Hardware Specifications |
Total Network Interfaces |
48x GE RJ45 and 4x 10GE SFP+ ports
Note: SFP+ ports are compatible with 1 GE SFP |
Dedicated Management 10/100 Port |
1 |
RJ-45 Serial Console Port |
1 |
Form Factor |
1 |
Power over Ethernet (PoE) Ports |
48 (802.3af/at) |
PoE Power Budget |
421 W |
Mean Time Between Failures |
> 10 years |
System Specifications |
Switching Capacity (Duplex |
176 Gbps |
Packets Per Second (Duplex) |
262 Mpps |
MAC Address Storage |
32 K |
Network Latency |
<1μs |
VLANs Supported |
4 K |
Link Aggregation Group Size |
8 |
Total Link Aggregation Groups |
Up to number of ports |
Packet Buffers |
2 MB |
DRAM |
1GB DDR4 |
FLASH |
256 MB |
Environment |
Power Required |
100–240V AC, 50/60 Hz |
Power Supply |
AC built in |
Redundant Power |
Redundant AC |
Power Consumption* (Average / Maximum) |
440.12 W / 442.234 W |
Heat Dissipation |
163.066 BTU/h |
Operating Temperature |
32–122°F (0–50°C) |
Storage Temperature |
-4–158°F (-20–70°C) |
Humidity |
10–90% non condensing |
Air-Flow Direction |
side-to-back |
Layer 2 |
Jumbo Frames, Auto-negotiation for Port Speed and Duplex, MDI/MDIX Auto-crossover, IEEE 802.1D MAC Bridging/STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP), IEEE 802.1s Multiple Spanning Tree Protocol (MSTP), STP Root Guard, STP BPDU Guard, Edge Port / Port Fast, IEEE 802.1Q VLAN Tagging, Private VLAN, IEEE 802.3ad Link Aggregation with LACP, Unicast/Multicast traffic balance over trunking port
(dst-ip, dst-mac, src-dst-ip, src-dst-mac, src-ip, src-mac), IEEE 802.1AX Link Aggregation, Spanning Tree Instances (MSTP/CST), IEEE 802.3x Flow Control and Back-pressure, IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3z 1000Base-SX/LX, IEEE 802.3ab 1000Base-T, IEEE 802.3ae 10 Gigabit Ethernet, IEEE 802.3az Energy Efficient Ethernet, IEEE 802.3bz Multi Gigabit Ethernet, IEEE 802.3 CSMA/CD Access Method and Physical Layer Specifications, Time-Domain Reflectcometry (TDR) Support, Split Port (QSFP+ breakout to 4x10G SFP+ or 4x1G SFP), Virtual-Wire, MAC, IP, Ethertype-based VLANs, Storm Control |
Layer 3 |
Static Routing (Hardware-based) |
Yes |
Routing Entries |
16K |
Host Entries |
16K |
Dynamic Routing Protocols |
OSPFv2, RIPv2, VRRP khi kèm License |
Bidirectional Forwarding Detection (BFD) |
Yes |
DHCP Relay |
Yes |
Services |
IGMP Snooping |
Security and Visibility |
Port Mirroring, Admin Authentication Via RFC 2865 RADIUS, IEEE 802.1x authentication Port-based, IEEE 802.1x Authentication MAC-based, IEEE 802.1x Guest and Fallback VLAN, IEEE 802.1x MAC Access Bypass (MAB), IEEE 802.1x Dynamic VLAN Assignment, Radius CoA (Change of Authority), Radius Accounting, sFlow, ACL, IEEE 802.1ab Link Layer Discovery Protocol (LLDP), IEEE 802.1ab LLDP-MED, IEEE 802.1ae MAC Security (MAC Sec), DHCP-Snooping, Dynamic ARP Inspection, Sticky MAC and MAC Limit |
High Availability |
Multi-Chassis Link Aggregation (MCLAG) |
Quality of Service |
IEEE 802.1p Based Priority Queuing, IP TOS/DSCP Based Priority Queuing, IEEE 1588 PTP (Transparent Clock) |
Management |
IPv4 and IPv6 Management, Telnet / SSH, HTTP / HTTPS, SNMP v1/v2c/v3, SNTP, Standard CLI and Web GUI Interface, Software download/upload: TFTP/FTP/GUI, Managed from FortiGate, Support for HTTP REST APIs for, Configuration and Monitoring |
