| Hardware |
| Hardware Type |
Indoor Smart AP |
| Number of Radios |
2 |
| Number of Antennas |
4 Internal plus 1 Bluetooth |
| Peak Antenna Gain |
4 dBi for 2.4 GHz, 5 dBi for 5 GHz |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
| Frequency of Radio 1 |
2.4 GHz b/g/n (2x2:2 stream), 20/40 Mhz (64 QAM) |
| Frequency of Radio 2 |
5 GHz a/n/ac (2x2:2 stream), 20/40/80 Mhz (256 QAM), MU-MIMO 2 simultanous devices |
| Bluetooth Low Energy (BT/BLE) Radio |
Bluetooth scanning and iBeacon advertisement @ 4 dBm maximum TX power |
| Throughput |
Radio 1: up to 300 Mbps, Radio 2: up to 867 Mbps |
| Ethernet Ports |
2x GE RJ45 |
| USB Port |
1x Type A |
| Serial Console Port |
1 RS-232 x RJ45 |
| Power over Ethernet (PoE) |
Dual redundant PoE power ports with support for IEEE 802.3af (12.9 W) |
| WME Multimedia Extensions |
Yes (4 priority queues for voice, video, data and background traffic) |
| Simultaneous SSIDs |
16 (14 if background scanning enabled) |
| EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication |
WPA™ and WPA2™ with 802.1x or Preshared key, WEP and Web Captive Portal, MAC blacklist & whitelist |
| Maximum Tx Power |
19 dBm (80 mW) |
| Physical Security |
Kensington Lock |
| Mean Time Between Failures |
>30 Years |
| IEEE Specifications |
802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11n, 802.1x, 802.11ac, 802.3af, 802.3at, 802.3az |
| Mounting Options |
Ceiling, T-Rail and wall |
| Included Accessories |
Ceiling, T-Rail and wall mount kit (AC power adapter sold separately) |
| Wireless Mesh Capable |
Yes |
| FortiPresence Capable |
Yes |
| Modes of Operation |
FortiGate or FortiCloud management |
| SSID Types Supported |
Local-Bridge, Tunnel & Mesh (when managed by FortiGate) |
| FortiDeploy and FortiCloud Key |
Yes |
| Per Radio Client Capacity |
Up to 512 |
| LED Off Mode |
Yes |
| Onboard Security Features when Managed from FortiCloud |
| Application Control |
Yes |
| Block Botnet |
Yes |
| Antivirus |
Yes |
| Intrusion Prevention |
Yes |
| URL Filtering |
Yes |
| FortiGuard Security Feed |
Subscription available through FortiCloud |
| Advanced 802.11 Features |
| 802.11ac Wave2 MU-MIMO |
Yes |
| Transmit Beam Forming (TxBF) |
Yes |
| Low-Density Parity Check (LDPC) Encoding |
Yes |
| Maximum Likelihood Demodulation (MLD) |
Yes |
| Maximum Ratio Combining (MRC) |
Yes |
| A-MPDU and A-MSDU Packet Aggregation |
Yes |
| MIMO Power Save |
Yes |
| Short Guard Interval |
Yes |
| Wireless Monitoring Capabilities |
| Frequencies scanned |
2.4 and 5 GHz |
| Background scan with client access on 2.4 and 5 GHz |
Yes |
| Full-time scan as dedicated monitor |
Yes |
| Full-time scan with client access |
No |
| Packet sniffer mode |
Yes |
| Spectrum analyzer |
Yes |
| Dimensions |
| Length x Width x Height |
7.87 x 7.87 x 1.81 inches (20 x 20 x 4.6 cm) |
| Weight |
1.2 lbs (0.55 kg) |
| Package (shipping) Weight |
2.5 lbs (1.15 kg) |
| Environment |
| Power Supply |
Adapter input:100–240V, 50/60Hz,0.9A, Max output: 12V DC, 3A |
| Power Consumption (Average / Maximum) |
22.87 W / 24 W |
| Humidity |
5–90% non condensing |
| Operating Temperature |
-4–122°F (-20–50°C) |
| Storage Temperature |
-40–158°F (-40–70°C) |
| Directives |
Low Voltage Directive • RoHS |
| UL2043 Plenum Material |
Yes |
| IP Rating |
— |
| Certifications |
| WiFi Alliance Certified |
Yes |
| DFS Certified |
Yes |
