Tường lửa Firewall Fortinet FG-100F FortiGate 100F with Multiple GE RJ45, GE SFP and 10GE SFP+ slots
| Fortigate Part Number |
:
|
| List Price |
: $
|
| Giá bán |
:
|
| Bảo hành |
:
|
| Made In |
:
|
| Stock |
:
|
Thiết bị tường lửa thế hệ mới Firewall Fortinet FortiGate FG-100F cung cấp khả năng tường lửa thế hệ mới cho các doanh nghiệp vừa và lớn, với sự linh hoạt được triển khai tại các doanh nghiệp hoặc các chi nhánh.
FortiGate 100F Datasheet
Firewall FortiGate FG-100F giúp chống lại các mối đe dọa trên mạng với bộ xử lý bảo mật cung cấp hiệu suất cao, hiệu quả bảo mật và khả năng hiển thị chi tiết các vấn đề bảo mật.
Thông số kỹ thuật Firewall FortiGate FG-100F
| Interfaces and Modules |
| GE RJ45 Ports |
12 |
| GE RJ45 Management/HA/DMZ Ports |
1 / 2 / 1 |
| GE SFP Slots |
4 |
| 10 GE SFP+ Slots |
2 |
| GE RJ45 WAN Ports |
2 |
| GE RJ45 or SFP Shared Ports |
4 |
| Console Port |
1 |
| USB Port |
1 |
| System Performance and Capacity |
| Firewall Throughput (1518 / 512 / 64 byte, UDP) |
20 / 18 / 10 Gbps |
| Firewall Latency (64 byte, UDP) |
5 μs |
| Firewall Throughput (Packet per Second) |
15 Mpps |
| Concurrent Sessions (TCP) |
1.5 Million |
| New Sessions/Sec (TCP) |
56,000 |
| Firewall Policies |
10,000 |
| IPsec VPN Throughput (512 byte) |
11.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2,500 |
| Client-to-Gateway IPsec VPN Tunnels |
16,000 |
| SSL-VPN Throughput |
1 Gbps |
| Concurrent SSL-VPN Users |
500 |
| SSL Inspection Throughput (IPS, HTTP) |
1 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
1,800 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
135,000 |
| Application Control Throughput (HTTP 64K) |
2.2 Gbps |
| CAPWAP Throughput (1444 byte, UDP) |
15 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of Switches Supported |
32 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
128 / 64 |
| Maximum Number of FortiTokens |
5,000 |
| Maximum Number of Registered FortiClients |
600 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput |
2.6 Gbps |
| NGFW Throughput |
1.6 Gbps |
| Threat Protection Throughput |
1 Gbps |
| Dimensions and Power |
| Height x Width x Length (inches) |
1.73 x 17 x 10 |
| Height x Width x Length (mm) |
44 x 432 x 254 |
| Weight |
7.25 lbs (3.29 kg) |
| Form Factor |
Rack Mount, 1 RU |
| Environment |
| Power Required |
100–240V AC, 50-60 |
| Maximum Current |
100V / 1A, 240V / 0.5A |
| Power Consumption (Average / Maximum) |
35.1 W / 38.7 W |
| Heat Dissipation |
119.77 BTU/h |
| Redundant Power Supplies |
Yes |
| Operating Temperature |
32–104°F (0–40°C) |
| Storage Temperature |
-31–158°F (-35–70°C) |
| Operating Altitude |
Up to 7,400 ft (2,250 m) |
| Humidity |
10–90% non-condensing |
| Noise Level |
40.4 dBA |
| Compliance |
FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI |
| Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; IPv6 |
Các tùy chọn Option, License cho FG-100F
Fortinet FortiGate-100F 360 Protection (ASE FortiCare plus App Ctrl, IPS, AV, Web Filtering, AS, FSA Cloud, Security Rating, IoT Detection, SD-WAN Orchestrator/Cloud Monitoring/Overlay Ctrl VPN, FMG/FAZ/IPAM Cloud, Industrial Security and FortiConverter S
FortiGate-100F 1 Year 360 Protection (ASE FortiCare plus App Ctrl, IPS, AMP, Web Filtering, AS, Security Rating, IoT Detection, SD-WAN Orchestrator/Cloud Monitoring/Overlay Ctrl VPN, FMG/FAZ/IPAM Cloud, Industrial Security and FortiConverter Svc)
#FC-10-F100F-817-02-12
List Price: Liên hệ
FortiGate-100F 3 Year 360 Protection (ASE FortiCare plus App Ctrl, IPS, AMP, Web Filtering, AS, Security Rating, IoT Detection, SD-WAN Orchestrator/Cloud Monitoring/Overlay Ctrl VPN, FMG/FAZ/IPAM Cloud, Industrial Security and FortiConverter Svc)
