Phân phối FG-100D Firewall FortiGate 100D 20x GE RJ45 ports (1 DMZ, 1 Mgmt, 2 HA, 16 RJ45 ports), 2 shared media pairs (2 GE RJ45, 2 GE SFP), 32 GB giá tốt
Mã sản phẩm: FG-100D
Firewall Fortinet FortiGate FG-100D cung cấp khả năng tường lửa thế hệ mới cho các doanh nghiệp vừa và lớn, với sự linh hoạt được triển khai tại các doanh nghiệp hoặc các chi nhánh. Firewall FortiGate FG-100D giúp chống lại các mối đe dọa trên mạng với bộ xử lý bảo mật cung cấp hiệu suất cao, hiệu quả bảo mật và khả năng hiển thị chi tiết các vấn đề bảo mật.
Công nghệ bảo mật được đánh giá cao nhất bởi NSS Labs, Virus Bulletin và AV Comparatives
Bảo vệ mối đe dọa cao nhất và hiệu năng kiểm tra SSL
Khả năng bảo mật đa lớp để giảm sự phức tạpFG-100D Firewall Fortinet FortiGate 100D 20 GE RJ45 ports (1 DMZ, 1 Mgmt, 2 HA, 16 RJ45 ports), 2 shared media pairs (2x GE RJ45, 2x GE SFP), 32 GB storage, Max managed FortiAPs (Total/Tunnel) 64/32
FortiGate mid-range firewalls include
Khả năng hiển thị và kiểm soát chi tiết các ứng dụng, người dùng và thiết bị IOT
Chế độ quản lý single-pane-glass với quản lý và báo cáo tập trung
View Datasheet
Thông số kỹ thuật Firewall FortiGate FG-100D
Interfaces and Modules
GE RJ45 Ports
20
GE RJ45 PoE Ports
-
GE SFP or RJ45 Shared Ports
2
GE SFP Ports
-
USB Ports (Client / Server)
1 / 2
Console Port
1
Internal Storage
32 GB
System Performance and Capacity
Firewall Throughput
2.5 Gbps
Firewall Latency (64 byte, UDP)
37 μs
Firewall Throughput (Packet per Second)
300 Kpps
Concurrent Sessions (TCP)
2 Million
New Sessions/Sec (TCP)
22,000
Firewall Policies
10,000
IPsec VPN Throughput (512 byte)
380 Mbps
Gateway-to-Gateway IPsec VPN Tunnels
2000
Client-to-Gateway IPsec VPN Tunnels
10,000
SSL-VPN Throughput
300 Mbps
Concurrent SSL-VPN Users
300
SSL Inspection Throughput (IPS, HTTP)
190 Mbps
Application Control Throughput (HTTP 64K)
500 Mbps
CAPWAP Throughput (1444 byte, UDP)
1.2 Gbps
Virtual Domains (Default / Maximum)
10 / 10
Maximum Number of Switches Supported
24
Maximum Number of FortiAPs (Total / Tunnel Mode)
64 / 32
Maximum Number of FortiTokens
1,000
Maximum Number of Registered FortiClients
600
High Availability Configurations
Active / Active, Active / Passive, Clustering
System Performance — Optimal Traffic Mix
IPS Throughput
950 Mbps
System Performance — Enterprise Traffic Mix
IPS Throughput
400 Mbps
NGFW Throughput
250 Mbps
Threat Protection Throughput
200 Mbps
Dimensions and Power
Height x Width x Length (inches)
1.75 x 17.01 x 11.73
Height x Width x Length (mm)
44 x 432 x 298
Weight
9.5 lbs (4.3 kg)
Form Factor
Rack Mount, 1 RU
Environment
Power Required
100–240V AC, 60–50 Hz
Maximum Current
110 V / 3 A, 220 V / 1.5 A
Total Available PoE Power Budget
-
Power Consumption (Average / Maximum)
52.6 W / 63.1 W
Heat Dissipation
215.3 BTU/h
Operating Temperature
32–104°F (0–40°C)
Storage Temperature
-31–158°F (-35–70°C)
Humidity
10–90% non-condensing
Noise Level
46 dBA
Operating Altitude
Up to 7,400 ft (2,250 m)
Compliance
FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6
Các loại module quang sử dụng cho Firewall FortiGate FG-100D
1 GE SFP LX transceiver module
FG-TRAN-LX
1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots
1 GE SFP RJ45 transceiver module
FG-TRAN-GC
1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots
1 GE SFP SX transceiver module
FG-TRAN-SX
1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots
