| Datasheet Fortigate FG-121G-BDL |
| Specifications |
| License |
FortiCare Premium và FortiGuard UTP |
| Hardware Accelerated GE RJ45 Ports |
16 |
| Hardware Accelerated GE RJ45 Management / HA Ports |
2 |
| Hardware Accelerated GE SFP Slots |
8 |
| Hardware Accelerated 10 GE SFP+ FortiLink Slots (default) |
4 |
| USB Ports |
1 |
| Console (RJ45) Port |
1 |
| Internal Storage |
1 x 480 GB SSD |
| Trusted Platform Module (TPM) |
Yes |
| Bluetooth Low Energy (BLE) |
Yes |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput 2 |
5.3 Gbps |
| NGFW Throughput 2, 4 |
3.1 Gbps |
| Threat Protection Throughput 2, 5 |
2.8 Gbps |
| System Performance and Capacity |
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) |
39 / 39 / 28 Gbps |
| Firewall Latency (64 byte UDP packets) |
3.17 μs |
| Firewall Throughput (Packets Per Second) |
42 Mpps |
| Concurrent Sessions (TCP) |
3 M |
| New Sessions/Second (TCP) |
140 000 |
| Firewall Policies |
10 000 |
| IPsec VPN Throughput (512 byte) 1 |
35 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2000 |
| Client-to-Gateway IPsec VPN Tunnels |
16 000 |
| SSL-VPN Throughput 6 |
1.5 Gbps |
Concurrent SSL-VPN Users
(Recommended Maximum, Tunnel Mode) |
500 |
| SSL Inspection Throughput (IPS, avg. HTTPS) 3 |
3 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) 3 |
2100 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3 |
315 000 |
| Application Control Throughput (HTTP 64K) 2 |
6.7 Gbps |
| CAPWAP Throughput (HTTP 64K) |
35 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of FortiSwitches Supported |
32 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
128 / 64 |
| Maximum Number of FortiTokens |
5000 |
| High Availability Configurations |
Active-Active, Active-Passive, Clustering |
| Dimensions |
| Height x Width x Length (inches) |
1.73 x 17 x 10 |
| Height x Width x Length (mm) |
44 x 432 x 254 |
| Weight |
12.17 lbs (5.52 kg) |
| Form Factor (supports EIA/non-EIA standards) |
Rack Mount, 1RU |
| Operating Environment and Certifications |
| Input Rating |
100-120VAC, 1A-.5A Max, 50-60Hz |
| Power Supply Efficiency Rating |
N/A |
| Redundant Power Supplies |
Yes (Default dual non-swappable AC PSU for 1+1 Redundancy) |
| Maximum Current |
100VAC@1A, 120V@0.5A |
| Power Consumption (Average / Maximum) |
43 W / 47 W |
| Heat Dissipation |
159 BTU/h |
| Operating Temperature |
32°–104°F (0°–40°C) |
| Storage Temperature |
-31°–158°F (-35°–70°C) |
| Humidity |
10%–90% non-condensing |
| Noise Level |
49 dBA |
| Air Flow |
Side to back |
| Operating Altitude |
Up to 10 000 ft (3048 m) |
| Compliance |
FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI |
| Certifications |
USGv6/IPv6 |