#FC-10-F100F-817-02-36
List Price: Liên hệ
FortiGate-100F 5 Year 360 Protection (ASE FortiCare plus App Ctrl, IPS, AMP, Web Filtering, AS, Security Rating, IoT Detection, SD-WAN Orchestrator/Cloud Monitoring/Overlay Ctrl VPN, FMG/FAZ/IPAM Cloud, Industrial Security and FortiConverter Svc)
#FC-10-F100F-817-02-60
List Price: Liên hệ
Fortinet FortiGate-100F Enterprise Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering, Antispam, FortiSandbox Cloud, IoT Detection, Industrial Security, Security Rating, and FortiConverter Svc)
FortiGate-100F 1 Year Enterprise Protection (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering, Antispam, IoT Detection, Industrial Security, Security Rating, and FortiConverter Svc)
#FC-10-F100F-811-02-12
List Price: Liên hệ
FortiGate-100F 3 Year Enterprise Protection (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering, Antispam, IoT Detection, Industrial Security, Security Rating, and FortiConverter Svc)
#FC-10-F100F-811-02-36
List Price: Liên hệ
FortiGate-100F 5 Year Enterprise Protection (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering, Antispam, IoT Detection, Industrial Security, Security Rating, and FortiConverter Svc)
#FC-10-F100F-811-02-60
List Price: Liên hệ
Fortinet FortiGate-100F IoT Detection Service
FortiGate-100F 1 Year IoT Detection Service
#FC-10-F100F-231-02-12
List Price: Liên hệ
Fortinet FortiGate-100F FortiIPAM Cloud Service
FortiGate-100F 1 Year FortiIPAM Cloud Service
#FC-10-F100F-233-02-12
List Price: Liên hệ
Fortinet FortiGate-100F SD-WAN Orchestrator Entitlement License
FortiGate-100F 1 Year SD-WAN Orchestrator Entitlement License
#FC-10-F100F-319-02-12
List Price: Liên hệ
Fortinet FortiGate-100F Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud)
FortiGate-100F 1 Year Unified Threat Protection (UTP) (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering and Antispam Service)
#FC-10-F100F-950-02-12
List Price: Liên hệ
FortiGate-100F 3 Year Unified Threat Protection (UTP) (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering and Antispam Service)
#FC-10-F100F-950-02-36
List Price: Liên hệ
FortiGate-100F 5 Year Unified Threat Protection (UTP) (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering and Antispam Service)
#FC-10-F100F-950-02-60
List Price: Liên hệ
Fortinet FortiGate-100F Advanced Threat Protection (24x7 FortiCare plus Application Control, IPS, AV and FortiSandbox Cloud)
FortiGate-100F 1 Year Advanced Threat Protection (24x7 FortiCare plus Application Control, IPS and AMP Service)
#FC-10-F100F-928-02-12
List Price: Liên hệ
FortiGate-100F 3 Year Advanced Threat Protection (24x7 FortiCare plus Application Control, IPS and AMP Service)
#FC-10-F100F-928-02-36
List Price: Liên hệ
FortiGate-100F 5 Year Advanced Threat Protection (24x7 FortiCare plus Application Control, IPS and AMP Service)
#FC-10-F100F-928-02-60
List Price: Liên hệ
Fortinet FortiGate-100F FortiGate Cloud Management, Analysis and Log Retention
FortiGate-100F 1 Year FortiGate Cloud Management, Analysis and Log Retention
#FC-10-F100F-131-02-12
List Price: Liên hệ
FortiGate-100F 3 Year FortiGate Cloud Management, Analysis and Log Retention
#FC-10-F100F-131-02-36
List Price: Liên hệ
FortiGate-100F 5 Year FortiGate Cloud Management, Analysis and Log Retention
#FC-10-F100F-131-02-60
List Price: Liên hệ
Fortinet FortiGate-100F FortiGuard Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiSandbox Cloud Service
