FortiSwitch Rugged FSR-124D 16x GE RJ45, 4x GE SFP slots.
Part Number |
:
|
List Price |
: $
|
Giá bán |
:
|
Bảo hành |
:
|
Made In |
:
|
Stock |
:
|
Các thiết bị chuyển mạch FSR-124D cung cấp hiệu suất cao và bảo mật cho các giải pháp Ethernet. FortiSwitch 112D-POE là sản phẩm đáng tin cậy, đơn giản, có thể mở rộng và được gia cố để trở nên phù hợp trong môi trường khắc nghiệt.
FSR-124D Datasheet
FSR-124D cung cấp khả năng phục hồi mạnh mẽ và có khả năng chịu được biến động nhiệt độ mạnh, dòng FortiSwitch Rugged cũng đảm bảo tính toàn vẹn và hiệu suất của mạng ngay cả trong những môi trường triển khai khắc nghiệt nhất
.
Thông số kỹ thuật FortiSwitch FSR-124D
Ethernet |
Ethernet Interface |
16x GE RJ45, 4x GE SFP slots,
8 shared media interfaces (GE RJ45 / GE SFP slots) |
Console Interface |
DB9 connector |
Operating Mode |
Store and forward, L2/L3 wire-speed/non-blocking switching engine |
MAC Addresses |
8K |
Switching Capacity |
56 Gbps |
Packets Per Second |
83 Mpps |
VLANs Supported |
4K |
DRAM |
512 MB |
FLASH |
512 MB |
Copper RJ45 Ports |
Speed |
10/100/1000 Mbps |
MDI/MDIX Auto-crossover |
Support straight or cross wired cables |
Auto-negotiating |
10/100/1000 Mbps speed auto-negotiation; Full and half duplex |
PoE+ (PSE) |
N/A |
SFP (pluggable) Ports |
Port Types Supported |
Gigabit fiber multimode, fiber single mode, fiber long-haul single mode 1000Base(SX/LX/ZX) |
Link Aggregation Group Size |
LC typically for fiber (depends on module) |
Power |
Power Input |
Redundant input terminals |
Input Voltage Range |
44–57V DC. |
Reverse Power Protection |
|
Switch Power |
25.434 W (Maximum) |
Heat Dissipation |
117.49 BTU/h |
Indicators |
Power Status Indication |
Indication of power input status |
PoE Indication |
N/A |
Ethernet Port Indication |
Link and speed |
Environment |
Operating Temperature Range |
-40–167°F (-40–75°C) cold startup at -40°C/°F) |
Storage Temperature Range |
-40–185°F (-40–85°C) |
Humidity |
5–95% RH non-condensing |
MTBF |
> 30 years |
Cooling |
Fanless |
Certification and Compliances |
EMI |
Radiated Emission: CISPR 22, EN55022 Class B
Conducted Emission: EN55022 Class B |
EMS |
ESD: IEC61000-4-2
Radiated RF (RS): IEC61000-4-3
EFT: IEC61000-4-4
Surge: IEC61000-4-5
Conducted RF (CS): IEC61000-4-6 |
RoHS and WEEE |
Compliant |
FCC |
Yes, with supplementary IEEE 1613 |
ICES |
Yes |
CE |
Yes, with supplementary IEC 61850-3 |
RCM |
Yes |
VCCI |
Yes |
BSMI |
Yes |
CB |
Yes |
UL/cUL |
Yes, with additional Class I, Division 2, Groups A, B, C, D |
ATEX |
|
Mechanical |
Ingress Protection |
IP30 |
Installation Option |
DIN-Rail mounting, wall mounting |
Dimensions |
Length x Width x Height |
17.40 x 13.86 x 1.73 inches (442 x 352 x 44 mm) |
Weight |
12.78 lbs (5.80 kg) |
Warranty |
Fortinet warranty |
Limited lifetime |
Các tính năng trên Switch Fortinet FSR-112D-POE
Management and Configuration |
- Auto Discovery of Multiple Switches
- Number of Managed Switches per FortiGate: 8 to 256 Depending on FortiGate Model (Please refer to admin-guide)
- FortiLink Stacking (Auto Inter-Switch Links)
- Software Upgrade of Switches
- Centralized VLAN Configuration
- Switch POE Control
