| CELLULAR WAN |
Supported Frequency Bands
LTE: B1, B2, B3, B4, B5, B7, B8, B20, B28
WCDMA: 2100(B1), 1900(B2), 850(B5)
EV-DO/CDMA: 800(BC0)
GSM/GPRS/EDGE: 850/900/1800/1900
Automatic SIM based network operator switching |
| HOST INTERFACES |
10/100 Base-T RJ45 Ethernet port
RS-232 or RS-485 Serial Console Port
3 SMA antenna connectors (WI-FI and Double-cellular)
Active GPS/ZigBee antenna support (option)
(6) pin 3.5mm terminal block |
| INPUT/OUTPUT |
(6) pin 3.5mm terminal block
(2) DI, (1) DO, (1) Relay.
Input ON Voltage: 5 to 30 VDC
Input OF Voltage: 0 to 3 VDC
Output < 50mA @ 30VDC |
| LAN |
DNS, DNS Proxy
DHCP Server
IP Passthrough (option)
VLAN
Host Interface Watchdog
PPPoE |
| SERIAL |
TCP/U DP PAD Mode
Modbus (ASCII, DTU, Variable)
PPP
Reverse Telnet |
| WI-FI |
IEEE802.11 b/g/n, AP and client mode.
Adjustable output power (Max: 26dBm)
Access point for up to 30 clients
Simultaneous access point/client mode
WEP, WPA-PSK, WPA2-PSK etc. Security |
| NETWORK AND ROUTING |
Network Address Translation (NAT)
Port Forwarding
Host Port Routing
VRRP
Reliable Static Route
Dynamic DNS |
| VPN |
IPsec, GRE, and OPENVPN Client
Up to 10 concurrent tunnels
Split Tunnel
Dead Peer Detection (DPD)
Multiple Subnets
VPN Failover |
| SECURITY |
Remote Authentication
DMZ
Inbound and Outbound Port filtering
Inbound and Outbound Trusted IP
MAC Address Filtering
PCI DSS V3.0 compatible |
| GPS (Option) |
Antenna Interface: SMA Female, 50 ohms impedance
Tracking Sensitivity: better than -144 dBm
Horizontal position accuracy: 2.5 m
Time-To-First-Fix: 29 s
Protocol: NMEA-0183 V2.3 |
| EVENTS ENGINE (Option) |
Custom event triggers and reports
Configurable interface, no programming
Event Types: Digital Input, Network Parameters, Data Usage, Timer, Power, Device Temperature
Report Types: RAP, SMS, Email, SNMP Trap, TCP (Binary, XML, CSV)
Event Actions: Drive Relay Output |
| Four-Faith MANAGEMENT SERVICE |
Secure cloud-based device management application
Remote provisioning
Gateway configuration and template management
Configurable monitoring and alerting
Software and radio module firmware updates
Auto configuration |
| MANAGEMENT INTERFACES |
Web-Based User Interface
Device Configuration Templates
Software and radio module firmware updates
AT Command Line Interface (Telnet/SSH/Serial)
SMS Commands (Option)
SNMP |
| Operating Environment |
Operating Temperature: -35°C to +75°C / -31°F to +167°F
Storage Temperature: -40°C to 85°C / -40°F to 185°F
Humidity: 90% RH @ 60°C |
| DIMENSIONS |
Dimension: (L x W x H): 133 x 115.7 x 45 mm
Installation: 34.6 mm Din-Rail or wall mounting or desktop |