FortiGate-100F 1 Year FortiGuard Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiGate Cloud Sandbox Service
#FC-10-F100F-100-02-12
List Price: Liên hệ
Fortinet FortiGate-100F FortiGuard IPS Service
FortiGate-100F 1 Year FortiGuard IPS Service
#FC-10-F100F-108-02-12
List Price: Liên hệ
Fortinet FortiGate-100F FortiGuard Web Filtering Service
FortiGate-100F 1 Year FortiGuard Web Filtering Service
#FC-10-F100F-112-02-12
List Price: Liên hệ
Fortinet FortiGate-100F FortiGuard Industrial Security Service
FortiGate-100F 1 Year FortiGuard Industrial Security Service
#FC-10-F100F-159-02-12
List Price: Liên hệ
Fortinet FortiGate-100F FortiGuard Security Rating Service
FortiGate-100F 1 Year FortiGuard Security Rating Service
#FC-10-F100F-175-02-12
List Price: Liên hệ
Fortinet FortiGate-100F SD-WAN Cloud Assisted Monitoring: Cloud-based SD-WAN Bandwidth & Quality Monitoring Service
FortiGate-100F 1 Year SD-WAN Cloud Assisted Monitoring: Cloud-based SD-WAN Bandwidth & Quality Monitoring Service
#FC-10-F100F-288-02-12
List Price: Liên hệ
Fortinet FortiGate-100F SD-WAN Overlay Controller VPN Service: Cloud-based SD-WAN VPN Overlay Service & Portal
FortiGate-100F 1 Year SD-WAN Overlay Controller VPN Service: Cloud-based SD-WAN VPN Overlay Service & Portal
#FC-10-F100F-289-02-12
List Price: Liên hệ
Fortinet FortiGate-100F FortiManager Cloud: Cloud-based Central Management & Orchestration Service
FortiGate-100F 1 Year FortiManager Cloud: Cloud-based Central Management & Orchestration Service
#FC-10-F100F-179-02-12
List Price: Liên hệ
Fortinet FortiGate-100F FortiAnalyzer Cloud: Base subscription for Cloud-based Events Management & Analytics Service
FortiGate-100F 1 Year FortiAnalyzer Cloud: Cloud-based Events and Security Log Monitoring including IOC Service
#FC-10-F100F-188-02-12
List Price: Liên hệ
Fortinet FortiGate-100F FortiConverter Service for one time configuration conversion service
FortiGate-100F 1 Year FortiConverter Service for one time configuration conversion service
#FC-10-F100F-189-02-12
List Price: Liên hệ
Fortinet FortiGate-100F 24x7 FortiCare Contract
FortiGate-100F 1 Year 24x7 FortiCare Contract
#FC-10-F100F-247-02-12
List Price: Liên hệ
FortiGate-100F 3 Year 24x7 FortiCare Contract
#FC-10-F100F-247-02-36
List Price: Liên hệ
FortiGate-100F 5 Year 24x7 FortiCare Contract
#FC-10-F100F-247-02-60
List Price: Liên hệ
Fortinet FortiGate-100F ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
FortiGate-100F 1 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
#FC-10-F100F-284-02-12
List Price: Liên hệ
FortiGate-100F 3 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
#FC-10-F100F-284-02-36
List Price: Liên hệ
FortiGate-100F 5 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
#FC-10-F100F-284-02-60
List Price: Liên hệ
Fortinet FortiGate-100F Next Day Delivery Premium RMA Service (requires 24x7 support)
FortiGate-100F 1 Year Next Day Delivery Premium RMA Service (Requires 24x7 or ASE FortiCare)
#FC-10-F100F-210-02-12
List Price: Liên hệ
Fortinet FortiGate-100F 4-Hour Hardware Delivery Premium RMA Service (requires 24x7 support)
FortiGate-100F 1 Year 4-Hour Hardware Delivery Premium RMA Service (Requires 24x7 or ASE FortiCare)
#FC-10-F100F-211-02-12
List Price: Liên hệ
Fortinet FortiGate-100F 4-Hour Hardware and Onsite Engineer Premium RMA Service (requires 24x7 support)
FortiGate-100F 1 Year 4-Hour Hardware and Onsite Engineer Premium RMA Service (Requires 24x7 or ASE FortiCare)
#FC-10-F100F-212-02-12
List Price: Liên hệ
Fortinet FortiGate-100F Secure RMA Service
FortiGate-100F 1 Year Secure RMA Service
#FC-10-F100F-301-02-12
List Price: Liên hệ
