| Interfaces and Modules |
| Hardware Accelerated 10 GE SFP+ Slots |
10 + 2 bypass |
| Hardware Accelerated GE RJ45 Ports |
32 |
| GE RJ45 Management Ports/ HA Ports |
2 |
| USB Ports |
1 |
| Console Port |
1 |
| Internal Storage |
1x 480 GB |
| Included Transceivers |
2x SFP+ (SR 10 GE) |
| System Performance and Capacity |
| Firewall Throughput (1518 / 512 / 64 byte, UDP) |
150 / 150 / 95 Gbps |
| Firewall Latency (64 byte, UDP) |
2 μs |
| Firewall Throughput (Packet per Second) |
145.5 Mpps |
| Concurrent Sessions (TCP) |
20 Million |
| New Sessions/Sec (TCP) |
500,000 |
| Firewall Policies |
100,000 |
| IPsec VPN Throughput (512 byte) |
95 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
100,000 |
| Client-to-Gateway IPsec VPN Tunnels |
50,000 |
| SSL-VPN Throughput |
6 Gbps |
| Concurrent SSL-VPN Users |
10,000 |
| SSL Inspection Throughput (IPS, HTTP) |
25 / 11.5 Gbps |
| Application Control Throughput (HTTP 64K) |
20 Gbps |
| CAPWAP Throughput (1444 byte, UDP) |
21 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 500 |
| Maximum Number of Switches Supported |
128 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
4,096 / 1,024 |
| Maximum Number of FortiTokens |
5,000 |
| Maximum Number of Registered FortiClients |
50,000 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
| System Performance — Optimal Traffic Mix |
| IPS Throughput |
25 Gbps |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput |
11.5 Gbps |
| NGFW Throughput |
9 Gbps |
| Threat Protection Throughput |
5.4 Gbps |
| Dimensions and Power |
| Height x Width x Length (inches) |
3.5 x 17.4 x 21.9 |
| Height x Width x Length (mm) |
88 x 442 x 555 |
| Weight |
38.5 lbs (17.6 kg) |
| Form Factor |
2 RU |
| AC Power Supply |
100–240V AC, 50–60 Hz |
| DC Power Supply |
- |
