| CELLULAR WAN |
- Supported Frequency Bands
LTE: B1, B2, B3, B4, B5, B7, B8, B20, B28
WCDMA: 2100 (B1), 1900 (B2), 850 (B5
EV-DO / CDMA: 800 (BC0)
GSM / GPRS / EDGE: 850/900/1800/1900
- Automatic SIM based network operator switching |
| HOST INTERFACES |
10/100/1000 Base-T RJ45 Ethernet port
(1)RS-232 ,(5)RS-485 Serial Console Port
3 SMA antenna connectors (WIFI and Double-cellular)
(6) pin,(14)pin 3.5mm terminal block |
| INPUT/OUTPUT |
(2) DI, (1) DO, (1) Relay
Input ON Voltage: 5 to 30 VDC.
Input OFF Voltage: 0 to 3 VDC.
Output < 50mA @ 30VDC.
Relay:1A 250VAC/30VDC |
| LAN |
DNS, DNS Proxy
DHCP Server
IP Passthrough (option)
VLAN
Host Interface Watchdog
PPPoE |
| SERIAL |
TCP/UDP PAD Mode
Modbus (ASCII, DTU, Variable)
PPP
Reverse Telnet |
| EVENTS ENGINE (Option) |
Custom event triggers and reports.
Configurable interface, no programming.
Event Types: Digital Input, Network Parameters, Data Usage, Timer, Power, Device Temperature.
Report Types: TCP, UDP, SMS, SNMP Trap, HTTP, JSON.
Event Actions: Drive Relay Output. |
| WIFI |
IEEE802.11 ac, compatible IEEE 802.11 b/g/n
AP and client mode
Adjustable output power (Max: 26dBm)
Access point for up to 30 clients
Simultaneous access point/client mode
WEP, WPA-PSK, WPA2-PSK etc. Security
|
| NETWORK AND ROUTING |
Network Address Translation (NAT)
Port Forwarding
Host Port Routing
VRRP
Reliable Static Route
Dynamic DNS |
| VPN |
IPSec, GRE, and OPENVPN Client
Up to 10 concurrent tunnels
Split Tunnel
Dead Peer Detection (DPD)
Multiple Subnets
VPN Failover |
| SECURITY |
Remote Authentication
DMZ
Inbound and Outbound Port filtering
MAC Address Filtering. |
| GPS (Option) |
Antenna Interface: SMA Female, 50 ohms impedance
Tracking Sensitivity: better than -144 dBm
Horizontal position accuracy: 2.5 m
Time-To-First-Fix: 29 s
Protocol: NMEA-0183 V2.3 |
| OPERATION ENVIRONMENT |
Operating Temperature: -35°C to +75°C / -31°F to +167°F
Storage Temperature: -40°C to 85°C / -40°F to 185°F
Humidity: 90% RH @ 60°C |
