| Interfaces and Modules |
| Hardware Accelerated 10 GE SFP+ Slots |
2 |
| Hardware Accelerated GE SFP Slots |
8 |
| Hardware Accelerated GE RJ45 Ports |
8 |
| GE RJ45 Management / HA Ports |
2 |
| USB Ports (Client / Server) |
1/2 |
| Console Port |
1 |
| Internal Storage |
120 GB |
| Included Transceivers |
2x SFP (SX 1 GE) |
| System Performance and Capacity |
| Firewall Throughput (1518 / 512 / 64 byte, UDP) |
36 / 36 / 24 Gbps |
| Firewall Latency (64 byte, UDP) |
3 μs |
| Firewall Throughput (Packet per Second) |
36 Mpps |
| Concurrent Sessions (TCP) |
5.5 Million |
| New Sessions/Sec (TCP) |
270,000 |
| Firewall Policies |
10,000 |
| IPsec VPN Throughput (512 byte) |
20 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2000 |
| Client-to-Gateway IPsec VPN Tunnels |
50,000 |
| SSL-VPN Throughput |
2.2 Gbps |
| Concurrent SSL-VPN Users |
5,000 |
| SSL Inspection Throughput (IPS, HTTP) |
3.5 Gbps |
| Application Control Throughput (HTTP 64K) |
9 Gbps |
| CAPWAP Throughput (1444 byte, UDP) |
10 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of Switches Supported |
64 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
1024 / 512 |
| Maximum Number of FortiTokens |
1,000 |
| Maximum Number of Registered FortiClients |
2,000 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
| System Performance — Optimal Traffic Mix |
| IPS Throughput |
7 Gbps |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput |
4 Gbps |
| NGFW Throughput |
3.8 Gbps |
| Threat Protection Throughput |
3 Gbps |
| Dimensions and Power |
| Height x Width x Length (inches) |
1.75 x 17 x 12.68 |
| Height x Width x Length (mm) |
44.45 x 432 x 322 |
| Weight |
11.46 lbs (5.2 kg) |
| Form Factor |
1 RU |
| AC Power Supply |
100–240V AC, 60–50 Hz |
| DC Power Supply |
- |
