| Application Availability |
| Easy to use and configure Layer 4/7 policy and group management |
- Virtual service definition with inherited persistence, load balancing method and pool members
- Static, default and backup policies and groups
- Layer 4/7 application routing policy
- Layer 4/7 server persistence
- Application load balancing based on round robin, weighted round robin, least connections, shortest response
- Granular real server control including warm up rate limiting and maintenance mode with session ramp down
- Custom Scripting for SLB and Content Rewriting
- Application Templates for Microsoft Applications including SharePoint, Exchange and Windows Remote Desktop
- Application and script health checks
- Clone Traffic Pools
|
| Layer 4 Application Load Balancing |
- TCP, UDP stateless protocols supported
- Round robin, weighted round robin, least connections, shortest response
- L4 dynamic load balancing based on server parameters (CPU, Memory and disk)
- Persistent IP, has IP/port, hash header, persistent cookie, hash cookie, destination IP hash, URI hash, full URI hash, host hash, host domain hash
|
| Layer 7 Application Load Balancing |
- HTTP, HTTPS, HTTP 2.0 GW, FTP, SIP, RDP, RADIUS, MySQL, RTMP, RTSP supported
- L7 content switching – HTTP Host, HTTP Request URL, HTTP Referrer – Source IP Address
- URL Redirect, HTTP request/response rewrite (includes HTTP body)
- Layer 7 DNS load balancing, security, and caching
- 403 Forbidden Rewrite
- Content rewriting
|
| Link Load Balancing |
- Inbound and outbound LLB
- Support for Policy Route and SNAT
- Multiple health check target support
- Configurable intervals, retries and timeouts
- Tunnel Routing
|
| Global Server Load Balancing (GSLB) |
- Global data center DNS-based failover of web applications
- Delivers local and global load balancing between multi-site SSL VPN deployments
- DNSSEC
- DNS Access Control Lists
- GSLB setup wizard
|
| Deployment Modes |
- One arm-mode (Proxy with X-forwarded for support)
- Router mode
- Transparent mode (switch)
- High Availability (AA/AP Failover)
|
| Application Acceleration |
| SSL Offloading and Acceleration |
- Offloads HTTPS and TCPS processing while securing sensitive data
- Full certificate management features
- SSL Forward Proxy for secure traffic inspection
- HTTP/S Mirroring for traffic analysis and reporting
|
| HTTP and TCP Optimization |
- 100x acceleration by off-loading TCP processing
- Connection pooling and multiplexing for HTTP and HTTPS
- HTTP Page Speed-UP for Web Server Optimization and Acceleration
- TCP buffering
- HTTP Compression and Decompression
- HTTP Caching (static and dynamic objects)
- Bandwidth allocation with Quality of Service (QoS)
- HTTP and Layer 4 Rate Limiting
|
| Authentication Offloading |
- Local
- LDAP
- RADIUS
- Kerberos
- SAML 2.0 (SP & Idp)
|
| Networking |
| Networking |
- NAT for maximum flexibility and scalability
- VLAN and port trunking support
- Cisco ACI and OpenStack SDN Support
- NVGRE and VXLAN Support
- BGP and OSPF with Route Health Inspection (RHI)
- IPv6 Support
- IPv6 routing
- IPv6 firewall rules
|
| Security |
| Security |
- FortiGuard Antivirus and FortiSandbox integration
- GEO IP security and logs (subscription required)
- Stateful firewall
- Web Filtering (subscription required)
- IP Reputation (subscription required)
- IPv4 and 6 firewall rules
- Granular policy-based connection limiting
- Syn Cookie Protection
- Connection Limits
|
| Web Application Firewall |
| Web Application Firewall |
- Web Attack Signatures
- XML/JSON/SOAP Validation
- SQLi/XSS Injection Detection
- Bot Detection
- URL/File Protection
- Web application vulnerability scanner
|
| Management |
| Management |
- Single point of cluster management
- CLI Interface for configuration and monitoring
- Secure SSH remote network management
- Secure Web UI access
- RESTful API
- SNMP with private MIBs with threshold-based traps
- Real-time Data Analytics
- Syslog support
- Role-based administration
- In-build diagnostic utilities
- Real-time monitoring graphs
- Built-in reporting
- Getting Started wizard for first-time login
- Virtual Domains (VDOMs)
|
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: FAD-5000F ?
Thông lượng ứng dụng của thiết bị cân bằng tải Fortinet FortiADC FAD-5000F là 200Gbps/150Gbps (L4/L7) nhé bạn.
Layer 4 Throughput của FortiADC FAD-100F là 250 Gbps ạ
Số lượng truy cập tại cùng thời điểm tối đa trên layer 4 của thiết bị FAD-100F là 160.000.000 ạ
Dung lượng memory của FAD-5000F là 192GB ạ
Thiết bị FortiADC FAD-5000F có SSD dung lượng 3.74 TB ạ
