TECHNOLOGY |
OPERATING MODES |
Centralized deployment mode
Distributed deployment mode
MESH mode
Bridge mode
Remote VPN tunnel mode |
QOS |
802.11E support (including WMM)
Dynamic WMM rate adaptation
Configurable QoS rules per user and application |
SECURITY |
WEP, WPA-PSK, WPA-TKIP, WPA2-AES, 802.11i, 802.1X (EAP-TLS, EAP-TTLS, PEAP, LEAP, EAP-FAST, EAP-SIM, EAP-AKA, and EAP-MD5)
802.1X and captive portal authentication against local database on the controller, RADIUS, and Active Directory
RADIUS-assisted per-user and per-ESSID access control via MAC filtering |
MANAGEMENT |
Centrally managed by any Fortinet controller running System Director 6.1 or later
Automatically discovers controllers and downloads configuration settings for plug-and-play deployment
Upgrades and management via System Director / Network Manager
Support for SNMP
Concurrent Clients Per Radio (Maximum / Recommended) — 128 / 40 |
WIRELESS SPECIFICATIONS |
Model Introduction |
dual-radio, dual-band IEEE Std 802.11a/b/g/n/ac access point with six RP-SMA connectors and six external omnidirectional antennas |
Supported Radio Technologies |
Dual-band, dual-radio access point
3x3:3SS (three spatial streams)
Indoor application
Supported 2.4 GHz (TurboQAM Mode) and 5.x GHz for dual-band, dual-radio operation, data rate up to 1.9 Gbps
Supported dual 5.x GHz IEEE Std 802.11ac operation with RF collocation (FCC Permit by Ask provision), data rate up to 2.6 Gbps
Supported transmit beam-forming (TxBF) IEEE Std 802.11ac standard
IEEE Std 802.11n/ac with Orthogonal Frequency Division Multiplexing (OFDM)
IEEE Std 802.11b with Direct Sequence Spread Spectrum (DSSS)
IEEE Std 802.11ac with 20/40/80 MHz (VHT20/40/80) channel width
IEEE Std 802.11n with 40 MHz (HT40) channel width
IEEE Std 802.11a/g with 20 MHz channel
IEEE Std 802.11b with 22 MHz channel |
Supported Modulation |
IEEE Std 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
IEEE Std 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
IEEE Std 802.11b: BPSK, QPSK, CCK
Featured 256-TurboQAM modulation for 2.4 GHz and 5 GHz operations |
Supported MCS Index |
Supported MCS0–MCS9 (NSS=1-3) for IEEE Std 802.11ac
Supported MCS0–MCS23 for IEEE Std 802.11n |
Supported Frequency Bands |
2.400–2.4835 GHz (ISM)
5.150–5.250 GHz (UNII-1)
5.250–5.350 GHz (UNII-2, DFS)
5.470–5.725 GHz (UNII-2 Extended, DFS)
5.725–5.825 GHz (UNII-3)
Country-specific restrictions apply; adjusted by controller upon approva |
Operating Channels |
- 2.4 GHz Channels
- CH1–11 for U.S., Canada
- CH1–13 for Japan, Europe, rest of world
- 5 GHz HT20 (20 MHz) Channel
- Non-DFS Channel: CH36, 40, 44, 48, 144, 149, 153, 161, 165
- DFS Channel upon approval: CH 52, 56, 60, 64, 100, 104, 108, 112, 116, 120*, 124*, 128*, 132*, 136, 140, 144 (*weather radar)
- 5 GHz HT40 (40 MHz) Center Channel
- Non-DFS channel: CH38, 46, 151, 159
- DFS channel upon approval: CH54, 62, 102, 110, 118*, 116*, 134* 134, 142 (*weather radar)
- 5 GHz VHT80 (80 MHz) Center Channel
- Non-DFS channel: CH42, 155
- DFS channel upon approval: CH58, 106, 122* (*weather channel)
- Platform supports Dynamic Frequency Selection (DFS & DFS/TPC)
- Country-specific restrictions apply; adjusted by controller upon approva
|
Supported Data Rate (Mbps) |
IEEE Std 802.11ac three streams: 19.5–1300 Mbps (MCS0-HT20@800nS to MCS9-HT40@400nS)
IEEE Std 802.11ac per stream: 6.5–433.3 Mbps (MCS0-HT20@800nS to MCS9-HT40@400nS)
IEEE Std 802.11n Three streams: 13–450 Mbps (MCS9-HT20@800nS to MCS23-HT40@400nS)
IEEE Std 802.11n Per stream: 6.5–150 Mbps (MCS0-HT20 @ 800nS to MCS7-HT40@400nS)
IEEE Std 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE Std 802.11b: 1, 2, 5.5, 11 Mbps |
PHYSICAL SPECIFICATIONS |
Power |
Operates at IEEE 802.3af power
Powered by IEEE Std 802.3af or 802.3at PoE (Power over Ethernet) injector or switch
12V external power adapter (sold separately) |
Other Interfaces |
Networks: One 10/100/1000 Mbps Base-T Ethernet RJ-45 port for Data uplink (G1) supports only 802.3af PoE. One 10/100/1000 Mbps Base-T Ethernet RJ-45 port for Data uplink (G2) requires 802.3at PoE.
Six RPSMA RF connectors for external antenna SKU (AP832e)
One console port
One reset button
One Kensington security slot |
LED Indicators |
One tri-color LED for AP status
Additional LEDs for Ethernet activity over two RJ45 ports (G1 & G2) |
Mounting |
Wall, desktop, or ceiling mount
Three mounting kits included with access point:
– 650-00232, 15/16” T-bar and wall-mount combo adapter
– 650-00233, 9/16” T-bar adapter
– Flat-surface wall-mount bracket (used with 650-00232) |
Option (ordered separately) |
CBL-SERIAL-DB9-35, DB9-stereo console cable
CBL-RJ45-ADAPT-X5, GE extension adapter
MNT-FEET-SET-X5, rubber feet for desktop staging |
Installation in the Air-Handling Space |
metal enclosure only by removing plastic façade |
Dimensions |
with mounting bracket: 7.1 x 7.1 x 2.7 inches (18.0 x 18.0 x 6.8 cm)
without plastic façade: 6.3 x 6.3 x 2.1 inches (16.1 x 16.0 x 5.2 cm) |
Weight |
with mounting bracket: 1.9 lbs (0.9 kg)
without facade and mounting bracket: 1.5 lbs (0.7 kg) |
Environmental |
Operating temperature: 32–122°F (0–50°C)
Operating humidity: 5–95% non-condensing
Storage temperature: -40–158°F (-40–70°C) ambient
Storage humidity: 5–95% non-condensing |
REGULATORY APPROVAL |
REGULATORY APPROVAL |
LFCC (United States of America)
CE Mark (European Community)
Industry Canada (Canada)
TELEC (Japan)
Safety Approval (worldwide)
For more country-specific regulatory approval, please contact your Fortinet representative |
CERTIFICATIONS |
CERTIFICATIONS |
WiFi CERTIFIED™
EU RoHS
CB Report |
