SFP+, 2x QSFP+, 4x Unified port QSFP28, 2x AC PSU, 4x Fan module.

Dell EMC Networking S4148U-ON

Thông số kỹ thuật Dell EMC S4148U-ON

Product Description
S4148U-ON
  • S4148U, 24x Unified port SFP+, 24x 10GbE SFP+, 2x QSFP+, 4x Unified port QSFP28, 2x AC PSU, 4x Fan module, I/O Panel to PSU Airflow
  • S4148U, 24x Unified port SFP+, 24x 10GbE SFP+, 2x QSFP+, 4x Unified port QSFP28, 2x AC PSU, 4x Fan module, PSU to I/O Panel Airflow
Performance
Switching capacity (full duplex)
  • 1.76 Tbps
Forwarding Capacity (Mpps)
  • 1320
Buffer size
  • 12MB
Latency (microseconds)
  • <800 n sec
Ports
FC8/FC16 24 unified SFP+/SFP28
FC8/FC16/FC32 unified QSFP28
Max FC 8G/16G ports (oversubscribed) 40
Max FC 16G line rate 28
Max FC 32G ports (oversubscribed) 16
Max FC 32G line rate 8
1/10GBase-T

NA

10GbE 72
25GbE 16
40GbE (QSFP+) 6
50GbE 8
100GbE 4
Expansion module slots (Modules support speed indicated) -
Power and cooling
Max. power consumption (W) 460 (max)/300 (normal)
Power options AC or DC
Redundant power supplies 2
Redundant power supplies Normal or reverse air flow
Features
Stacking Not currently available
Operating system Dell EMC OS10 and select 3rd party OS
Industry-standard CLI Dell EMC networking and several 3rd party OS
iSCSI optimization storage features   iSCSI optimization, FSB, NPIV Proxy gateway, F_Port, FCoE/ FC hosts, FC zoning
Max L2 VLANs and L3 VLANs 500 L3 VLANs
Max MAC entries 272K
Link aggregation (groups/Members) 32 links per group, 128 groups
Max routes (IPv4/IPv6) 200K/130K
Jumbo frames (Bytes) 9,416
IPv4 routing RIP, OSPF, BGP
IPv6 routing OSPFv3
Multicast routing In process

Bạn đang cần tư vấn về sản phẩm: S4148U-ON ?

Có 1 bình luận:
T
Tính
Thiết bị mạng S4148U-ON Dell EMC PowerSwitch 24x Unified SFP+, 24x 10GbE SFP+, 2x QSFP+, 4x Unified QSFP28 có hỗ trợ BGP không admin?
V
Quang VinhQuản trị viên

Thiết bị chuyển mạch Dell EMC PowerSwitch S4148U-ON không hỗ trợ BGP nhé bạn.
