FS-5203B Firewall FortiSwitch module for Fortinet 5000 series

Phân phối FS-5203B Firewall FortiSwitch Networking blade with 8x 10 GE SFP+ fabric slots, 2x 10 GE SFP+ base slots, 1x GE RJ45 management port giá tốt

✓ Mã sản phẩm: FS-5203B

✓ Tình trạng: Còn Hàng

Phụ kiện dùng cho Fortinet

FS-5203B Firewall FortiSwitch Networking blade with 8x 10 GE SFP+ fabric slots, 2x 10 GE SFP+ base slots, 1x GE RJ45 management port

Name: FS-5203B
Brand: Fortinet
SKU: FS-5203B
Availability: InStock
Rating: 5 (45 reviews)

Module Firewall FortiSwitch FS-5203B bao gồm 8 cổng 10GigE SFP+ fabric slots (cổng F1 đến F8) hỗ trợ các module quang 10G, 2 cổng 10GigE SFP+ base slots (cổng B1 và B2) hỗ trợ các module quang 10G, 1 cổng 10/100/1000BASE-T (MGMT) được sử dụng để quản lý.

FS-5203B Firewall FortiSwitch Networking blade

Physical Description

Interfaces and Modules
Fabric Channel Interfaces	8x 10 GE SFP+
Base Channel Interfaces	2x 10 GE SFP+
Management Interfaces	1x GE RJ45
Included Transceivers	2x 10 GE SFP+ SR
40 GE Backplane Fabric Support	-
10 GE Backplane Fabric Support	Yes
GE Backplane Fabric Support	Yes
System Performance
Maximum Traffic Throughput	40 Gbps
Maximum Concurrent Sessions	20 Million
New Sessions/Second (TCP)	170,000
Power and Environment
Power Consumption (Average / Maximum)	210 / 250 W
Heat Dissipation (Average)	853 BTU/h
Operating Temperature	32–104°F (0–40°C)
Storage Temperature	-13–158°F (-35–70°C)
Humidity	20–90% non-condensing
Compliance
Certifications	FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
NEBS Certified	-

Các loại module quang Fortinet sử dụng được cho module FS-5203B

10 GE SFP+ Transceiver Module, Short Range	FG-TRAN-SFP+SR	10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Short Range	FG-TRAN-XFPSR	10 GE XFP transceiver module, short range for all systems with XFP slots
10 GE SFP+ Transceiver Module, Long Range	FG-TRAN-SFP+LR	10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Long Range	FG-TRAN-XFPLR	10 GE XFP transceiver module, long range for all systems with XFP slots
10 GE SFP+ Active Direct Attach Cable	SP-CABLE-ADASFP+	10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots

FS-5203B sử dụng được cho các thiết bị sau

BUNDLE ITEMS

SKU

DESCRIPTION

FortiGate 5144C Chassis	FG-5144C-DC	14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5144C-DC Chassis	FG-5144C-DC-NEBS	14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves, NEBS certified
FortiGate 5140B Chassis	FG-5140B-DC	13U 14-slot chassis with 40G Dual Star fabric backplane, 2 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5060 Chassis	FG-5060-DC	5U 6-slot chassis with Dual Star fabric backplane, 2 PEMs, 2 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves
