FG-5001C Firewall Fortigate Security blade module for 5000 series

Phân phối FG-5001C Firewall Fortigate Security blade with 2x 10 GE SFP+ ports, 2x GE RJ45 management ports, 128 GB SSD onboard storage giá tốt
Mã sản phẩm: FG-5001C
Tình trạng: Còn hàng
Check Giá List

FG-5001C Firewall Fortigate Security blade with 2x 10 GE SFP+ ports, 2x GE RJ45 management ports, 128 GB SSD onboard storage

Module Firewall Fortigate FG-5001C bao gồm hai cổng 10GigE SFP+ (cổng 1 và 2) hỗ trợ các module quang 10G, 2 cổng 10/100/1000BASE-T (MGMT1, MGMT2) được sử dụng để quản lý.

FG-5001C Firewall Fortigate Security blade

Physical Description

Interfaces and Modules
40 GE QSFP+ Ports -
10 GE SFP+ Ports 2
GE RJ45 Ports 2
RJ45 Console Port 1
Included Transceivers 2x 10 GE SFP+ SR
Local Storage 128 GB
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte UDP packets) 40 / 40 / 40 Gbps
Firewall Latency (64 byte, UDP) 4 μs
Firewall Throughput (Packet per Second) 60 Mpps
Concurrent Sessions (TCP) 29.5 Million
New Sessions/Sec (TCP) 210,000
Firewall Policies 200,000
IPsec VPN Throughput (512 byte) 17 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 40,000
Client-to-Gateway IPsec VPN Tunnels 64,000
SSL-VPN Throughput 3.6 Gbps
Concurrent SSL-VPN Users 20,000
SSL Inspection Throughput 12 Gbps
Virtual Domains (Default / Maximum) 10 / 500
Maximum Number of FortiTokens 5,000
Maximum Number of Registered FortiClients 20,000
Maximum Number of FortiAPs (Total / Tunnel) 4,096 / 1,024
Power and Environment
Power Consumption (Average / Maximum) 187 / 225 W
Heat Dissipation (Average) 768 BTU/h
Operating Temperature 32–104°F (0–40°C)
Storage Temperature -13–158°F (-25–70°C)
Humidity 20–90% non-condensing
Compliance
Certifications FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB, ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
NEBS Certified -

Các loại module quang Fortinet sử dụng được cho module FG-5001C

10 GE SFP+ Transceiver Module, Short Range FG-TRAN-SFP+SR 10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Short Range FG-TRAN-XFPSR 10 GE XFP transceiver module, short range for all systems with XFP slots
10 GE SFP+ Transceiver Module, Long Range FG-TRAN-SFP+LR 10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Long Range FG-TRAN-XFPLR 10 GE XFP transceiver module, long range for all systems with XFP slots
10 GE SFP+ Active Direct Attach Cable SP-CABLE-ADASFP+ 10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots

FG-5001C sử dụng được cho các thiết bị sau

BUNDLE ITEMS  SKU  DESCRIPTION
FortiGate 5144C Chassis FG-5144C-DC 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5144C-DC Chassis FG-5144C-DC-NEBS 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves, NEBS certified
FortiGate 5140B Chassis FG-5140B-DC 13U 14-slot chassis with 40G Dual Star fabric backplane, 2 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5060 Chassis FG-5060-DC 5U 6-slot chassis with Dual Star fabric backplane, 2 PEMs, 2 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves
