Hardware Specifications |
GE RJ45 WAN / DMZ Ports |
1 |
GE RJ45 Internal Ports |
3 |
GE RJ45 FortiLink Ports |
1 |
GE RJ45 PoE/+ Ports |
- |
Wireless Interface |
802.11 a/b/g/n/ac wave 2 |
Console Port |
1 |
USB Port |
1 |
Internal Storage |
- |
System Performance — Enterprise Traffic Mix |
IPS Throughput |
1 Gbps |
NGFW Throughput |
800 Mbps |
Threat Protection Throughput |
600 Mbps |
System Performance |
Firewall Throughput (1518 / 512 / 64 byte UDP packets) |
5/5/5 Gbps |
Firewall Latency (64 byte, UDP) |
4 μs |
Firewall Throughput (Packet per Second) |
7.5 Mpps |
Concurrent Sessions (TCP) |
700,000 |
New Sessions/Sec (TCP) |
35,000 |
Firewall Policies |
5,000 |
IPsec VPN Throughput (512 byte) |
4.4 Gbps |
Gateway-to-Gateway IPsec VPN Tunnels |
200 |
Client-to-Gateway IPsec VPN Tunnels |
250 |
SSL-VPN Throughput |
490 Mbps |
Concurrent SSL-VPN Users |
200 |
SSL Inspection Throughput (IPS, HTTP) |
310 Mbps |
SSL Inspection CPS (IPS, avg. HTTPS) |
320 |
SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
55,000 |
Application Control Throughput |
990 Mbps |
CAPWAP Throughput (1444 byte, UDP) |
3.5 Gbps |
Virtual Domains (Default / Maximum) |
10 / 10 |
Maximum Number of Switches Supported |
16 |
Maximum Number of FortiAPs (Total / Tunnel Mode) |
10 / 10 |
Maximum Number of FortiTokens |
500 |
High Availability Configurations |
Active / Active, Active / Passive, Clustering |
Radio Specifications |
Multiple (MU) MIMO |
3x3 |
Maximum Wi-Fi Speeds |
1300 Mbps @ 5 GHz
450 Mbps @ 2.4 GHz
|
Maximum Tx Power |
20 dBm |
Antenna Gain |
3.5 dBi @ 5GHz
5 dBi @ 2.4 GHz
|
Dimensions and Power |
Height x Width x Length (inches) |
1.5 x 8.5 x 6.3 |
Height x Width x Length (mm) |
38.5 x 216 x 160 |
Weight |
2.2 lbs (1 kg) |
Form Factor |
Desktop |
Operating Environment and Certifications |
Input Rating |
12Vdc, 3A |
Power Required |
Powered by External DC Power Adapter, 100–240V AC, 50–60 Hz |
Maximum Current |
100V AC / 0.2A, 240V AC / 0.1A |
Power Consumption (Average / Maximum) |
12.4 W / 15.4 W |
Heat Dissipation |
52.55 BTU/hr |
Operating Temperature |
32–104°F (0–40°C) |
Storage Temperature |
-31–158°F (-35–70°C) |
Humidity |
10–90% non-condensing |
Noise Level |
Fanless 0 dBA |
Operating Altitude |
Up to 7,400 ft (2,250 m) |
Compliance |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
