| Interfaces and Modules |
| GE RJ45 WAN Interfaces |
2 |
| GE RJ45 LAN Interfaces |
52 |
| GE RJ45 PoE LAN Interfaces |
32 |
| GE SFP DMZ Interfaces |
4 |
| USB (Client / Server) |
1 / 1 |
| Console (RJ45) |
1 |
| Local Storage |
64 GB |
| Included Transceivers |
- |
| System Performance and Capacity |
| Firewall Throughput (1518 / 512 / 64 byte, UDP) |
4 / 4 / 4 Gbps |
| Firewall Latency (64 byte, UDP) |
2 μs |
| Firewall Throughput (Packet per Second) |
6 Mpps |
| Concurrent Sessions (TCP) |
2 Million |
| New Sessions/Sec (TCP) |
77,000 |
| Firewall Policies |
10,000 |
| IPsec VPN Throughput (512 byte) |
1.3 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2000 |
| Client-to-Gateway IPsec VPN Tunnels |
10,000 |
| SSL-VPN Throughput |
400 Mbps |
| Concurrent SSL-VPN Users |
300 |
| SSL Inspection Throughput (IPS, HTTP) |
340 Mbps |
| Application Control Throughput (HTTP 64K) |
1.5 Gbps |
| CAPWAP Throughput (1444 byte, UDP) |
1.8 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of Switches Supported |
24 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
128 / 64 |
| Maximum Number of FortiTokens |
1,000 |
| Maximum Number of Registered FortiClients |
600 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
| System Performance — Optimal Traffic Mix |
| IPS Throughput |
2.1 Gbps |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput |
420 Mbps |
| NGFW Throughput |
330 Mbps |
| Threat Protection Throughput |
310 Mbps |
| Dimensions and Power |
| Height x Width x Length (inches) |
3.5 x 17.2 x 11.8 |
| Height x Width x Length (mm) |
89 x 437 x 300 |
| Weight |
17.0 lbs (7.6 kg) |
| Form Factor |
2 RU |
| AC Power Supply |
100–240V AC, 60–50 Hz |
| Maximum Current |
110 V / 7 A, 220 V / 3.5 A |
| Power Consumption (Average / Maximum) |
228 / 418 W |
| Heat Dissipation |
1426 BTU/h |
| Total Available PoE Power Budget |
270 W |
