| Cellular Module |
Industrial cellular module |
| Standard and Band |
CDMA2000 1xRTT 800MHz,
800/1900MHz(optional),450MHz(optional) |
| Bandwidth |
153.6Kbps |
| TX power |
<30dBm |
| RX sensitivity |
<-104dBm |
| Standard and Band |
IEEE 802.15.4
ISM 2.4 GHz |
| Indoor/Urban Range |
60m
90m(for enhanced version) |
| Outdoor/RF Line-of-Sight Range |
1200m
3200m(for enhanced version) |
| Transmit Power |
3.1 mw (+5dBm) /Normal mode, 6.3 mw (+8dBm)/Boost mode
63 mw (+18dBm) (for enhanced version) |
| Bandwidth |
250Kbps |
| Receiver Sensitivity |
-102dBm |
| Network Topologies |
Point-to-Point, Point-to-Multipoint, Peer-to-Peer and Mesh |
| Number of channels |
16 Direct Sequence Channels
15 Direct Sequence Channels (for enhanced version) |
| Channels |
11 to 26
11 to 25 (for enhanced version) |
| Hardware System |
| CPU |
Industrial 32 bits CPU |
| FLASH |
512KB (Extendable) |
| SRAM |
256KB(Extendable) |
| Interface Type |
| Serial |
1 RS232 port and 1 RS485(orRS422) port, 15KV ESD protection
Data bits: 5, 6 ,7, 8
Stop bits: 1, 1.5, 2
Parity: none, even, odd, space, mark
Baud rate: 110~230400 bps |
| Indicator |
"Power", "ACT", "Online", "ZigBee" |
| Antenna |
Cellular: Standard SMA female interface, 50 ohm, lighting protection(optional)
ZigBee: Standard SMA female interface, 50 ohm, lighting protection(optional) |
| SIM/UIM |
Standard 3V/1.8V user card interface, 15KV ESD protection |
| Power |
Terminal block interface, reverse-voltage and overvoltage protection |
| Power Input |
| Standard Power |
DC 12V/0.5A |
| Power Range |
DC 5~35V |
| Power Consumption |
| Communication |
50-85mA@12VDC；115-160mA@5VDC |
| Standby |
25mA@12VDC；45mA@5VDC |
| Sleep |
8mA@12VDC；18mA@5VDC |
| Timing Power Off |
0.6mA@12VDC；1mA@5VDC |
| Physical Characteristics |
| Housing |
Iron, providing IP30 protectionDimensions |
| Dimensions |
91x58.5x22 mm |
| Weight |
210g |
| Environmental Limits |
| Operating Temperature |
-25~+65ºC (-13~+149℉) |
| Extended Operating Temperature |
-30~+75ºC (-22~+167℉) |
| Storage Temperature |
-40~+85ºC (-40~+185℉) |
| Operating Humidity |
95% ( unfreezing) |
