| Hardware |
| Hardware Type |
Remote (Indoor) |
| Number of Radios |
1 |
| Number of Antennas |
2 internal |
| Peak Antenna Gain |
3 dBi for 2.4 GHz, 4 dBi for 5 GHz |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725,
5.725–5.850 |
| Frequency of Radio 1 |
2.4 GHz b/g/n, 5 GHz a/n |
| Frequency of Radio 2 |
- |
| Throughput |
Up to 300 Mbps |
| Tx/Rx Streams |
2x2 MIMO 2 spatial stream |
| Ethernet Ports |
10x GE RJ45 ports
(2x GE WAN ports, 8x GE LAN ports) |
| USB Port |
2x Type A, 1x Type B |
| Serial Console Port |
- |
| Power over Ethernet (PoE) |
- |
| WME Multimedia Extensions |
Yes (4 priority queues for voice, video, data and background traffic) |
| Simultaneous SSIDs |
8 (7 if background scanning enabled) |
| EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2,
PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication |
WPA™ and WPA2™ with 802.1x or Preshared key,
WEP and Web Captive Portal, MAC blacklist & whitelist |
| Maximum Tx Power |
17 dBm (50 mW) * |
| Physical Security |
Kensington Lock |
| Mean Time Between Failures |
> 10 years |
| IEEE Specifications |
802.11b, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11n, 802.1x |
| 802.11n Features |
20 MHz and 40 MHz High-Throughput (HT) Support
Increased maximum frame transmission by incorporating A-MPDU
and A-MSDU Packet Aggregation
Conserve power via Dynamic MIMO power save |
Advanced 802.11n to enhance
rate-over-range including: |
Low-density parity check (LDPC) encoding
Maximum likelihood demodulation (MLD)
Transmit beamforming (TxBF)
Maximum Ratio Combining (MRC) for improved receiver |
| Mounting Options |
Desktop, Wall |
| Included Accessories |
AC power adapter and wall mount kit |
| FortiPresence Capable |
Yes |
| Reg Domain |
Singapore |
| Wireless Monitoring Capabilities |
| Frequencies scanned |
2.4 and 5 GHz |
| Background scan with client access on 2.4 and 5 GHz |
- |
| Full-time scan as dedicated monitor |
Yes |
| Dimensions |
| Length x Width x Height |
7.09 x 8.43 x 1.38 inches (18 x 21.4 x 3.5 cm) |
| Weight |
1.1 lbs (0.5 kg) |
| Package (shipping) Weight |
3.2 lbs (1.47 kg) |
| Environment |
| Power Supply |
Adapter Input: 100–240V AC, 50–60 Hz |
| Power Consumption (Average) |
14 W |
| Power Consumption (Maximum) |
15 W |
| Humidity |
20–90% non-condensing |
| Operating Temperature |
32–104°F (0–40°C) |
| Storage Temperature |
-13–158°F (-25–70°C) |
| Directives |
Low Voltage Directive • RoHS |
