| Hardware Type |
Outdoor AP |
| Number of Radios |
3 + 1 BLE |
| Number of Antennas |
4 dual band WiFi + 1 dual band scanning + 1 single band 2.4 GHz BLE/ZigBee |
| Antenna Type and Peak Gain |
WiFi and scanning radio dual band antenna: 5.5 dBi in 2.4 GHz and 7.2 dBi in 5 GHz band BLE antenna: 5.0 dBi in 2.4 GHz band |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
| Radio 1 Capabilities |
Frequency band: 2.4 GHz Channel width: 20/40MHz Modulation: BPSK, QPSK, 64/256/1024 QAM MIMO Chains: 4x4 Service |
| Radio 2 Capabilities |
Frequency band: 5.0 GHz Channel width: 4x4 20/40/80MHz and 2x2 160 MHz contiguous Modulation: BPSK, QPSK, QAM64, QAM256, and QAM1024 MIMO Chains: 4x4 Service |
| Radio 3 Capabilities |
Frequency bands: 2.4 GHz and 5.0 GHz MIMO Chains: 1x1 Frequency Scanning |
| Maximum Data Rate |
Radio 1: up to 1147 Mbps
Radio 2: up to 2402 Mbps
Radio 3: Frequency scanning only |
| Interfaces |
1x 10/100/1000/2500 Base-T RJ45,1 x 10/100/1000 Base-T RJ45 (802.3af PoE PSE), 1x RS-232 RJ45 Serial Port |
| Power over Ethernet (PoE) |
- 802.3bt PoE default (ships with Passive PoE injector
- Powered by 802.3at PoE - Operate in 4x4 mode with reduced Tx power Radio1/R2 17dBm
- This product only supports PSE functionality when it is powered by PoE injector that ships with the product. |
| Simultaneous SSIDs |
Up to 16 (14 if background scanning enabled) |
| Per Radio Client Capacity |
Up to 512 clients per radio (Radio1 and Radio2) |
| IEEE Standards |
802.11a, 802.11b, 802.11e, 802.11g, 802.11h, 802.11i,802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11w, 802.11ac, 802.11ax (Wi-Fi 6), 802.1Q, 802.1X, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3bt, 802.3bz |