- Link Aggregation Configuration
- Spanning Tree
- LLDP/MED
- IGMP Snooping
- L3 Routing and Services
- Policy-Based Routing
- Virtual Domain
|
Security and Visibility |
- 802.1x Authentication (Port-based, MAC-Based, MAB)
- Syslog Collection
- DHCP Snooping
- Device Detection
- MAC Black/While Listing
- Policy Control of Users and Devices
|
UTM Features |
- Firewall
- IPC, AV, Application Control, Botnet
|
High Availability |
- Support FortiLink FortiGate in HA Cluster
- LAG support for FortiLink Connection
|
Layer 2 |
- Jumbo Frames
- Auto-negotiation for port speed and duplex
- IEEE 802.1D MAC Bridging/STP
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
- IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
- STP Root Guard
- Edge Port / Port Fast
- IEEE 802.1Q VLAN Tagging
- Private VLAN
- IEEE 802.3ad Link Aggregation with LACP
- Unicast/Multicast traffic balance over trunking port (dst-ip, dst-mac, src-dst-ip, src-dst-mac, src-ip, src-mac)
- IEEE 802.1AX Link Aggregation
- Spanning Tree Instances (MSTP/CST)
- IEEE 802.3x Flow Control and back-pressure
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3z 1000Base-SX/LX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3 CSMA/CD Access Method and Physical Layer Specifications
- Storm Control
- MAC, IP, Ethertype-based VLANs
- Virtual-Wire
- Time-Domain Reflectcometry (TDR) Support
|
Services |
IGMP Snooping |
Security and Visibility |
- Port Mirroring
- Admin Authentication Via RFC 2865 RADIUS
- IEEE 802.1x authentication Port-based
- IEEE 802.1x Authentication MAC-based
- IEEE 802.1x Guest and Fallback VLAN
- IEEE 802.1x MAC Access Bypass (MAB)
- IEEE 802.1x Dynamic VLAN Assignment
- sFlow
- ACL
- IEEE 802.1ab Link Layer Discovery Protocol (LLDP)
- IEEE 802.1ab LLDP-MED
- DHCP-Snooping
- Dynamic ARP Inspection
- Sticky MAC and MAC Limit
|
Quality of Service |
- IEEE 802.1p Based Priority Queuing
- IP TOS/DSCP Based Priority Queuing
|
Management |
- IPv4 and IPv6 Management
- Telnet / SSH
- HTTP / HTTPS
- SNMP v1/v2c/v3
- SNTP
- Standard CLI and web GUI interface
- Software download/upload: TFTP/FTP/GUI
- Managed from FortiGate
- Support for HTTP REST APIs for Configuration and Monitoring
|
Additional RFC and MIB Support |
- RFC 2571 Architecture for Describing SNMP Framework
- DHCP Client
- RFC 854 Telnet Server
- RFC 2865 RADIUS
- RFC 1643 Ethernet-like Interface MIB
- RFC 1213 MIB-II
- RFC 1354 IP Forwarding Table MIB
- RFC 2572 SNMP Message Processing and Dispatching
- RFC 1573 SNMP MIB II
- RFC 1157 SNMPv1/v2c
- RFC 2030 SNTP
|
Bạn đang cần tư vấn về sản phẩm: FSR-124D ?
Switch Fortinet FSR-124D này có tính năng routing bạn nhé
Datasheet của switch Fortinet FSR-124D đã được gửi vào mail của bạn, bạn vui lòng check giúp shop nha. Nếu có thắc mắc gì khác, hãy liên hệ với shop qua hotline 0906.051.599 để được tư vấn một cách chi tiết hơn bạn nhé
Báo giá của switch Fortinet FSR-124D đã được gửi vào mail của bạn. Bạn vui lòng check mail nhé. Nếu cần tư vấn hay có thắc mắc gì khác, bạn vui lòng liên hệ với shop nhé.
Thiết bị chuyển mạch Fortinet FortiSwitch FSR-124D được thiết kế để sử dụng trong môi trường khắc nghiệt nhé bạn.
